Считыватель карт Android автобусная система контроля доступа платежный терминал/Android bus nfc

1. Made of ABS, Fully adapt to special circumstances on bus

2. Sealed, dustproof, waterproof, shockproof and anti-electromagnetic interference

3. Dedicated stable power supply, voltage overload protection
4. With the most advanced Linux system, high-definition LCD display

5. WIFI Communication + USB data acquisition, support remote upgrading

6. Contactless smart card, read/write capability, light display for reading card 7. Live voice prompts, supports 15 kinds of voice prompts: such as "student card", "employee card";

8. Support Mifare1 card, CPU card
9. With Thermal printing module, can connect to POS58 slip printer

10. Optional GPS positioning module, for global positioning satellite positioning;

 11. Great stability of data storage, data kept as long as 10 years even with power outage
12. Card Capacity: 91,880,000 pcs;
13. Can check the nearest 20 records, to prevent ticket payment dispute.
14. Certification: ISO9001, CCC, CE, IP65

Android card reader bus access control system payment terminal/Android bus nfc terminal POS

Model:CL0618 bus terminal
Dimension:240*140*47.7mm
Material:Engineering Plastics, Anti static electricity coating design, be protected from high-frequency
interference
Display:5 inch LCD display
Operating system:Linux or Android
Working Voltage:DC 8V-50V
Operating temperature:-25℃~65℃
Storage temperature:-40℃~85℃
Humidity:0-95% RH non condensing
RFID:Can read and write ISO14443 TYPE A\\B Electronic tag (Incl. Combi-Card )

Read card distance:0~50mm
Supporting card:Mifare 1 card, Mifare DESfiire card,CPU card, UnionPay IC card
Frequency:13.56MHz
Interfaces/Connectors:RS232, RS485, USB
Positioning mode:GPS
Power consumption:≤10W
Communication Modules:4G
WIFI:Supporting 802.11n/b/g standards,150Mbps,2.4Ghz
UnionPay:Compatible for PBOC3.0 UnionPay card
Lighting:Red, Green light

Sound prompt:Buzzer, single channel speaker (voice report)
Voice report prompt:16KHz,16bit single channel voice report prompt

Hardware

We are not only provided the system ,but also provided the pos machine.

Software

In order to provide good service ,we also provide customers the management system.

High quality

Passed the ISO9001:2008 quality system authentication and CE authentication.

Company

Workshop

Our Workshop

Testing

Our Testing room

Showroom

Our Showroom

A: We can sell them together ,but you also can only buy machine or system.

A: We'll provide you the whole set instruction book of machine and the system,you can do as the instruction .We also can send engineers to your country to setup the machine and system for you.

A: Yes, we could offer the sample for you inspection.

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
