Распродажа от завода Yaweh новый многофункциональный экскаватор-погрузчик с фронтальным погрузчиком по цене
- Категория: Loaders >>>
- Поставщик: Shandong,Yaweh,Heavy,Industry,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 11900.34 $* | 12495.88 $* |
| Aug-16-2025 | 11800.45 $* | 12390.82 $* |
| Jul-16-2025 | 9900.23 $* | 10395.43 $* |
| Jun-16-2025 | 11600.37 $* | 12180.59 $* |
| May-16-2025 | 10100.5 $* | 10605.74 $* |
| Apr-16-2025 | 11400.50 $* | 11970.44 $* |
| Mar-16-2025 | 11300.61 $* | 11865.99 $* |
| Feb-16-2025 | 11200.78 $* | 11760.44 $* |
| Jan-16-2025 | 11100.58 $* | 11655.77 $* |
Характеристики
About Our Company
Details Images
Yaweh Heavy Industries Telescopic boom loader parameters | ||||||||||
Overall dimensions | Engine | |||||||||
1 | Dimension（mm) | 8750*2000*2800 | 1 | Model | Yunnei 4102 supercharged | |||||
2 | Wheelbase（mm） | 2650 | 2 | Form | Turbocharged | |||||
3 | Wheelbase（mm) | 1560 | 3 | Power Rating（KW) | 76 | |||||
4 | Minimum Ground Clearance（mm) | 320 | 4 | Rated speed（r/min) | 2400 | |||||
Performance Parameters | 5 | Cylinder bore | 102 | |||||||
1 | System pressure（Mpa) | 25 | Drivetrain | |||||||
2 | Weight of the whole machine（kg) | 6800 | 1 | Transmission | Powershift | |||||
3 | Maximum speed（Km/h) | 38 | 2 | Number of gears | Front 2 and back 2 | |||||
4 | Maximum climbing capacity（°） | 35 | 3 | Torque converter model | 280 split high and low speed | |||||
5 | Minimum turning radius（mm) | 4250 | Axle | |||||||
Partial parameters of excavator | 1 | model | Large wheel side bridge | |||||||
1 | Maximum excavation depth（mm) | 3000 | Tires | |||||||
2 | Maximum excavation radius（mm) | 4800 | 1 | Specification | 16/70-20 | |||||
3 | Maximum excavation height（mm) | 5600 | 2 | Braking form | Brake disc brake | |||||
4 | Excavation unloading height（mm） | 4100 | 3 | Parking brake | Manual brake | |||||
5 | Bucket width(mm) | 55 | Other parameters | |||||||
6 | Excavator rotation angle（°) | 280/360 | 1 | Drive form | Four-wheel drive | |||||
Steering System | 2 | Variable speed form | Hydraulic variable speed | |||||||
1 | Form | Fully hydraulic steering | 3 | Operating System | Electromagnetic hydraulic pilot system | |||||
2 | Steering angle（°） | 38 | ||||||||
