Performance of Tile Backer Board
|
Item
|
Standard
|
Result
|
Thermal Conductivity
|
EN 12667:2001
|
0.033 Watt/m.k
|
Compressive Strength (10% deflection)
|
EN 826:1996
|
Minimum of 0.35N/mm2
|
Bond Strength
|
BS EN 1384
|
0.4N/mm2
|
Maximum Tile Loading Weight
|
CERAM121107
|
62kg/m2
|
Flexural Strength
|
ASTM C203
|
2.05 ± 0.02 MPa
|
Long term water absorption
|
EN12087
|
0.11kg/m2
|
Water Vapour Permeability (Sd)
|
DIN EN 12086
|
3.2m
|
Resistance to body Impact
|
ETAG 003
|
3 x 120N/m
|
Bending Stiffness, E( 12 mm )
|
EN 12089
|
420 KNmm2
|
Coefficient of linear expansion
|
N/A
|
30 x 10-6 K-1
|
Flammability
|
EN 13501-1
|
Class E
|
Impact Sound Reduction
|
BS-ISO140-8
|
dLw = 21
|
Shear Bond Strength
|
EN 1448
|
3.32kg/cm2
|
EU controlled substances content
|
N/A
|
none
|
