Полуавтоматическая Четырехцветная машина для печати на
- Категория: Carton\u00A0Printing\u00A0Slotting\u00A0Die-Cutting\u00A0Machinery >>>
- Поставщик: Hebei,Huazhu,Carton,Equipment,Manufacturing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.4 $* | 0.56 $* |
| Aug-17-2025 | 0.81 $* | 0.41 $* |
| Jul-17-2025 | 0.42 $* | 0.53 $* |
| Jun-17-2025 | 0.92 $* | 0.46 $* |
| May-17-2025 | 0.7 $* | 0.23 $* |
| Apr-17-2025 | 0.66 $* | 0.55 $* |
| Mar-17-2025 | 0.68 $* | 0.34 $* |
| Feb-17-2025 | 0.89 $* | 0.52 $* |
| Jan-17-2025 | 0.84 $* | 0.92 $* |
Характеристики
Product Description
● Designed in accordance with The European concept, functional, security more reliable.
●PLC touch screen control, including automatic counting, speed, quantity display, interval, alarm lamp function.
● High quality materials and accessories are selected. All drive rollers are made of high quality steel, balanced by static and static, and polished by grinding and plating hard chrome.
● The main transmission gear adopts 40 chromium high quality alloy steel high frequency quenching treatment, high precision processing, high precision gear, wear resistance, transmission Stable and reliable delivery, rockwell hardness >60 degrees.
● The main drive bearing is AAA quality bearing of Harbin.
● The main control electrical appliances with domestic famous brand Zhengtai.
● Keyless connection ring is applied to reduce center wear and keep long-term printing overprint accuracy.
● Host start protection, host can not start actively without locking, to prevent misoperation.
● All units of the machine are automatically or independently separated, electrically operated and pneumatically locked, and the alarm bell continuously rings during walking to ensure the safety of operators. Automatic braking to ensure position cannot be moved.
● Emergency stop protection, emergency stop switch is set in the machine, which can quickly stop the unit movement inside, ensuring more protection.
● Control system: the host computer adopts PLC control system, touch computer screen operation. Each group is controlled by phase meter.
● The main transmission gear adopts 40 chromium high quality alloy steel high frequency quenching treatment, high precision processing, high precision gear, wear resistance, transmission Stable and reliable delivery, rockwell hardness >60 degrees.
● The main drive bearing is AAA quality bearing of Harbin.
● The main control electrical appliances with domestic famous brand Zhengtai.
● Keyless connection ring is applied to reduce center wear and keep long-term printing overprint accuracy.
● Host start protection, host can not start actively without locking, to prevent misoperation.
● All units of the machine are automatically or independently separated, electrically operated and pneumatically locked, and the alarm bell continuously rings during walking to ensure the safety of operators. Automatic braking to ensure position cannot be moved.
● Emergency stop protection, emergency stop switch is set in the machine, which can quickly stop the unit movement inside, ensuring more protection.
● Control system: the host computer adopts PLC control system, touch computer screen operation. Each group is controlled by phase meter.
The machine clutch
(2) The transmission shaft is attached with friction clutch to avoid damage to the machine due to incorrect operation.
(3) Pneumatic interlocking device.
(4) Pneumatic protection device for main engine motor.
(4) Pneumatic protection device for main engine motor.
Printing Department
(1) the diameter of 480 mm (including edition) Ø. High quality steel
(2) The surface of the steel tube is ground and hard branded.
(3) Balance correction, stable operation.
(2) The surface of the steel tube is ground and hard branded.
(3) Balance correction, stable operation.
(4) Printing plate roller adopts plate hanging device, foot switch control positive and negative rotation, loading and unloading printing plate fast and convenient.
(5) Fixed scroll plate shaft.
(6) Full version hanging glue slot, applicable for 10mm*3mm hanging plate.
(7) Loading and unloading printing plate, foot switch electric control forward turning.
(8) Roller wall thickness 16mm
(5) Fixed scroll plate shaft.
(6) Full version hanging glue slot, applicable for 10mm*3mm hanging plate.
(7) Loading and unloading printing plate, foot switch electric control forward turning.
(8) Roller wall thickness 16mm
Die-cutting with slotter (down): Die-cutting and Slotting
(1) Surface grinding, hard burning plating
2）The lower roller is equipped with a plate-free slotting device. The template is not used in the standard slotting box to reduce the use cost. Four slotting knives are used to adjust the height of the box synchronously.
(3) Equipped with roller lifting device, when there is no cardboard, the die roller will automatically drop to reduce the wear ofrubber cushion roller.
2）The lower roller is equipped with a plate-free slotting device. The template is not used in the standard slotting box to reduce the use cost. Four slotting knives are used to adjust the height of the box synchronously.
(3) Equipped with roller lifting device, when there is no cardboard, the die roller will automatically drop to reduce the wear ofrubber cushion roller.
Size Information
model | 1200mm | 1450mm | 1650mm | ||
The machine width | 2000/2600/2800/3000mm | 2000/2600/2800/3000mm | 2000/2600/2800/3200mm | ||
Design speed | 200piece/min | 150piece/min | 140piece/min | ||
Economic speed | 150piece/min | 120piece/min | 120piece/min | ||
Maximum feed size | 1700/2300/2600/2700mm | 1700/2300/2600/2700mm | 1700/2300/2500/2900mm | ||
Minimum feed size | 300×500mm | 350×500mm | 500×650mm | ||
paper thickness | 0-12mm | ||||
Tinted precision | two color±0.5mm | ||||
Maximum printing area | 1600/2200/2500/2600mm | 1600/2200/2400/2600mm | 1600/2200/2400/2800mm | ||
The standard version of thickness | 7.2mm | ||||
Axial adjustment of printing roller | ±15mm | ||||
