Product Description
Plasma Surface Treatment Machine
GS-503AH is designed by our company to mect the requirment of pretreating the surface of plastic made of PE and PP prior to printing.The molecular strucre for surface of substrate treated by The machine is changed so that the print ink adherence is improved.
High frequency plasma surface activation technology provides an innovative, safe and economical solution to the problem of bonding and bonding between objects. Plasma pretreatment can greatly improve the surface energy of the object and improve the hydrophilicity, adhesion, dyeability, biocompatibility and electrical properties. It is very important for printing, bonding, painting, coating, gluing, cleaning and other processes.
GS-503AH is designed by our company to mect the requirment of pretreating the surface of plastic made of PE and PP prior to printing.The molecular strucre for surface of substrate treated by The machine is changed so that the print ink adherence is improved.
High frequency plasma surface activation technology provides an innovative, safe and economical solution to the problem of bonding and bonding between objects. Plasma pretreatment can greatly improve the surface energy of the object and improve the hydrophilicity, adhesion, dyeability, biocompatibility and electrical properties. It is very important for printing, bonding, painting, coating, gluing, cleaning and other processes.
Feature
Assembled with general purpose conical holder can meet the normal requirements, special size is also available by made to order.
Electroplated aluminum alloy holder and bright plating
Stable Speed: Use miniature electronic speed adjustor form Janpan to ensure Reliable and stable conveyance;
Energy Saving: Specially designed flame spray gun and ejector make lliquefied gas be burnt to full;
The structure of the machine is new, design is reasonable, operation is convenient, and assembled with movable roller wheels to make convenient move.
Conveyor belt
Adjustable speeds from 1 m/min to 11.0 m/min (3 ft/min to 37 ft/min) increments: Flexibility in setting specific speeds for each application
Rotating mounting system can align plasma heads perpendicular to belt’s direction of travel: Extendable in width for curing of larger parts
Rotating mounting system can align plasma heads parallel to belt’s direction of travel: Maximum dose for curing smaller parts at faster speeds
Assembled with general purpose conical holder can meet the normal requirements, special size is also available by made to order.
Electroplated aluminum alloy holder and bright plating
Stable Speed: Use miniature electronic speed adjustor form Janpan to ensure Reliable and stable conveyance;
Energy Saving: Specially designed flame spray gun and ejector make lliquefied gas be burnt to full;
The structure of the machine is new, design is reasonable, operation is convenient, and assembled with movable roller wheels to make convenient move.
Conveyor belt
Adjustable speeds from 1 m/min to 11.0 m/min (3 ft/min to 37 ft/min) increments: Flexibility in setting specific speeds for each application
Rotating mounting system can align plasma heads perpendicular to belt’s direction of travel: Extendable in width for curing of larger parts
Rotating mounting system can align plasma heads parallel to belt’s direction of travel: Maximum dose for curing smaller parts at faster speeds
Plasma Surface Treatment Machine GS-503AH（30mm） | ||
Output power: | 1000W | |
Input voltage: | 200-240V | |
Working air pressure: | 0.1-0.3MPa | |
Processing width: | 30mm | |
Gun head size: | 90*279mm | |
Host size: | 500*280*580mm | |
Input voltage fluctuation | ±5V | |
Working pressure range | 0.1MPa～0.2MPa (1Kg～2Kg) | |
External air source requirements | 0.4MPa～1.0Mpa (4Kg～10Kg) | |
Output cable length | 3000mm | |
weight | 19KG | |
Conveyor belt
Adjustable speeds from 1 m/min to 11.0 m/min (3 ft/min to 37 ft/min) increments: Flexibility in setting specific speeds for each application
Rotating mounting system can align plasma heads perpendicular to belt’s direction of travel: Extendable in width for curing of larger parts
Rotating mounting system can align plasma heads parallel to belt’s direction of travel: Maximum dose for curing smaller parts at faster speeds
Adjustable speeds from 1 m/min to 11.0 m/min (3 ft/min to 37 ft/min) increments: Flexibility in setting specific speeds for each application
Rotating mounting system can align plasma heads perpendicular to belt’s direction of travel: Extendable in width for curing of larger parts
Rotating mounting system can align plasma heads parallel to belt’s direction of travel: Maximum dose for curing smaller parts at faster speeds
Conveyors GS-2036LDX（360mm） | ||
Overall Dimensions (LxWxH) | 2000 mm (78.8") x 540 mm (21.2") x 1450 mm (57.1") | |
Belt Width | 300mm (11.8") open mesh Teflon® coated fiberglass | |
Belt Speed | 1 m/min to 14.5 m/min (3 ft/min to 48 ft/min) | |
Height Adjustment | 30 mm to 60 mm in 10 mm increments | |
Head Angle Adjustment | 0 to 90 degrees relative to belt travel direction in 15-degree increments | |
Weight | 114 kg | |
Electrical | 100-240 V AC, 50/60 Hz, single phase | |
Controls | Power on, Speed adjust | |
In order to ensure the safety of operators and avoid harm to the plasma machine control system and environment, the safety precautions described in this section and subsequent chapters must be strictly observed whenever the plasma mechanical equipment is started.
• Note that there is high frequency and high voltage inside the plasma system. Please do not open the back cover of the chassis for debugging and maintenance during the operation of the machine.
• Note that the temperature of plasma flame is very high. Please do not use it in places with flammable and explosive materials.
• Please do not touch the plasma flame with your hands to avoid being electrified and burned.
• Note that when the plasma machine is moving and running, it is strictly prohibited to extend the body and other objects into the protective box to avoid unnecessary losses.
• Note that there is high frequency and high voltage inside the plasma system. Please do not open the back cover of the chassis for debugging and maintenance during the operation of the machine.
• Note that the temperature of plasma flame is very high. Please do not use it in places with flammable and explosive materials.
• Please do not touch the plasma flame with your hands to avoid being electrified and burned.
• Note that when the plasma machine is moving and running, it is strictly prohibited to extend the body and other objects into the protective box to avoid unnecessary losses.
