HPE-POWER интеллигентая (ый) Длинная дуга УФ eps/ПСВ (Инвертор Балласт для отверждения
- Категория: Other Power Supplies >>>
- Поставщик: Xiamen,Powertron,Electric,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.91 $* | 0.55 $* |
| Aug-16-2025 | 0.25 $* | 0.92 $* |
| Jul-16-2025 | 0.57 $* | 0.54 $* |
| Jun-16-2025 | 0.38 $* | 0.61 $* |
| May-16-2025 | 0.11 $* | 0.84 $* |
| Apr-16-2025 | 0.36 $* | 0.79 $* |
| Mar-16-2025 | 0.23 $* | 0.57 $* |
| Feb-16-2025 | 0.88 $* | 0.38 $* |
| Jan-16-2025 | 0.39 $* | 0.66 $* |
Характеристики
Products Description
Input Section | ||
Main Input Voltage | 360~440Vac | |
Frequency | >47Hz | |
COS∅ | 1 | |
Power Factor | 0.96 | |
THD （current） | 30% | |
Efficiency | Typ.>94% | |
Output Section | ||
Working Frequency | Variable from 6Khz to 16Khz | |
Ignition Voltage | >4000Vpp | |
Ignition Frequency | 270Khz | |
Max. Output Power | 22Kw(40℃ ambient Temp) | |
Output Voltage | Up to 2500Vac | |
Output Current | Up to 20A | |
Control Port | MODBUS/Analog and Digital I/O | |
Lamp Monitoring | Voltage/current/power/status/error code | |
Protections | Input under/over Voltage； Phase Loss Output Open/Short Output Over voltage Over Temperature Ground&Leakage Fault | |
Auxiliary Section | ||
Voltage | 21Vdc-30Vdc | |
Current | 1.5Adc | |
Working Environment | ||
Max. ambient Temperature | 40℃(up to 1000meters Sea Level) | |
Max. Humidity | <80% | |
Protection Class | IP20 | |
Cooling | Forced Air Cooling | |
Dimension (LWH)mm | 675*160*363 | |
Weight | 31Kg | |
Recommend Products
Product Categories
Company Profile
Product packaging
FAQ
Q1. Can all the products be customized?
A: We are the factory of making UV lamp,UV accessories,UV curing system and IR lamps. All the our products can be made by the details you provide.
Q2. What is the outer package of the product?
A: We use very strong export-specific carton packaging and wooden box packaging to ensure that the goods can be safely delivered to customers.
Q3. Processing cycle?
A: Some of products we have in stock.
IR lamps and UV lamps usually need about 5-30 days to make.
If you need urgently,we will make the UV lamp as soon as our possible.
UV curing system need about 14-28days to prepare.
UV accessories need about 1-7 days to prepare.
IR lamps and UV lamps usually need about 5-30 days to make.
If you need urgently,we will make the UV lamp as soon as our possible.
UV curing system need about 14-28days to prepare.
UV accessories need about 1-7 days to prepare.
Q4. Minimum Order quantity?
A: Customized UV lamps and IR lamps usually is 3-5 pieces for your testing first.Other products MOQ is 1 set/unit.
Q5: Do you accept OEM?
A: Yes.
Q6: Can we be your distributor?
A: Yes, if your annuals sales much more than our other customers in your market that you can be our distributor. Over rich OEM experience, we can provide professional solutions for customers.
