Цена:3 500,00 $ - 5 500,00 $*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-15-2025 4165.92 $* 4373.19 $*
Aug-15-2025 4130.1 $* 4337.84 $*
Jul-15-2025 3465.15 $* 3638.6 $*
Jun-15-2025 4060.81 $* 4263.89 $*
May-15-2025 3535.39 $* 3712.70 $*
Apr-15-2025 3990.16 $* 4190.15 $*
Mar-15-2025 3955.77 $* 4153.3 $*
Feb-15-2025 3920.88 $* 4116.72 $*
Jan-15-2025 3885.69 $* 4079.75 $*

Характеристики



Products Description


Scope of application
Hammer crusher is a one-stage crusher that directly crushes materials with a particle size of 600-1800 mm to below 25 or 25 mm. Hammer crusher is suitable for crushing medium hardness materials, such as limestone, slag, coke, coal and other materials in the cement,
chemical, electric power, metallurgy and other industrial sectors for medium and fine crushing operations.




Technical Parameter


Model No.
Max Feeding Size
(mm)
Output Size
(mm)
Capacity
(t/h)
Motor Power
（KW）
Weight
(t)
Overall Diemension
(mm)
PC400×300
≤200
≤25
8-16
11
0.8
900*670*860
PC600×400
≤250
≤30
16-35
22
2.26
1200*1050*1200
PC800×600
≤250
≤35
26-64
55
4.8
1310*1180*1310
PC1000×800
≤350
≤35
40-80
75
5.9
1600*1390*1575
PC1000×1000
≤350
≤35
48-88
90
8
1800*1590*1775
PC1250×1250
≤350
≤35
56-104
132
14
2060*1600*1890
PC1400×1400
≤350
≤35
80-160
280
32
2365*1870*2220
PC1600×1600
≤350
≤35
160-240
480
37.5
3050*2850*2800




Applications
widely used in industrial sectors such as cement, chemical industry, electric power, and metallurgy.


Applicable materials
The hammer crusher is suitable for crushing medium hardness materials such as limestone, slag, coke, coal and other materials in medium and fine crushing operations in cement, chemical, electric power, metallurgy and other industrial sectors.


Working Principle
The hammer crusher is mainly composed of housing, rotor, bearing iron and grate, etc. The housing is divided into two parts: upper and lower parts, which are cut and welded by steel plates, and the rest parts are bolted together. The casing is equipped with high manganese steel lining plates, which can be replaced after wear. The main shaft of the hammer crusher is equipped with several groups of regularly distributed hammers, which form the rotor with the turntable and the hammer piercing shaft.

The rotor is rotated by the motor and v-belt, and the hammers are stretched out in all directions by the centrifugal force generated during the rotation, and the large pieces of material are crushed by the hammers moving at high speed after entering the crushing chamber through the feed opening. The crushed material is discharged by the castor bar with a gap in the lower part, while the unqualified material is left in the crushing cavity and is repeatedly acted upon by the hammers and the iron block until it can be discharged.




Product Structure




Product Advantages
1. The crushing ratio is large, the production efficiency is high, and the applicability is strong. The required particle size can be adjusted according to customer requirements.
2. There is no screen grate bottom, there is no requirement for the moisture content of the material, there is no problem of sticking and blocking the sieve plate, and there is no problem that the material cannot be discharged in time and repeatedly crushed; the structure seal of the hammer is broken, which solves the dust pollution in the crushing workshop. and body leakage problems.
3. The overall design has the advantages of beautiful appearance, compact structure, few wearing parts, and convenient maintenance. It is an upgraded product.
4. The bearing box is all made of cast steel and fixed with four screws, which is scientific and practical; the working hammer head is cast by new technology, which is wear-resistant and impact-resistant.


Production Line








If you need our products, please contact us, this is my WhatsApp. Or you can directly click the blue font below to send an inquiry, we will help you make more money.
WhatsApp：+8617739786040
E-mail：betty@hanfagroup.com
Click here to contact us!!!


Company Introduction






FAQ


1. Are you a trading company or a manufacturer?
We are a professional manufacturer. Our factory mainly produces water well drilling rigs, core drilling rigs, down-the-hole drilling rigs, pile drivers, etc. The products have been exported to hundreds of countries around the world and enjoy a high reputation all over the world.

2. How is the quality of your machine?
Our products pass strict quality inspections before they leave the factory to ensure that they are qualified before they are shipped.

3. How to inspect the goods?
1) Support customers to come to the factory for on-site inspection.
2) Support customers to designate third-party companies to inspect goods.
3) Support video inspection.

4. Do you have after-sales service?
Yes, we have a dedicated service team that will provide you with professional technical guidance. If you need, we can send our engineers to your workplace and provide training for your employees.

5. How about quality assurance?
We provide a one-year quality guarantee for the main machine of the machine.

6. How long is your delivery cycle?
1) In the case of stock, we can deliver the machine within 7 days.
2) Under standard production, we can deliver the machine within 15-20 days.
3) In the case of customization, we can deliver the machine within 20-25 days.
