12 кВ 250 кВА ZGS американская сборная
- Категория: Industrial Controls >>>
- Поставщик: Shenheng,Power,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.53 $* | 0.92 $* |
| Aug-16-2025 | 0.15 $* | 0.9 $* |
| Jul-16-2025 | 0.79 $* | 0.4 $* |
| Jun-16-2025 | 0.45 $* | 0.59 $* |
| May-16-2025 | 0.12 $* | 0.43 $* |
| Apr-16-2025 | 0.74 $* | 0.17 $* |
| Mar-16-2025 | 0.68 $* | 0.0 $* |
| Feb-16-2025 | 0.76 $* | 0.67 $* |
| Jan-16-2025 | 0.19 $* | 0.40 $* |
Характеристики
Products Description
Altitude | not more than 1000m |
Ambient temperature | -35℃ ~+40℃ |
Relative humidity | the daily average is not more than 95%, the monthly average is not more than 90% |
transformer | Intelligent integrated substation selection of low loss, oil-immersed, fully sealed S9, S10, S11 series transformer, can also choose resin insulation or NOMEX paper insulation environmental protection type dry transformer |
name | unit | technical parameter |
rated voltage | KV | 10/0.4(High pressure / low pressure) |
maximum operating voltage | KV | 12(high-pressure side) |
rated frequency | HZ | fifty |
rated capacity | KVA | 50-1600 |
1minPower frequency and pressure resistance | KV | thirty-five |
Lightning impact voltage | KV | seventy-five |
cooling-down method | immersed natural cooling | |
High voltage backup fuse open current | KA | fifty |
Add-in fuse plug-off current | KA | Two point five |
ambient temperature | °C | -35- +40 |
The coil allows a temperature rise | °C | sixty-five |
No load pressure regulation | +-5%or+-2*2.5% | |
noise grade | db | fifty |
levels of protection | IP43 |
certificates
Company Profile
Shenheng Power Equipment CO., LTD is a company specializing in the production of high and low voltage switch power transmission and distribution equipment and high, low voltage electrical components, one of the professional production enterprises, the production of all fully insulated and fully sealed inflatable cabinet, intelligent solid insulation ring main unit, outdoor high voltage cable branch box, box-type substation, etc. Product quality is stable, reliable, It is deeply trusted and approved by the customers.
Manufacturing of the main products are YBW box-type substation, KYN61-40.5, KYN28A - 24, KYN28A - 12, XGN2-10, HXGN-10 high voltage switchgear, XGN ring net cabinet, SHSRM inflatable ring main unit, SHSG solid ring main unit, MNS, GCS, GCS, GGD, XL low voltage switchgear , vacuum circuit breaker , oil immersed transformer , dry type transformer , current /potential transformer,load break switch and other transmission and distribution equipment.
For a long time also for all kinds of metallurgy, shipbuilding, electric power, mining, and intelligent buildings, high-rise buildings, hospitals, schools and other industries to provide high quality power transmission and distribution of complete sets of equipment and electrical control equipment. The company has a strong technical force, sophisticated technology and sophisticated testing methods, and the products sell well across the country.
company workshop
our workshop
Inspection by engineer
packaging
FAQ
1. Are you a trading company or manufacturer ?
We are a professional factory with 10 years experience in the field of High and low Voltage switchgears,
Substation,transformers,cable distribution box and various electrical equipment, such as vacuum circuitbreaker , load break switch etc.Our factory is the excellent supplier of State Grid Corporation od China .
2. Do you accept customized serveice ?
We offer OEM/ODM service , can print your logo on product . our professional technical and quotation team can provice a satisfied project according to your drawing and parameters .
3. What is your MOQ?
Our MOQ is 1 piece.
4. How long is your delivery lead time ?
It depends on your product requirement and quantity . Generally , 5~10 working days is avaliable .
5. How do you solve quality problems?
Please porvide detailed photoes of quality problems. our technical and quality testing department will analyse.we will make a
satisfied soluton within 2 days .
6. What is your payment terms ?
30%T/T in adcance,70% before shipment . West union , L/C are also acceptable .
We are a professional factory with 10 years experience in the field of High and low Voltage switchgears,
Substation,transformers,cable distribution box and various electrical equipment, such as vacuum circuitbreaker , load break switch etc.Our factory is the excellent supplier of State Grid Corporation od China .
2. Do you accept customized serveice ?
We offer OEM/ODM service , can print your logo on product . our professional technical and quotation team can provice a satisfied project according to your drawing and parameters .
3. What is your MOQ?
Our MOQ is 1 piece.
4. How long is your delivery lead time ?
It depends on your product requirement and quantity . Generally , 5~10 working days is avaliable .
5. How do you solve quality problems?
Please porvide detailed photoes of quality problems. our technical and quality testing department will analyse.we will make a
satisfied soluton within 2 days .
6. What is your payment terms ?
30%T/T in adcance,70% before shipment . West union , L/C are also acceptable .
