Китайский поставщик завод по производству гипсовых порошков Лидер продаж машина для производства
- Категория: Construction & Building Machinery >>>
- Поставщик: Henan,Turui,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 8752714.2 $* | 9190350.4 $* |
| Aug-20-2025 | 8679162.39 $* | 9113120.55 $* |
| Jul-20-2025 | 7281670.43 $* | 7645754.88 $* |
| Jun-20-2025 | 8532058.8 $* | 8958661.57 $* |
| May-20-2025 | 7428774.60 $* | 7800213.29 $* |
| Apr-20-2025 | 8384953.5 $* | 8804201.15 $* |
| Mar-20-2025 | 8311401.45 $* | 8726971.58 $* |
| Feb-20-2025 | 8237849.78 $* | 8649741.24 $* |
| Jan-20-2025 | 8164296.55 $* | 8572511.28 $* |
Характеристики
Product Description
China supplier gypsum plant manufacturer hot sale gypsum making machine best quality gypsum powder manufacturing machine
Machine component:mainframe, separator, blower, finished powder cyclone collector, bag filter and connecting pipes, etc.Processed Materials: Limestone, calcite, barite, dolomite, potassium feldspar, marble,talcum, gypsum, kaolin, bentonite, medical stone, rock phosphate, iron ore, quartz, active carbon, coal, ect.
[ Capacity ]: 0.5–60 t/h
[ Applicable Material ]:
Raymond mill, also known as raymond grinding mill, raymond roller mill and raymond grinder, is suitable for grinding non-flammable and non-explosive materials.The finished powder size can be adjusted between 30 and 425 mesh(0.613mm-0.044mm).
[ Applicable Material ]:
Raymond mill, also known as raymond grinding mill, raymond roller mill and raymond grinder, is suitable for grinding non-flammable and non-explosive materials.The finished powder size can be adjusted between 30 and 425 mesh(0.613mm-0.044mm).
Raymond mill is suitable for process in various non-flammable mineral which is below seven Mos hardness, moisture below 6%, such as limestone, calcite carbonate,dolomite, barite, talc, gypsum, diabase, quartz, bentonite, bauxite, iron ore, etc.
Application
Gypsum calcination process plant production line --- the latest type of Raymond Mill, has become one of the most advanced grinding mills in the world with its so many intellectual properties like bear-gear drive, inner oil lubricating system, arc air channel, etc. It is widely used in cement, coal , power plant desulfurization, metallurgy, chemical industry, non-metallic mineral, construction material, ceramics, etc.. It can process the material such as limestone, calcite, barite, dolomite, potassium feldspar, bentonite, medical stone, rock phosphate, manganese ore, iron ore, quartz, active carbon, carbon black, ceramic, coal, etc..
Working Principle
1>. The whole structure of Raymond Mill machine is mainly including the host, analysis machine, plumbing fixtures and the blower, according to user needs, it can be equipped with crusher, elevator, electromagnetic vibrating feeder, electric control cabinet etc.
2>. After materials crushed to the desired particle size, enter into the storage hopper by the elevator, and then through vibrating feeder enter into grinding chamber of Raymond mill uniform continuously.
3>. Due to the centrifugal force when rotating, the rollers swings outward, pressed on the grinding ring, shovel blade scoop up materials, then sent them between grinding roller and grinding ring, due to the grinding roller roller rolling to achieve crushing purpose.
4>. After grinding material, the powder along with the circulating air which made by blower, is brought into the analysis machine for sorting, coarse material will regrind. Qualified powder along with the air enters into finished product cyclone powder collector, then discharge powder tube, that is finished product.
5>. In the grinding chamber of Raymond mill, because there are certain moisture in the grinded material, when grinding, it will generate heat, moisture evaporates, and the pipe interface of the whole is not tight, the outside air is drawn into making the circulation pressure increased to ensure that the mill wok under negative pressure. The increased air flow enter into the dust through the duct, at last enter into the atmosphere after purification.
2>. After materials crushed to the desired particle size, enter into the storage hopper by the elevator, and then through vibrating feeder enter into grinding chamber of Raymond mill uniform continuously.
3>. Due to the centrifugal force when rotating, the rollers swings outward, pressed on the grinding ring, shovel blade scoop up materials, then sent them between grinding roller and grinding ring, due to the grinding roller roller rolling to achieve crushing purpose.
4>. After grinding material, the powder along with the circulating air which made by blower, is brought into the analysis machine for sorting, coarse material will regrind. Qualified powder along with the air enters into finished product cyclone powder collector, then discharge powder tube, that is finished product.
5>. In the grinding chamber of Raymond mill, because there are certain moisture in the grinded material, when grinding, it will generate heat, moisture evaporates, and the pipe interface of the whole is not tight, the outside air is drawn into making the circulation pressure increased to ensure that the mill wok under negative pressure. The increased air flow enter into the dust through the duct, at last enter into the atmosphere after purification.
