Подземный самосвал MDT16 для горных работ тонннельный 16 тонн без шарнирного подземного рудника
- Категория: Mining Machinery >>>
- Поставщик: Zhengzhou,Kepai,Mechanical,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 18921.74 $* | 19867.93 $* |
| Aug-17-2025 | 18762.41 $* | 19700.63 $* |
| Jul-17-2025 | 15741.93 $* | 16528.48 $* |
| Jun-17-2025 | 18444.7 $* | 19366.94 $* |
| May-17-2025 | 16059.78 $* | 16862.35 $* |
| Apr-17-2025 | 18126.57 $* | 19032.31 $* |
| Mar-17-2025 | 17967.28 $* | 18865.18 $* |
| Feb-17-2025 | 17808.98 $* | 18698.68 $* |
| Jan-17-2025 | 17649.39 $* | 18531.42 $* |
Характеристики
Product Description
MDT series 4-45 tons mining dump trucks mainly used for underground mines, above ground mines pit and mining areas, muddy roads, tunnel construction, Building construction, swamps, river beaches, deserts, paddy fields, tropical rain forests, snow and ice etc.
The truck Certified to mine safety standards. It have the characteristics of large traction, good climbing performance and strong transportation capacity.
The truck Dimension is small, Suitable for working in narrow mine tunnel. Exhaust gas treatment is Water filter purifier, reducing air pollution when working in underground mines.
Model | MDT6 | MDT8 | MDT10 | MDT12 |
Rated Capacity(Ton) | 6 | 8 | 10 | 12 |
Rated power(HP) | 63 | 95 | 110 | 110 |
engine model | Yunnei 490 | Yunnei 4102 | Yunnei 4102 | Yunnei 4102 |
Fuel type | Diesel | Diesel | Diesel | Diesel |
Type of drive | 4*4WD (or 4*2 WD) | 4*4WD (or 4*2 WD) | 4*4WD (or 4*2 WD) | 4*4WD (or 4*2 WD) |
Braking form | Air brake (or wet brake) | Air brake (or wet brake) | Air brake (or wet brake) | Air brake (or wet brake) |
Tire | 700-16, Front 2 tires+Rear4 tires | 750-16, Front 2 tires+Rear4 tires | 750-16, Front 2 tires+Rear4 tires | 825-16, Front 2 tires+Rear4 tires |
Wheelbase | 2280 | 2500 | 2600 | 2650 |
cargo body volume | 2700*1650*550mm, 2.2 cbm | 3000*1800*700mm, 3.2 cbm | 3300*1800*700mm, 4 cbm | 3400*2100*700mm, 4.8 cbm |
cargo Steel plate thickness | Bottom 8mm, side 6mm | Bottom10mm, side 6mm | Bottom10mm, side 6mm | Bottom10mm, side 6mm |
Dimension(L*W*H) (mm) | 4350*1650*1950mm | 4700*1800*2050mm | 5000*1800*2050mm | 5200*2100*2050mm |
| Model | MDT16 | MDT20 | MDT25A | MDT25B |
| Rated Capacity(Ton) | 16 | 20 | 25 | 25 |
| Rated power(HP) | 160 | 210 | 290 | 290 |
| engine model | Yuchai 4108 | Yuchai 210 | Yuchai 290 | Yuchai 290 |
| Fuel type | Diesel | Diesel | Diesel | Diesel |
| Type of drive | 4*4WD (or 4*2 WD) | 4*2 WD | 4*2 WD | 6*4 WD |
| Braking form | Air brake (wet brake) | Air brake | Air brake | Air brake |
| Tire | 900-20, 2 Front 2 tires+Rear4 tires | 1000-20, Front 2 tires+Rear4 tires | 1000-20, Front 2 tires+Rear4 tires | 1100-20, Front 2 tires+Rear48tires |
| Wheelbase | 3000 | 3200 | 3500 | 3650 |
| Ground clearance (mm) | 255 | 325 | 325 | 325 |
| cargo body volume | 3600*2200*750mm, 6 cbm | 3600*2300*1000mm, 8 cbm | 4600*2400*1100mm, 11 cbm | 4700*2400*1000mm, 11 cbm |
| cargo Steel plate thickness | Bottom10mm, side 8mm | Bottom12mm, side 8mm | Bottom12mm, side 8mm | Bottom12mm, side 8mm |
| Dimension(L*W*H) (mm) | 5600*2300*2150mm | 6100*2450*2400mm | 6800*2400*2400mm | 7800*2450*2700mm |
