Прицеп для транспортировки сада ATV 1000
US $750.00-$1000
3 оси 40000/50000 литров топлива/дизельное топливо/бензин/сырая/вода/молоко транспортировка стальной резервуар/Автоцистерна
- Категория: Trailers >>>
- Поставщик: Shandong,China,Transport,Industrial,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 11900.12 $* | 12495.68 $* |
| Aug-15-2025 | 11800.24 $* | 12390.7 $* |
| Jul-15-2025 | 9900.29 $* | 10395.76 $* |
| Jun-15-2025 | 11600.59 $* | 12180.13 $* |
| May-15-2025 | 10100.53 $* | 10605.68 $* |
| Apr-15-2025 | 11400.95 $* | 11970.0 $* |
| Mar-15-2025 | 11300.9 $* | 11865.1 $* |
| Feb-15-2025 | 11200.15 $* | 11760.61 $* |
| Jan-15-2025 | 11100.84 $* | 11655.53 $* |
Характеристики
Tank Body | ||
Shape | Optional ( Round or Suare) | |
Dimension | 12000mm*2490mm*3990mm ( Exact size depends on the final design) | |
Tare weight | About 8000KGS-12800KGS | |
Total Volume（m3） | 25m³-60 m³ | |
Tanker Body Material | 6mm aluminum | |
End Plate | 7mm /aluminum / | |
Manhole Cover | Aluminum alloy API manhole cover, ∮500mm | |
Bottom Valve | Aluminum API Pneumatic Bottom Valve | |
Discharging Valve | Diameter is 3 or 4 inch | |
Compartments | Optional | |
Discharging Pipe | 4” rubber hose, 2 pcs, 6m/each | |
Cat Walk | With (Common model or special design) | |
Chassis | ||
Main Beams | Weldding design or Special design I beam, connected by bolts and nuts | |
Axle | 2 or 3 axles, BPW/FUWA/HUAJING brand | |
Landing Gear | JOST (D200T）or CHINA BRAND 28T | |
King Pin | JOST 2.00 or 3.5 inch bolt-in king pin | |
Suspension | Mechanical suspension/Germany or America type /air suspension | |
Leaf Spring | 90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12 /without | |
Pneumatic Braking System | WABCO RE 6 relay valve; Spring brake chamber（TKL brand）; one piece of 45L air tanks. | |
Rim | 9.00-22.5/8.00-20/8.5-20 China Brand | |
Tire | /12.00R22.5/315 80R22.5/11.00R20 /12.00R20 Brand can be Optional | |
ABS | Optional | |
Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint | |
Accessories | One standard tool box | |
Shipping Terms | By Bulk Cargo ,RORO or 40HQ Containers | |
The vehicle body is made of high-quality steel, advanced technology and strict production process. The structure of the vehicle is
reasonable, the performance is reliable, the operation is simple and the appearance is beautiful. All parts are manufactured by
famous manufacturers at home and abroad, and they are purchased, inspected and used in strict accordance with the requirements of
quality system documents to ensure the good performance of the vehicle.
reasonable, the performance is reliable, the operation is simple and the appearance is beautiful. All parts are manufactured by
famous manufacturers at home and abroad, and they are purchased, inspected and used in strict accordance with the requirements of
quality system documents to ensure the good performance of the vehicle.
Shandong China Transport Industrial Co. Ltd (CNTS).As One Member Of China National Industry Machinery Corporation(CNMC) is The Professional Semi Manufacturer In Jining City,shandong Province .which Is Known As Hometown Of Confucius And Mencius .CNTS Covers An Area Of More Than 30,000 Square Meters And Is A Modern Enterprise Specializing In The research And Development Of Semi Trailer And Spares. CNTS Has More Than 100 Outstanding Middle And Senior Technical Personnel, Has Strong Independence Research And Development Capabilities.
Our Main Products:Crawler Dumper, Semi Trailer , Mini And Medium Vehicles,backhoe Loader And Trailer spare parts ETC.we Can Do OEM & ODM Service With Reasonable Design,CNTS Products Are Sold Throughout China And Are Exported To Russia, Middle East,Southeast Asia, South America,Africa ,and Other Countries. High Quality ,Reasonable Price ,Professional Technical Service,Good Credit, CNTS Will Be The Best Business Partner For You! Welcome All Friends From All Over The World To Visit CNTS And Cooperate With Us.
As Professional Semi Trailer Supplier We Provide Custom Made.
1.We Have Carbon Steel Material , Aluminum Material , Stainless Material Tanker Trailer For Your Choose . You Can According ToYour Transport Liquid To Choose Tank Body Material.
1.We Have Carbon Steel Material , Aluminum Material , Stainless Material Tanker Trailer For Your Choose . You Can According ToYour Transport Liquid To Choose Tank Body Material.
2.Tanker trailer payload capacity from 25000 liter to 60000 liters according to your transport demand to design.
3. Axle:2 axle/3 axle/4 axles for choose.
