Подвесная платформа подвесной подъемник фабрика оптовая продажа подвесная zlp630 по отличной
- Категория: Work Platforms >>>
- Поставщик: Henan,Ideal,Machinery,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 4344.94 $* | 4561.3 $* |
| Aug-19-2025 | 4307.52 $* | 4522.61 $* |
| Jul-19-2025 | 3614.15 $* | 3795.59 $* |
| Jun-19-2025 | 4234.79 $* | 4446.66 $* |
| May-19-2025 | 3687.63 $* | 3871.39 $* |
| Apr-19-2025 | 4161.87 $* | 4369.22 $* |
| Mar-19-2025 | 4125.94 $* | 4331.73 $* |
| Feb-19-2025 | 4088.0 $* | 4292.26 $* |
| Jan-19-2025 | 4052.95 $* | 4255.28 $* |
Характеристики
ZLP630 Galvanized Hoist Motor 1.5kw Electrical Scaffolding For Construction Electric Suspended Platform
Suspended Platform Application:
Glass and aluminum or marble curtain wall/Facade Painting and plastering/Facade Installing an insulating layer/Cleaning windows and so on.
Glass and aluminum or marble curtain wall/Facade Painting and plastering/Facade Installing an insulating layer/Cleaning windows and so on.
Products Description
1. Time-saving and cost-saving alternative to tubular scaffolding
2. Unlimited working height
3. Quick and easy to assemble and install
4. Lightweight and easy to transport
2. Unlimited working height
3. Quick and easy to assemble and install
4. Lightweight and easy to transport
Model | zlp630 | zlp800 | |
Appearance | Painting/hot galvanized | ||
Material | Steel/aluminum alloy | ||
Rated load | 630kg | 800kg | |
Lifting speed | 9-11m/min | 8-10m/min | |
Motor power | 2x1.5kw | 2x1.8kw | |
Brake torque | 2x16kN | 2x16kN | |
Steel rope angle adjusting range | 3°-8° | 3°-8° | |
Distance between two steel rope | ≤100m | ≤100m | |
Counterweight(optional) | 25kgx36pcs | 25kgx40pcs | |
Diameter of steel rope | 8.3mm | 9.1mm | |
Max lifting height(m) | 300m | 300m | |
Motor rotation speed | 1420r/min | 1420r/min | |
Voltage(3phases)(optional) | 220v/380v/415v/440v 50hz/60hz to be OEM | ||
Product Overview
Platform Suspension:
The different variants are to be distinguished by their suspension principles. Three different stirrups allow choosing the
platform that best to your requirements (type of work, type of building, maximum loads, number of persons).
End stirrup:
Fitted at the ends of the platform.
Advantages:
The most economical and lightweight version, although showing extraordinary performances. Max length 12m
"Frame" stirrup:
Slipped over the platform like a "frame".
Advantages:
The ends of the platform and therefore the building corners are clear and can be easily accessed, exchangeable with the upper part
of the end stirrup. Max length 16m
"L" stirrup:
Placed at the rear of the platform behind the workers.
Advantages:
The working surface is completely clear and the whole facade can be easily accessed. Max length 16m.
The different variants are to be distinguished by their suspension principles. Three different stirrups allow choosing the
platform that best to your requirements (type of work, type of building, maximum loads, number of persons).
End stirrup:
Fitted at the ends of the platform.
Advantages:
The most economical and lightweight version, although showing extraordinary performances. Max length 12m
"Frame" stirrup:
Slipped over the platform like a "frame".
Advantages:
The ends of the platform and therefore the building corners are clear and can be easily accessed, exchangeable with the upper part
of the end stirrup. Max length 16m
"L" stirrup:
Placed at the rear of the platform behind the workers.
Advantages:
The working surface is completely clear and the whole facade can be easily accessed. Max length 16m.
Company Profile
In 2000, “Ideal machinery” started a small workshop in Changge city, assembling rebar cutting machines and bending machines.through 20 years of development and relied on word-of-mouth advertising, our product involved kinds of the light construction machine.In order to push our machines into the overseas market, the Brand “Ideal machinery” is established in 2015 and started export trading. until now, nearly 10,000 sets of our machines are servicing the overseas construction sites now.
FAQ
Q1. How can we do if there are problems with the products?
A: Our engineers will analyze the problem for you and find the best
solution. If problems happened within the guaranteed time, we can replace the components for you free of charge. We have dealers in some countries, for some technical problems which you can not solve by yourself.
Q2. What is the delivery time for your products?
A: Once we promise the delivery time, we will try our best to fulfill it. Special procedures such as emergency inventory will be used to maintain your uninterrupted supply of the products.
Q3. Is there any guarantee for your products
A: Most of our products have one year guarantee(for the main parts).
Q4. How can you control your product quality?
A: Quality is always considered as the most important part during our manufacturing process. All of our products come under strict quality control system from raw material inspection, component inspecting,semi-finished product inspecting,performance test of finished products,to random inspection before delivery.
A: Our engineers will analyze the problem for you and find the best
solution. If problems happened within the guaranteed time, we can replace the components for you free of charge. We have dealers in some countries, for some technical problems which you can not solve by yourself.
Q2. What is the delivery time for your products?
A: Once we promise the delivery time, we will try our best to fulfill it. Special procedures such as emergency inventory will be used to maintain your uninterrupted supply of the products.
Q3. Is there any guarantee for your products
A: Most of our products have one year guarantee(for the main parts).
Q4. How can you control your product quality?
A: Quality is always considered as the most important part during our manufacturing process. All of our products come under strict quality control system from raw material inspection, component inspecting,semi-finished product inspecting,performance test of finished products,to random inspection before delivery.
