Гибридная солнечная система Sunflx Rs485 48 В 200 А 220
- Категория: Renewable Energy >>>
- Поставщик: Chengdu,Dod,New,Energy,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.47 $* | 0.18 $* |
| Aug-16-2025 | 0.99 $* | 0.32 $* |
| Jul-16-2025 | 0.61 $* | 0.63 $* |
| Jun-16-2025 | 0.65 $* | 0.87 $* |
| May-16-2025 | 0.69 $* | 0.55 $* |
| Apr-16-2025 | 0.0 $* | 0.3 $* |
| Mar-16-2025 | 0.39 $* | 0.22 $* |
| Feb-16-2025 | 0.20 $* | 0.56 $* |
| Jan-16-2025 | 0.20 $* | 0.37 $* |
Характеристики
Product Details
Inverter Working Mode
Product Paramenters
Model | SX-SPI-10K-U | SX-SPI-8K-U | SX-SPI-8K-S | SX-SPI-10K-S | SX-SPI-10K-SP | SX-SPI-8K-H3 | SX-SPI-10K-H3 | SX-SPI-12K-H3 | |||||||
Rated Power | 10,000W | 8,000W | 10,000W | 8,000W | 10,000W | 12000W | |||||||||
Peak Power | 20,000W | 16,000W | 20,000W | 16,000W | 20,000W | 24,000W | |||||||||
Output Waveform | Pure Sine Wave | ||||||||||||||
Rated Output Voltage | 120(single-phase) / 240V(split-phase) | 230Vac, single phase | 400Vac, three-phase | ||||||||||||
Capacity of Motor Load | 6HP | 5HP | 6HP | 5HP | 6HP | ||||||||||
Rated Frequency | 50/60Hz | ||||||||||||||
Switch Time | 10ms（typical） | ||||||||||||||
Battery Type | Li-ion / Lead-Acid / User Defined | ||||||||||||||
Rated Battery Voltage | 48Vdc | ||||||||||||||
Battery Voltage Range | 40～60Vdc | ||||||||||||||
Num. of MPPT Trackers | 2 | ||||||||||||||
Max.PV Array Power | 5,500W+5,500W | 6,000W/6,000W | 7,500W/7,500W | 9,000W/9,000W | |||||||||||
Max.Input Current | 22A+22A | ||||||||||||||
Input Frequency Range | 50/60Hz | ||||||||||||||
Bypass Overload Current | 63A | ||||||||||||||
MPPT Tracking Efficiency | 99.90% | ||||||||||||||
Max. Battery Inverter Efficiency | 92% | ≥92% | |||||||||||||
Dimensions | 620*445*130mm | ||||||||||||||
Weight | 27kg | ||||||||||||||
Protection Degree | IP20，indoor only | ||||||||||||||
Operating Temperature Range | -10~55℃, >45℃ derated | ||||||||||||||
Noise | <60dB | ||||||||||||||
Cooling Method | Internal Fan | air cooling | |||||||||||||
Internal Interface | RS485 / CAN / USB / Dry contact | ||||||||||||||
External Modules （Optional） | Wi-Fi / GPRS | ||||||||||||||
Safety | IEC62109-1, IEC62109-2, UL1741 | IEC62109-1, IEC62109-2 | IEC62109-1, IEC62109-2, UL1741 | ||||||||||||
EMC | EN61000-6-1, EN61000-6-3, FCC 15 class B | ||||||||||||||
RoHS | Yes | ||||||||||||||
Certifications
Our Factory
FAQ
sunflx 10kw split phase 3 phase parallel pv mpp solar inverter 10 kva solar hybrid inverter charger 8 kw hybrid solar inverter
Q1: Why you should choose us?8 kw hybrid solar inverter---More than 15 years solar products producing experiences
---Professional sales team and R & D team
---Qualified product and competitive price
---Delivery in time
---Sincerely services
Q2: How is your after-sale service?8 kw hybrid solar inverter
---solar panel : 10 years warranty ;
Hybrid inverter , charge controller , battery : 1-3 years warranty
--- we offer 1% sapre parts for free , will repair the PCB or provide new one
Q3: What kind of certification you have?8 kw hybrid solar inverter
---ISO9001,ISO14001, CE, ROHS, TUV ,UL and so on
---All series product pass different testing according to different countries’ requirements.
Q4: Delivery time:8 kw hybrid solar inverter
---Standard products could be delivered within 15 days after payment ;
Q5. Can I have a sample order?8 kw hybrid solar inverter
---Yes, we welcome sample order to test and check quality.
Q6. Do you have any MOQ?8 kw hybrid solar inverter
---Yes, we have MOQ , it depends on different models.
Most products 1~10pcs sample order is available. Lowest MOQ : 1 pc
Q7. Do you support OEM , ODM ?8 kw hybrid solar inverter
---Yes. OEM & ODM is available , just tell us your idea , we can design it for you .
OEM& ODM MOQ depends on different models .
OEM& ODM MOQ depends on different models .
