Хорошее качество плата цифрового усилителя мощности Плата BT Mono 150
- Категория: Receivers & Amplifiers >>>
- Поставщик: Guangzhou,Teampie,Electronics,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-17-2025 | 57.33 $* | 58.88 $* |
| Jul-17-2025 | 46.64 $* | 47.17 $* |
| Jun-17-2025 | 56.12 $* | 57.26 $* |
| May-17-2025 | 56.98 $* | 57.42 $* |
| Apr-17-2025 | 45.42 $* | 46.89 $* |
| Mar-17-2025 | 55.55 $* | 56.64 $* |
| Feb-17-2025 | 54.3 $* | 55.14 $* |
| Jan-17-2025 | 54.28 $* | 55.56 $* |
Характеристики
Products Description
PRODUCT SPECIFICATIONS | ||
Product Name | Trolley Speaker Amplifier Board | |
Model No. | YD-180AB.PCB+YD-PA10TY.PCB | |
Operating Voltage | AC 220-240V | |
External DC Input | DC 12V | |
Power Output | 150W * 1CH | |
Impedance | 4 OHMS | |
SNR | ≥85dB | |
Distortion | ≤0.5% | |
Functions | USB/MICRO SD/BT/AUX /FM/RECORD/REMOTE/DISPLAY | |
Features | Mic Piority/Volume/ Bass/Treble/Mic Bass/Mic Treble/Mic Echo/Mic Delay/Reverb/Guitar Volume/Vocal Fader | |
File System | FAT32 | |
Support Format | MP2/MP3/ WMA/ APE/FLAC/AAC/ MP4/ M4A/ WAV（IMAADPCM & PCM/AIF/AIFC | |
Fimrware Upgrade | Yes | |
Solution | MV SILICON BP1048+ CHINA MADE TRANSISTOR 5198/1941 | |
Size | L380*W190MM | |
Company Profile
Our Advantages
Product packaging
Transportation
Customers' Feedback
FAQ
1. Q：Are you a manufacturer/factory?
A： Yes, we are. We design and produce the audio modules.
2. Q：Do you test the products before shipment?
A:Yes, we 100% test them, even each button of the remote control.
3.Q： Does your factory provide OEM or ODM service?
A：Yes, we offer both, we have developed many exclusive designs for some big brands.
4.Q： Can you make custom LCD logo & BT name?
A：Yes, we can design your logo on the LCD and the BT name as well.
5.Q： How long is the warranty period of the modules?
A：We provide 1 year’s warranty.
A： Yes, we are. We design and produce the audio modules.
2. Q：Do you test the products before shipment?
A:Yes, we 100% test them, even each button of the remote control.
3.Q： Does your factory provide OEM or ODM service?
A：Yes, we offer both, we have developed many exclusive designs for some big brands.
4.Q： Can you make custom LCD logo & BT name?
A：Yes, we can design your logo on the LCD and the BT name as well.
5.Q： How long is the warranty period of the modules?
A：We provide 1 year’s warranty.
Product Names
Trolley Speaker board , Portable Speaker Module , Music Party Box Module , Active Subwoofer Board
