Роликовый подшипник NJ NU 2210 Однорядный цилиндрический роликовый NJ2210

Роликовый подшипник NJ NU 2210 Однорядный цилиндрический роликовый NJ2210

Категория: Cylindrical Roller Bearings >>>
Поставщик: Shandong,Bohong,Bearing,Co.,Ltd.

Цена:1,20 $ - 3,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Aug-19-2025	1.17 $*	1.24 $*
Jul-19-2025	1.73 $*	1.14 $*
Jun-19-2025	1.99 $*	1.41 $*
May-19-2025	1.49 $*	1.54 $*
Apr-19-2025	1.26 $*	1.5 $*
Mar-19-2025	1.32 $*	1.24 $*
Feb-19-2025	1.89 $*	1.48 $*
Jan-19-2025	1.31 $*	1.62 $*

Характеристики

roller bearing NJ NU 2210 single-row cylindrical roller bearing NJ2210 NU2210

Product Description

Cylindrical roller bearings, the cylindrical rollers are in linear contact with the raceways. They have a high radial load capacity and are suitable for high speeds.

There are different types designated as NU, NJ, NUP, N, NF (for single-row bearings), NNU, and NN (for double-row bearings depending on the design or absence of side ribs).

Double row cylindrical roller bearings are available in several designs with a cylindrical or tapered bore. The standard assortment presented in this section includes:
NNU design bearings
NN design bearings
NNUP design bearings

Specifications: NJ2210 cylindrical roller bearing NJ 2210 ECP/C3 single row
Roller bearing types	cylindrical roller bearing
Number of row	single row
Bore diameter	50mm
Outside diameter	90mm
Overall width	23mm
Cage material	nylon cage, brass cage, steel cage
Bore type	straight bore
Maximum rpm	9000RPM high speed bearing
Dynamic load capacity	90kN
Static load capacity	88kN
Origin	China cylindrical roller bearing
Bearing material	Gcr15 steel bearing
Internal clearance	C3 C4 C0 clearance bearing
Bearing precision	P0 P6 P5 P4 abec5 quality bearing

Types of cylindrical roller bearing:
Single row cylindrical roller bearing: NU, NJ, NUP, NUB series
Double row cylindrical roller bearings:NNU series
Four row cylindrical roller bearing:FC series
Single row full complement cylindrical roller bearing:SL18 series, SL 19 series
Double row full complement cylindrical roller bearing: SL01 series, SL02 series, SL18 series.

NU cylindrical roller bearing catalogue list:

Bearing Number	Inner dia (mm)	Outer dia (mm)	Thickness (mm)	Weight (Kg)
NU2203	17	40	16	0.092
NU2204	20	47	18	0.14
NU2205	25	52	18	0.17
NU2206	30	62	20	0.26
NU2207	35	72	23	0.40
NU2208	40	80	23	0.54
NU2209	45	85	23	0.52
NU2210	50	90	23	0.56
NU2211	55	100	25	0.79
NU2212	60	110	28	1.10
NU2213	65	120	31	1.40
NU2214	70	125	31	1.55
NU2215	75	130	31	1.60
NU2216	80	140	33	2.00
NU2217	85	150	36	2.45
NU2218	90	160	40	3.15
NU2219	95	170	43	3.85
NU2220	100	180	46	4.75
NU2222	110	200	53	6.70
NU2224	120	215	58	8.30
NU2226	130	230	64	10.5
NU2228	140	250	68	15.0
NU2230	150	270	73	20.0
NU2232	160	290	80	24.0
NU2234	170	310	86	30.0
NU2236	180	320	86	31.5
NU2238	190	340	92	39.0
NU2240	200	360	98	46.0
NU2244	220	400	108	62.5
NU2248	240	440	120	84.0
NU2252	260	480	130	110
NU2256	280	500	130	115
NU2260	300	540	140	145
NU2264	320	580	150	180
NU2268	340	620	165	220
NU2272	360	650	170	250
NU2276	380	680	175	275
NU2292	460	830	212	530
