DZ41 500C SW102 Bafang BBS01 BBS02 M500 M600 дисплей
US $25.00-$45.00
Контроллер бесщеточного электродвигателя постоянного тока для электрического велосипеда 36 В/48 в 350 Вт аксессуары электровелосипеда
- Категория: Other Electric Bicycle Parts >>>
- Поставщик: Honghui,(shenzhen),Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-16-2025 | 547.92 $* | 558.35 $* |
| Jul-16-2025 | 444.8 $* | 453.58 $* |
| Jun-16-2025 | 539.62 $* | 550.60 $* |
| May-16-2025 | 534.52 $* | 545.80 $* |
| Apr-16-2025 | 427.80 $* | 436.17 $* |
| Mar-16-2025 | 526.4 $* | 537.23 $* |
| Feb-16-2025 | 522.26 $* | 532.2 $* |
| Jan-16-2025 | 517.2 $* | 527.34 $* |
Характеристики
Product description
product name | 36V-48V 350W controller can work with hall sensor/hall sensorless | ||||||
Rated Voltage | 36V/48V | ||||||
Low Voltage | 31V/42V±0.5V | ||||||
Rated Power | 350W | ||||||
Limit Current | 17A | ||||||
Color | Silver | ||||||
1.pointer meter line
2. motor line
3.3-speed line
4.Anti-theft alarm line
5.self-learning line
6.hall line
7.throttle line
8.low brake
9.Anti-theft power line
10.Cruise speed line
11.battery（2 red wires battery +，black battery -）
12.high brake
一.connect the motor line (color to color）
二. connect the battery line(2 red wires :battery + , black:battery-)
三. connect the controller throttle line（color to color）
四. connect the hall line(if motor without hall line, don’t need connect)
五.docking the two self-learning lines, the wheel will forward or reverse.
(1.if wheel forward ,Separate the self-learning line.
2.if wheel reverse, Separate the self-learning line. Docking the self-learning line again，if wheel forward ,Separate the
self-learning line.)
六.other functions can be connected as needed.
2. motor line
3.3-speed line
4.Anti-theft alarm line
5.self-learning line
6.hall line
7.throttle line
8.low brake
9.Anti-theft power line
10.Cruise speed line
11.battery（2 red wires battery +，black battery -）
12.high brake
一.connect the motor line (color to color）
二. connect the battery line(2 red wires :battery + , black:battery-)
三. connect the controller throttle line（color to color）
四. connect the hall line(if motor without hall line, don’t need connect)
五.docking the two self-learning lines, the wheel will forward or reverse.
(1.if wheel forward ,Separate the self-learning line.
2.if wheel reverse, Separate the self-learning line. Docking the self-learning line again，if wheel forward ,Separate the
self-learning line.)
六.other functions can be connected as needed.
