High speed KOYO bearing DAC35680042-2RZ KOYO wheel hub bearing DAC35680042

The main function of a hub bearing is to support the load and provide precise guidance for the rotation of the hub. It bears both axial and radial loads and is a very important component. Traditional automotive wheel bearings are composed of two sets of tapered roller bearings or ball bearings. The installation, oiling, sealing and clearance adjustment of the bearings are performed on the automobile production line. This structure makes it difficult to assemble, high cost, and poor reliability in an automobile production plant, and the bearing needs to be cleaned, oiled, and adjusted when the automobile is maintained at a repair point. The hub bearing unit is developed on the basis of standard angular contact ball bearings and tapered roller bearings. It integrates two sets of bearings, has good assembly performance, can eliminate clearance adjustment, light weight, compact structure, and load capacity. Large, sealed bearings can be pre-installed with grease, omitting the external hub seal and maintenance-free, etc., has been widely used in cars, there is also a trend to gradually expand the application in trucks.

Item	DAC35680042
Dimension	35X68X42MM
Weight	0.52Kg
Material	Chrome steel/Gcr15(SAE52100)
Brand	KOYO
Package	Bulk , single box and industrial package,



Wheel Bearing Feature

• Less coefficient of friction


• High limiting speed


• With Heavier load used in various automobiles


• Types: seal type A, B, C, D, E and F


• Manufaturing according to customers' drawing and samples

Characteristics of wheel hub bearings

l Less energy consumption.

l Durable seals and couping life.

l Less vibration and noise.

l Super finished raceways.





P.N.	d	D	B	Mass (kg)
25BWD01	25	52	42	0.36
27BWD01J	27	60	50	0.36
28BWD03A	28	58	42	0.4
28BWD01A	28	61	42	0.53
30BWD08	30	55	26	0.26
30BWD01A	30	63	42	0.55
30BWD04	30	68	45	0.69
32BWD05	32	72	45	0.8
34BWD04B	34	64	37	0.82
34BWD11	34	64	37	0.46
34BWD10B	34	66	37	0.51
34BWD07B	34	68	42	0.64
34BWD09A	34	68	37	0.54
35BWD19E	35	65	37	0.48
35BWD07	35	68	30	0.48
35BWD07A	35	68	30	0.48
35BWD16	35	68	36	0.48
35BWD06A	35	72	31	0.55
36BWD04	36	68	33	0.48
36BWD03	36	72	42	0.68
