 Machine Features:
1. The machine has strong continuity and stability, and is suitable for producing all kinds of four-side sealing wipes, alcohol pads, cotton pads and other products.
2. Using the metering pump imported from Japan, a variety of liquids can be subpackaged and mixed. Precise control (adding error is 0.01ml/time).
3. Simple and easy to operate, servo motor, PLC touch screen, can freely adjust temperature, speed and length of wet wipes. Optical and electrical integration design, automatic fault alarm and safety control instructions.
4. The language in the touch screen can be customized according to requirements.

Technical Parameter:

Item/model	YG-W280Y
Packaging form	Horizontal  Four-side sealing
Packing material	CPP film ,PE film ,BOPP film ,paper ,aluminum
Inner material	30-80g/m2(Air laid paper,nonwoven,spun lace nonwoven fabric etc)
Raw material inner roller diameter	∅70-75mm
Packing specification	Length 50-140mm( can adjustable design max 220mm)
	Width 50-110mm (can adjustable design)
Floding way	Max 10 folding vertical,and 4 folding horizontal
Liquid added range	0-10ml
Packing speed	60-150bags/minute
Total power	7.0KW
Power supply type	380V 50/60Hz
Machine noise	≤64.9dB(A)
Air supply	0.6-0.8Mpa
Air consumption	300-500mL/min
Dimension	3200*2600*1800mm
Machine weight	1200kg
