24ft big size fan large commercial fan mexico
Products Description
W.Fans is new large HVLS energry-saving industrial fan based on PMSM (permanent magnet synchronous motor) principle developed by Dawang.With 260N.m torque,the driving force is more stronger and the torque is more stable.Save 30% energy,IE4 high efficiency.The fan diameter from 2.5M to 7.3M,14850m³/min air volume,free maintain for life,no need to change oil and seal. 20-years reliablelife,W.Fans series solves the problem of ventilation and cooling in large spaces with better performance,lower energy consumption and longer life.
1.Comfortable cooling
Simulate 2-3 level natural wind,evaporates the
sweat quickly,the body feels cool down 39-45 F.
sweat quickly,the body feels cool down 39-45 F.
2.15072m³/min super large air volume
26ft large diameter,2400m effective area,
eliminate the muggy,moist,smoke,dust and odor.
eliminate the muggy,moist,smoke,dust and odor.
3.Comprehensive all direction circulation
Accelerate the air circulation,eliminate the
temperature stratification effectively.
temperature stratification effectively.
4.Fewer noise
Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
5.More energy saving
Max 1.2KWH,match to national high efficiency and
energy saving standards.
energy saving standards.
6.More intelligence
APP remote control,
real-time operation monitor,
proactive technical support,
preventive maintenance strategy.
real-time operation monitor,
proactive technical support,
preventive maintenance strategy.
Blade shape- Streamlined variable cross-section
The blade section is from wide to narrow (304-186mm),from thick to thin (43mm-21mm).Adopts the equal chord length principle and relative linear velocity characteristics to ensure the balance pressure of the whole blade to achieve the tip,middle and roots air evenly including the middle.
Blade shape- transverse section,equal width section
The blade length is equal with cross section ,blade width is 19CM.High air resistance is not conducive to pushing airflow, holes in the middle, high energy consumption.
The blade length is equal with cross section ,blade width is 19CM.High air resistance is not conducive to pushing airflow, holes in the middle, high energy consumption.
Blade material- aviation aluminum sheet
Adopt NO.5052H32 1.5mm thickness aviation high grade density aluminum alloy original plate,with high strength and flexibility,bright and durable.
Adopt NO.5052H32 1.5mm thickness aviation high grade density aluminum alloy original plate,with high strength and flexibility,bright and durable.
Blade material-Low grade aluminum
Low grade aluminum mixed with recycled aluminum for secondary processing, low density, impurities, pores, low toughness and easy to break
Low grade aluminum mixed with recycled aluminum for secondary processing, low density, impurities, pores, low toughness and easy to break
Blade weight-light
Each blade 6.7KG,total weight for 5pcs 33.5KG.Smaller blades ,lighter weight, reducing the motor load and extend service life, low energy consumption.
Each blade 6.7KG,total weight for 5pcs 33.5KG.Smaller blades ,lighter weight, reducing the motor load and extend service life, low energy consumption.
Blade weight-heavy
Cross section width equal to the blades, Each blade 10KG,normal 6pcs or 8pcs.Heavy weight, large motor load, high energy consumption.
Cross section width equal to the blades, Each blade 10KG,normal 6pcs or 8pcs.Heavy weight, large motor load, high energy consumption.
Blade and petiole -- full mortise and tenon connection
The convex petiole and concave buffer device are locked with bolts, each blade is riveted with buffer device by 16 rivets,forming the blade, buffer device and petiole as a whole, torque and shear less and less.
The convex petiole and concave buffer device are locked with bolts, each blade is riveted with buffer device by 16 rivets,forming the blade, buffer device and petiole as a whole, torque and shear less and less.
Blade weight-heavy
Cross section width equal to the blades, Each blade 10KG,normal 6pcs or 8pcs.Heavy weight, large motor load, high energy consumption.
Cross section width equal to the blades, Each blade 10KG,normal 6pcs or 8pcs.Heavy weight, large motor load, high energy consumption.
Buffer device-Rubber mat
The rubber pad between mounting hole of buffer device and shaped inserts to achieve the flexible connection between petiole and chassis.Rubber mat absorb the most of vibration, improve the motor shaft work conditions, extend the life, more quieter
The rubber pad between mounting hole of buffer device and shaped inserts to achieve the flexible connection between petiole and chassis.Rubber mat absorb the most of vibration, improve the motor shaft work conditions, extend the life, more quieter
Buffer device-No
Vibration cannot be weakened, resulting petiole and blades loosen,heavy loading, high noise.
Vibration cannot be weakened, resulting petiole and blades loosen,heavy loading, high noise.
Wheel chassis-Integrated hub
Special-shaped mounting hole and inserts locked each other to prevent the blade from swinging
Special-shaped mounting hole and inserts locked each other to prevent the blade from swinging
Wheel chassis structure-die cast
Gravity die-casting aluminum wheel chassis or separated wheel hub, low strength, poor fatigue resistance.
Gravity die-casting aluminum wheel chassis or separated wheel hub, low strength, poor fatigue resistance.
Specification
Item | W.Fans | W.Fans | ||||||||||||||||
Models | 26ft | 24ft | 22ft | 20ft | 18ft | 16ft | 14ft | 12ft | 10ft | |||||||||
Diameter（m) | 8 | 7.3 | 6.7 | 6.1 | 5.5 | 4.9 | 4.2 | 3.6 | 3.1 | |||||||||
Speed（rpm) | 0-50 | 0-55 | 0-60 | 0-65 | 0-70 | 0-75 | 0-80 | 0-90 | 0-100 | |||||||||
Air Volume（m³/min) | 15072 | 13804 | 11630 | 9639 | 7836 | 6220 | 4570 | 3357 | 2263 | |||||||||
Coverage（m²) | 2462 | 2123 | 1809 | 1520 | 1256 | 1017 | 804 | 615 | 452 | |||||||||
Consumption（kw/h) | ≤1.2 | ≤1.0 | 22m | ≤0.8 | ≤0.6 | |||||||||||||
Weight（kg) | 108 | 92 | 90 | 73 | 63 | 60 | 57 | 42 | 39 | |||||||||
Noise（dB) | ≤38 | |||||||||||||||||
Blade Nos(pcs) | 5 | |||||||||||||||||
Rated power（kw) | 1.5 | 1.1 | 0.7 | |||||||||||||||
Full Load Current（A) | 3.2 | 5.2 | 3.5 | |||||||||||||||
Power supply（V) | 380 | 220 | ||||||||||||||||
Custom is available | Custom is available | |||||||||||||||||
Packing & Delivery
Model | Items | Pkg/Unit | Dimension(l*w*h) | Volume/Unit | Gross Weight/unit |
W.FANS | 24ft(7.3m) | 2 Carton boxes | Motor carton:920*520*520mm Blade carton:3400*230*320mm | 0.5m³ | 146Kg |
22ft(6.7m) | Motor carton:920*520*520mm Blade carton:3020*230*320mm | 0.47m³ | 143Kg | ||
20ft(6.1m) | 140Kg | ||||
18ft(5.5m) | 137Kg | ||||
16ft(4.9m) | 134Kg | ||||
12ft(3.6m) | 130Kg | ||||
10ft(3.1m) | 127Kg | ||||
08ft(2.5m) | 125Kg |
