Высококачественный коаксиальный кабель

Высококачественный коаксиальный кабель

Категория: >>>
Поставщик: GUANGXI,LIFETIME,CABLE,CO.,LTD

Цена:0,10 $ - 0,17 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-16-2025	0.15 $*	0.2 $*
Aug-16-2025	0.21 $*	0.14 $*
Jul-16-2025	0.42 $*	0.70 $*
Jun-16-2025	0.48 $*	0.50 $*
May-16-2025	0.30 $*	0.28 $*
Apr-16-2025	0.75 $*	0.16 $*
Mar-16-2025	0.89 $*	0.41 $*
Feb-16-2025	0.69 $*	0.90 $*
Jan-16-2025	0.42 $*	0.88 $*

Характеристики

Product Paramenters

1.Product model, name, standard and use

Product model	name	Standard	use
SYV	Solid core PE insulated RF cable	GB/T14864-2013	Suitable for transmission of radio frequency signals in radio communication, broadcasting equipment and related radio electronic equipment.
SYKV	Longitudinal hole polyethylene insulated RF cable	SJ/T10302-92	Suitable for transmission of RF signals in common antenna systems, closed circuit television systems and other electronic equipment.
SYWV	Physical foamed polyethylene insulated RF cable	GY/T135-1998	Suitable for closed-circuit TV system, common antenna TV system, cable TV system as trunk line, branch line and other electronic devices with physical foamed polyethylene insulation coaxial cable.

2.operating characteristic
Operating temperature: -25 ~ 70℃
Installation and laying temperature: not less than -15℃
Minimum bending radius:
SYV type: indoor 5D, outdoor 10D, D-cable od.
SYKV, SYWV: indoor 10D, outdoor 20D, D-cable diameter.

3.SYWV (PVC sheath) or SYWY (PE sheath) construction dimensions

model	Requirement	conductor diameter mm	Insulation diameter mm	sheath mm
model	Requirement	conductor diameter mm	Insulation diameter mm				thickness	diameter
SYWV-75-5	min	0.98	4.60	0.69	6.9
		nominal	1.00	4.80	0.88	7.2
		max	1.02	5.00		7.5
SYWV-75-7 SYWY-75-7	min	1.64	7.00	0.85	10.0
		nominal	1.66	7.25	1.05	10.3
		max	1.68	7.50		10.6
SYWV-75-9 SYWY-75-9	min	2.12	8.75	0.90	12.0
		nominal	2.15	9.00	1.15	12.3
		max	2.18	9.25		12.6
