Baofeng UV5R Handheld Radio Communication VHF 136-174MHz UHF 400-520MHz Handheld Walkie Talkie hf Transceiver in Moscow

Orders from UK. Canada can be shipped from those oversea warehouse, please chose shipping from China, then we will help you ship from oversea to shorten shipping time



Frequency range                                            65-108Mhz(only for FM)

                                                                          VHF:136-174Mhz(Rx/Tx) UHF:400-520(Rx/Tx)

Memory channels                                           Up to 128 channels

Frequency stability                                          2.5ppm

 Frequency step                                               2.5kHz/5kHz/6.25kHz/10kHz/12.5kHz/25kHz

Antenna impedance                                        50Ω

Operating temperature                                   -4οF to +140οF

 Supply voltage                                                  Rechargeable Lithium-Ion mAh7.4V/1800

Consumption in standby                                ≤75mA

Consumption in reception                              380mA

Consumption in transmission                       ≤1.4A

Mode of operation                                             Simplex or semi-duplex

Duty cycle                                                            03/03/54 min.(Rx/Tx/Standby)

Dimensions                                                       58mm*110mm*32mm

Weight                                                                 130g(approximate)

TRANSMITTER

RF power                                                            4W/1W

Type of modulation                                            FM

Emission class                                                 16KΦF3E/11KΦF3E(W/N)

Maximum deviation                                            ≤±5kHz/≤±2.5kHz(W/N)

Spurious emissions                                          <-60dB

RECEIVER

Receiver sensitivity                                              0.2μV(at 12dB SINAD)

Intermodulation                                                    60dB

Audio output                                                         1000mW

Adjacent channel selectivity                               65/60dB

Specification

Dual-band handheld transceiver with display function menu on the display “LED”

Commercial FM radio receiver (65MHz-108MHz)

Built-in LED flashlight

DTMF encoded

Built-in RX CTCSS/DCS scan

Function VOX

Alarm function

Broadband/narrowband selectable

Function beep on the keyboard

Dual Watch/dual Reception

Crossband reception/transmission

Function OFFSET

Tone end of transmission

Battery saving function SAVE

Programmable by PC

Built-in key lock

Package Units

1 x UV-5R (VHF136-174 & UHF 400-520Mhz)
1 x 7.4V 1800mah Li-ion Battery Pack

1 x dual band Antenna
1X ear hook earphone
1 x English and Russsian Manual
1 x Desktop Charger ( 100V ~ 240V  US/EU/UK/AU plug )



PS. Car charger, Air tube headset, Na771 antenna and Programming cable is optional
