Недорогой грузовик для очистки сточных вод с вакуумным резервуаром объемом 12000 л и насосом 12 куб. М туалетный септический
- Категория: Sewage Suction Trucks >>>
- Поставщик: Hubei,Runli,Special,Automobile,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 37842.25 $* | 39734.69 $* |
| Aug-16-2025 | 37524.61 $* | 39400.85 $* |
| Jul-16-2025 | 31482.36 $* | 33056.30 $* |
| Jun-16-2025 | 36888.36 $* | 38732.33 $* |
| May-16-2025 | 32118.58 $* | 33724.46 $* |
| Apr-16-2025 | 36252.23 $* | 38065.43 $* |
| Mar-16-2025 | 35934.70 $* | 37731.82 $* |
| Feb-16-2025 | 35616.35 $* | 37397.50 $* |
| Jan-16-2025 | 35298.48 $* | 37063.27 $* |
Характеристики
Waster Water Treatment Truck with 12000L Vacuum Sewage Tank and Pump 12cbm Toilet septic Transport Vehicle Call Ms.Pinky Whastapp: 0086 15897603919
1. combination vacuum truck include power take off, transmission, vacuum suction fecal pump, water separator, oil and gas separator, multi-way valve, suspender, fecal tank, discharge valve, water tank, fecal level indicator, vacuum pressure meter, pipe system and so on.
2. combination vacuum truck , Self-discharge and self-suction.
3. The Truck Mounted Vacuum Cleaner Sewage Body can Self Dumper;
4. Fill tank all time ≤10min, long service life, and high working speed, convenient transportation.
5. Suitable for collecting and transport manure, biogas slurry, mud, oil and other liquid goods.
2. combination vacuum truck , Self-discharge and self-suction.
3. The Truck Mounted Vacuum Cleaner Sewage Body can Self Dumper;
4. Fill tank all time ≤10min, long service life, and high working speed, convenient transportation.
5. Suitable for collecting and transport manure, biogas slurry, mud, oil and other liquid goods.
Waster Water Treatment Truck with 12000L Vacuum Sewage Tank and Pump 12cbm Toilet septic Transport Vehicle
Chassis model: DONGFENG
Color: White body and blue cabin optional
Drive type: LHD
Cabin: with A/C
Engine Model:B210-33
Engine power: 2100HP
Displacement:5900CC
Wheelbase: 4350+1300mm
Tyre:10.00-20
Capacity of tank body:12-15000Liters
With Two Vacuum Pump
Color: White body and blue cabin optional
Drive type: LHD
Cabin: with A/C
Engine Model:B210-33
Engine power: 2100HP
Displacement:5900CC
Wheelbase: 4350+1300mm
Tyre:10.00-20
Capacity of tank body:12-15000Liters
With Two Vacuum Pump
The Specification of Waster Water Treatment Truck with 12000L Vacuum Sewage Tank and Pump 12cbm Toilet septic Transport Vehicle
Products Technical Specification | ||||
Type | Suction truck | |||
Brand | Dongfeng 6*4 | |||
Cab | With A/C, on bed | |||
Vehicle Description | ||||
Overall dimensions（mm） | 9300×2500×3700 | |||
Curb weight(vehicle) (kg) | 12400 | |||
Loading capacity (kg) | 13000 | |||
Max speed (Km/h) | 95 | |||
Engine | ||||
Mode | B210-33 | |||
Type | Diesel, 6-cylinder in line with water cooling, turbo-charging | |||
Max. power/rotated speed | 155(KW) /2500(rpm) | |||
Max. torque | 700（N.m） /1400～1600(rpm) | |||
Cylinder bore×Stroke(mm) | 102×120 | |||
Displacement(ML) | 5900 | |||
Company of engine | Dongfeng Cummins | |||
Compression ratio | 17.3:1 | |||
Emission level | Euro 3 EGR | |||
Chassis Description | ||||
Wheel base | 4300+1350 | |||
Front axle | Elliot I-beam type 5T | |||
Rear axle | Driving axle, press-welding axle housing, single hypoid gear reduction final axle, full-floating axle shaft 10T×2 | |||
Number of leaf spring of suspension | 8/13 | |||
Front overhang / rear overhang | 1460/1990 | |||
Front tread / rear tread | 1940/1860 | |||
Approach angle /Departure angle | 30/16 | |||
Gear box | 8-speed with over drive | |||
Brake system | Air braking | |||
Operation control system | Power Steering | |||
Electric system | 24V | |||
Tyres | 10.00-20 | |||
Sewage tanker | ||||
Volume of tank | 12-15m3 | |||
Thickness of tank | 6mm | |||
horizontally mounted tank with domed ends, internal welded surge baffles, full tank length sub frame with side walks, Access Ladder top inspection cover, Sub frame integral with tank and dismountable from Chassis. Lockable quick release locking mechanism on inspection cover. Durable internal corrosion protection, Fabricated from 5mm Medium Carbon Steel Plate welded from inside and outside, Lifting eyes on top of tank for handling. Quick Opening 100mm intake and purge valve, Float ball ( Full tank) shut off valve to stop entry of liquid into pump suction. sight glass at front domed and indicating max liquid level. Tank Air tight and pressure tested to 1.5 bar and vacuum tested to 20 Hg vacuum. Equiped with two vacuum pump ( ratiing rotate speed=1400r/m; min rotae speed>800r/m; Max.suction lift>6m; vacuum >500mm Hg.clockwise. Equiped with power take off, transmission shaft, fecal tank, pipe network, fecal pipe for observing and cleanout equipment. Time for full suction < 5min; | ||||
Detail Equipment of Waster Water Treatment Truck with 12000L Vacuum Sewage Tank and Pump 12cbm Toilet septic Transport Vehicle:
Dongfeng Sewage Suction Truck:
Combi Vacuum Jetting Truck , Vacuum Sewage Suction Truck , Equipped with vacuum pump(rating rotate speed=1400r/m,min rotate speed≥800r/m, max suction lift ≥6m, vacuum 500mmHg, clockwise)
Equipped withpower take off, transmission shaft, fecal tank, pipe network, fecal pipe for observing and cleanout equipment Time for full suction<5min
Sewage Suction Truck, Vacuum Sewage Suction Truck Equipment is designed to collect, by suction, and transport the . Cesspit emptier consists of a subframe connected to the vehicle's chassis. A cylindirical tank, a hydraulically openning full diameter tailgate and the vacuum system powered by the PTO mounted to the gearbox of the vehicle. All the functions and the load distribution of the equipment are properly arranged to the technical specifications of the chassis on which it is mounted.
