Китайский ведущий бренд SHANTUI 130HP гусеничный бульдозер SD13 горячая
- Категория: Bulldozers >>>
- Поставщик: Anhui,Heavy,And,Light,Industries,International,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 49385.55 $* | 51854.85 $* |
| Aug-17-2025 | 48970.49 $* | 51419.64 $* |
| Jul-17-2025 | 41085.63 $* | 43139.55 $* |
| Jun-17-2025 | 48140.75 $* | 50547.13 $* |
| May-17-2025 | 41915.36 $* | 44011.94 $* |
| Apr-17-2025 | 47310.26 $* | 49676.54 $* |
| Mar-17-2025 | 46895.39 $* | 49240.27 $* |
| Feb-17-2025 | 46480.82 $* | 48804.55 $* |
| Jan-17-2025 | 46065.10 $* | 48368.28 $* |
Характеристики
Product Description
Detail Information of SD13
1.The Weichai electronic control, direct injection, turbocharged engine equipped features high torque reserve
co-efficient, excellent energy-conservation and environment-friendliness, and strong power.
2.The split transmission and torque converter system, single-turbine three-element torque converter, and AMT full-automatic electronic control transmission feature simple structure and higher reliability.
3.The electronic control joysticks feature convenient and flexible operations and incorporate the blade floating function.
4.The full-hydraulic maintenance-free wet drive axle features fast response, stable braking, and high safety and reliability.
Specification/Blade type | Straight-tilt | Angle | U-Blade | |||||
Operating Weight | Kg | 17400 | 17700 | 17900 | ||||
Min.Turning Radius | M | 3.2 | 3.2 | 3.2 | ||||
Ground Pressure | MPa | 0.069 | 0.07 | 0.071 | ||||
Track Gauge | MM | 1880 | 1880 | 1880 | ||||
Max. Pulling Force | KN | 142 | 142 | 142 | ||||
Grade Ability | ° | 30 | 30 | 30 | ||||
TRAVEL SPEED | ||||||||
1st | 2nd | 3rd | ||||||
Forward (km) | 0～3.8 | 0～6.6 | 0～10.6 | |||||
Reverse (km) | 0～10.6 | 0～8.5 | 0～13.6 | |||||
ENGINE | ||||||||
Model & Type | Weichai WD10G178E25 | |||||||
6-cylinder, in-line, vertical. water-cooled, 4-stroke-cycle, turbo-charged, over valve directs injection | ||||||||
Rated Revolution | (rpm) | 1850 | ||||||
Flywheel Horsepower | (HP) | 130 | ||||||
Cylinder Number-BoreX Stroke | (mm) | 6-126X 130 | ||||||
Piston Displacement | (L) | 9.73 | ||||||
Min. Fuel Consumption | (g/kW.h) | 223 | ||||||
Max.Torque | (Nm/rpm) | 830/1100 | ||||||
Starting Motor | V*KW | 24*7.5 | ||||||
POWER TRANSMISSION SYSTEM | ||||||||
Torque Converte | 3-element,1-stage,1-phase | |||||||
Transmission | Planetary gearing, hand-manipulated, hydraulic shift， forced lubrication,3 forward and 3 reverse speeds | |||||||
Bevel Gear | Spiral bevel gear, splash lubrication, single-stage speed reduction | |||||||
Steering Clutch | Wet, multi-disc, spring loaded, hydraulically separated, hydraulic control | |||||||
Steering Brake | Wet, band type, pedal hydraulic booster, with parking brakes | |||||||
Final Drive | Double reduction of spur gear, splash lubrication | |||||||
HYDRAULIC SYSTEM | ||||||||
Pump Type | Gear pump 07441-67503 | |||||||
Working Pressure | (MPa) | 13.4 | ||||||
System Discharge | (L/min) | 250 | ||||||
Working Cylinder type | Double-acting piston type | |||||||
Working Cylinder Lift Number-BoreXRodXStroke | (mm） | 2-110X65X1026 | ||||||
Working Cylinder Tilt BoreXRodXStroke | (mm) | 160X70X140 | ||||||
UNDERCARRIAGE SYSTEM | ||||||||
Type | Swing type of sprayed beam, suspended structure of equalizer bar | |||||||
Carrier Rollers | 2(each side) | |||||||
Track Rollers | 6/each side (4-single flange, 2-double flange) | |||||||
Track Type | Sealed, assembled single- grouser | |||||||
Number Of Track Shoes | 37(each side) | |||||||
Width Of Track Shoes | (mm) | 510 | ||||||
Pitch | (mm) | 203.2 | ||||||
Length Of Track 0n Ground | (mm) | 2430 | ||||||
WORK EQUIPMENT | ||||||||
Specification/Blade type | Straight-tilt | Angle | Angle | |||||
Blade Capacity | (m3) | 4.5 | 4.3 | 8.6 | ||||
Blade Width X Height | (mm) | 3416×1145 | 3970×1037 | 4064×1386 | ||||
Max.Lift | (mm) | 1110 | 1095 | 1110 | ||||
Max.Depth | (mm) | 530 | 545 | 530 | ||||
Max.tilt Adjustment | (mm) | ≥860 | ≥400 | ≥400 | ||||
Pitch Adjustment | ( ° ) | 55 | 55 | 55 | ||||
Capability | (m3/H) | 247 | 247 | 260 | ||||
Weight Of Blade | (kg) | 2350 | 2450 | 2560 | ||||
COOLANT AND LUBRICANT CAPACITY | ||||||||
Fuel Tank Capacity | L | 320 | ||||||
Hydraulic Tank Capacity | L | 108 | ||||||
Engine oil Capacity | L | 45 | ||||||
Torque Converter ,Transmission, Bevel Gear., Steering Clutch Capacity | L | 122 | ||||||
Final Drive Capacity | (L) | 33(each side) | ||||||
RIPPER(OPTIONAL) | ||||||||
3-Shank Ripper: | ||||||||
Max.Digging Depth | (mm) | 572 | ||||||
Max.Lift | (mm) | 702 | ||||||
Shank Of Distance | (mm) | 950 | ||||||
Weight | (kg) | 1700 | ||||||
Recommend Products
Company Profile
FAQ
1: What kind terms of payment can be accepted? A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted | ||||||||
2: What certificates are available in Machinery? A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC, | ||||||||
3: What about the delivery time? A: 7-20 days after receiving the deposit. | ||||||||
4: What about the warranty time? A: 12 months after shipment or 2000 working hours, whichever occuts first. | ||||||||
5. What about the Minimum Order Quantity? A: The MOQ is 1 pcs | ||||||||