Technical Parameter
SPECIFICATIONS | ||||||
capacity per year | capacity per hour | gypsum consumption per year | calciner dimension | |||
20,000 tons | 2.7 tons | 24000 tons | 4.5 x 1.0 x 1.2 m | |||
30,000 tons | 4.2 tons | 36000 tons | 4.5 x 1.2 x 1.4 m | |||
50,000 tons | 6.9 tons | 60000 tons | 4.5 x 1.4 x 1.6 m | |||
60,000 tons | 8.3 tons | 72000 tons | 4.5 x 1.6 x 1.8 m | |||
100,000 tons | 13.88 tons | 120000 tons | 4.5 x 2.0 x 2.2 m | |||
150,000 tons | 20.83 tons | 180000 tons | 4.5 x 2.2 x 2.4 m | |||
200,000 tons | 27.77 tons | 240000 tons | 4.5 x 2.4 x 2.6 m | |||
Gypsum Products Parameters:
1.Fineness: ≥100 mesh;
2.Flexural Strength (having a direct relation to raw material): ≥1.8Mpa; The Strength of Antipressure: ≥3.0Mpa;
3.Main Contents: Hemihydrate: ≥80% (Adjustable);
Gypsum <5% (Adjustable);
Soluble Anhydrous <5%(Adjustable).
4. The Initial Setting Time: 3-8min (Adjustable); the Final Setting Time: 6~15min (Adjustable)
5.Consistency: 65%~75% (Adjustable)
1.Fineness: ≥100 mesh;
2.Flexural Strength (having a direct relation to raw material): ≥1.8Mpa; The Strength of Antipressure: ≥3.0Mpa;
3.Main Contents: Hemihydrate: ≥80% (Adjustable);
Gypsum <5% (Adjustable);
Soluble Anhydrous <5%(Adjustable).
4. The Initial Setting Time: 3-8min (Adjustable); the Final Setting Time: 6~15min (Adjustable)
5.Consistency: 65%~75% (Adjustable)
Packing & Delivery
Packaging Details: We will make different packaging according to different machine sizes .standard international export packing, container, wooden box.
Delivery Time: We will customize according to the actual needs of customers. Senior designers start to design the plan. After receiving the deposit, we will complete the delivery within 20 to 30 working days.
Delivery Time: We will customize according to the actual needs of customers. Senior designers start to design the plan. After receiving the deposit, we will complete the delivery within 20 to 30 working days.
Our factory is capable of shipping large machine even more than 100 tons.
Customer Case
Hot-sale in many countries: Zimbabwe, Mozambique, Zambia, South Africa, Kenya, Philippines, Indonesia, Vietnam, Uganda, Ethiopia, Tanzania, Peru, Mexico.
Company Profile
Henan Turui Machinery Co., Ltd is a professional manufacturer of different mining machinery. It integrates the design, research, production, sales and installation together, guaranteeing the reliable and stable quality.
Its main products includes calcining equipment, ore dressing equipment, crushing and screening equipment, drying and cooling equipment, and grinding equipment. There are more than hundred of customers using our products all over the world, such as in south-east Asia, south-Asia, middle Asia, middle-east area, Africa, Australia, South America. The company covers an area of 40,000 square meters, building area of 10,000 spare meters. There are more than forty sets of boring-milling machine, gear hobbling machine, vertical lathe, and travelling crane at the workshop.
Its main products includes calcining equipment, ore dressing equipment, crushing and screening equipment, drying and cooling equipment, and grinding equipment. There are more than hundred of customers using our products all over the world, such as in south-east Asia, south-Asia, middle Asia, middle-east area, Africa, Australia, South America. The company covers an area of 40,000 square meters, building area of 10,000 spare meters. There are more than forty sets of boring-milling machine, gear hobbling machine, vertical lathe, and travelling crane at the workshop.
Now the company has more than one hundred employees, including 8 professional engineers. Seventy-five percent of the employees have participated the professional technical training, which makes sure high-efficient pre-sales and after-sale service.
FAQ
1.Q:How is the quality of your products?
A: Our products are manufactured strictly according to national and international standard, and we will take a test on every grinder before delivery.
2.Q:How about the Guaranteed?
A : All of our products are guaranteed for one year. If products quality is not consistent with the description as we described or the promise before you place order, we promise 100% refund.
3.Q:How about price?
A: For the complete same machine, we can promise our quality is the best when the price same as other competitors, and our price can be lowest when the quality at standard level.
4.Q:How about the service and payment terms?
A: We can accept T/T or other payment ways you request; 30% deposit, 70% balance before delivery, which is international trade practice; Finished product pictures will provide to customers before delivery.
A: Our products are manufactured strictly according to national and international standard, and we will take a test on every grinder before delivery.
2.Q:How about the Guaranteed?
A : All of our products are guaranteed for one year. If products quality is not consistent with the description as we described or the promise before you place order, we promise 100% refund.
3.Q:How about price?
A: For the complete same machine, we can promise our quality is the best when the price same as other competitors, and our price can be lowest when the quality at standard level.
4.Q:How about the service and payment terms?
A: We can accept T/T or other payment ways you request; 30% deposit, 70% balance before delivery, which is international trade practice; Finished product pictures will provide to customers before delivery.
