GTRIC Малый матричный волоконно-оптический фотоэлектрический датчик промышленного типа поперечный волоконно-лучевой усилитель
- Категория: Sensors >>>
- Поставщик: Wenzhou,Gtric,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.31 $* | 0.70 $* |
| Aug-16-2025 | 0.22 $* | 0.11 $* |
| Jul-16-2025 | 0.2 $* | 0.21 $* |
| Jun-16-2025 | 0.50 $* | 0.96 $* |
| May-16-2025 | 0.96 $* | 0.68 $* |
| Apr-16-2025 | 0.83 $* | 0.12 $* |
| Mar-16-2025 | 0.95 $* | 0.32 $* |
| Feb-16-2025 | 0.73 $* | 0.36 $* |
| Jan-16-2025 | 0.15 $* | 0.15 $* |
Характеристики
Specifications | ||||||||
Model | DN10 | DP10 | NA11 | NA41 | ||||
Output type | NPN | PNP | NPN | PNP | ||||
Operating voltage | 12~24V DC | |||||||
Light source | Red LED | |||||||
Distance regulation | Automatic adjustment | Manually adjust | ||||||
Response time | 25/50/100/200μs | 250 μs | ||||||
ON/OFF Time delay function | 1MS-999MS adjustment | 40MS | ||||||
Max sensing distance Diffuse reflection | 4700MM | 2200MM | ||||||
Max sensing distance Through-beam | 11000MM | 6000MM | ||||||
Switch type | Selectable L.on/D.on | |||||||
Operating temperature | ﹣25℃~55℃ | |||||||
Operating humidity | 35-85% RH | |||||||
Ambient luminance | Incandescent lamp:≤3000 lux, Sunlight:≤1000 lux | |||||||
Anti-vibration | 10-55 Hz, double amplitude 1.5 mm,XYZ three directions,1 hours each | |||||||
Impact resistance | (50G)500m/S² X,Y,Z three directions | |||||||
Connection | 2m 3-Wire cable | |||||||
About Us
Wenzhou Gtric Technology Co., Ltd. is located in Yueqing IoT sensors Park, which covers 5,000 square meters, with over 100 employees. We are focuses on intelligent manufacturing and industrial automation, our main businesses are sensors, encoders, button switch, coupling, expansion set and other industrial automation products, providing standard and individual products and solutions for customers.
Our products cover over 20 series, 1000specificatison, which have passed CCC, CE, UL, ISO9001 certification as well as EU RoHS Environmental Directives. Based on our technical advantages, Gtric can provide industrial automation solution according to customers’ requirements.
Q: Can I customize a special sensor?
A: Sure, we also offer customized services.
Q : Can I get a lower price if I order large quantities?
A : Yes, Cheaper prices with bigger size orders, please contact us and we will give you a quatation.
Q: If I need a sample for pretest, do you sale sample for this inquiry?
A: Yes, we can sale sample for pretest. If you need, please contact us.
Q : When will you ship my order?
A : 48 hours shipping guarantee for stock items and 10-15 days for non-stock items.
A: Sure, we also offer customized services.
Q : Can I get a lower price if I order large quantities?
A : Yes, Cheaper prices with bigger size orders, please contact us and we will give you a quatation.
Q: If I need a sample for pretest, do you sale sample for this inquiry?
A: Yes, we can sale sample for pretest. If you need, please contact us.
Q : When will you ship my order?
A : 48 hours shipping guarantee for stock items and 10-15 days for non-stock items.