Equipped withpower take off, transmission shaft, fecal tank, pipe network, fecal pipe for observing and cleanout equipment Time for full suction<5min
Sewage Suction Truck, Vacuum Sewage Suction Truck Equipment is designed to collect, by suction, and transport the . Cesspit emptier consists of a subframe connected to the vehicle's chassis. A cylindirical tank, a hydraulically openning full diameter tailgate and the vacuum system powered by the PTO mounted to the gearbox of the vehicle. All the functions and the load distribution of the equipment are properly arranged to the technical specifications of the chassis on which it is mounted.
Company Profile
Hubei Runli Special Automobile Co., Ltd. is located in Suizhou City, which is China special automobile industry city. Our company
covers an area of more than 166,000 square meters. We focus on the production of special automobile with export rights authorized
by the Ministry of Information Industry and Ministry of Commerce. Our company is licensed as the first tanker pressure
manufacturer by AQSIQ and is the only private enterprise which gets military quality system certification. Our company is also the
"100 key Enterprises in Hubei Province" and "Hubei Province Two Safety Standards Enterprise".
Hubei Runli Special Automobile Co., Ltd. is a special automobile corporation which integrates research, manufacture, and service
in one. Our company has 300 types of special vehicles in more than ten series including tank trucks, fire trucks, mobile machinery
shops, sprinklers, semi-trailers, pressure vessels, and more.
Our Client:
Our company's products have been exported to different countries and regions, including Central America: the Republic of Costa
Rica, Panama Republic, Trinidad and DOPA Republic.
South America: the Republic of Columbia, the Republic of Venezuela, the Republic of Ecuador, Peru, the Republic of Bolivia, Chile,
the Republic of Paraguay.
Africa: Ethiopia, Angola, Botswana, Burundi, Equatorial Guinea, Togo, Gambia, Republic of the Congo, Djibouti, Guinea, Ghana,
Gabon, Zimbabwe, Cameroon, Equatorial Guinea, Kenya and Liberia, Rwanda, Madagascar, Mali, Mozambique, Namibia, Nigeria, Sierra
Leone, Somalia, Tanzania, Uganda and Zambia.
Asia: the United Arab Emirates, Philippines, Cambodia, Qatar, Kyrgyzstan, Mongolia, old tart, Turkmenistan, Kazakhstan,
Tajikistan, Georgia, Uzbekistan, Afghanistan, Vietnam, Myanmar, Bangladesh. Papua: Oceania New Guinea, Fiji, Kiribati, Nauru,
etc..
covers an area of more than 166,000 square meters. We focus on the production of special automobile with export rights authorized
by the Ministry of Information Industry and Ministry of Commerce. Our company is licensed as the first tanker pressure
manufacturer by AQSIQ and is the only private enterprise which gets military quality system certification. Our company is also the
"100 key Enterprises in Hubei Province" and "Hubei Province Two Safety Standards Enterprise".
Hubei Runli Special Automobile Co., Ltd. is a special automobile corporation which integrates research, manufacture, and service
in one. Our company has 300 types of special vehicles in more than ten series including tank trucks, fire trucks, mobile machinery
shops, sprinklers, semi-trailers, pressure vessels, and more.
Our Client:
Our company's products have been exported to different countries and regions, including Central America: the Republic of Costa
Rica, Panama Republic, Trinidad and DOPA Republic.
South America: the Republic of Columbia, the Republic of Venezuela, the Republic of Ecuador, Peru, the Republic of Bolivia, Chile,
the Republic of Paraguay.
Africa: Ethiopia, Angola, Botswana, Burundi, Equatorial Guinea, Togo, Gambia, Republic of the Congo, Djibouti, Guinea, Ghana,
Gabon, Zimbabwe, Cameroon, Equatorial Guinea, Kenya and Liberia, Rwanda, Madagascar, Mali, Mozambique, Namibia, Nigeria, Sierra
Leone, Somalia, Tanzania, Uganda and Zambia.
Asia: the United Arab Emirates, Philippines, Cambodia, Qatar, Kyrgyzstan, Mongolia, old tart, Turkmenistan, Kazakhstan,
Tajikistan, Georgia, Uzbekistan, Afghanistan, Vietnam, Myanmar, Bangladesh. Papua: Oceania New Guinea, Fiji, Kiribati, Nauru,
etc..
Factory Room and equipment
professional workshop and worker for different tank truck at Hubei Runli Factory
Contact Information
More specs , photos, price, delivery time and other need,
please contact with Ms Pinky. Hotline(Whastapp): 0086 15897603919
TEL:0086 200 3308196
you also can contact with me by Skype ID, Whatsapp, Mail as the following information:
please contact with Ms Pinky. Hotline(Whastapp): 0086 15897603919
TEL:0086 200 3308196
you also can contact with me by Skype ID, Whatsapp, Mail as the following information:
