Лидер продаж небольшие холодильные грузовики для замороженного мяса и
- Категория: Refrigerator Trucks >>>
- Поставщик: Shandong,Shenghao,Special,Vehicle,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-18-2025 | 137029.11 $* | 139770.31 $* |
| Jul-18-2025 | 111134.29 $* | 113357.23 $* |
| Jun-18-2025 | 134871.12 $* | 137568.39 $* |
| May-18-2025 | 133792.91 $* | 136468.16 $* |
| Apr-18-2025 | 106818.5 $* | 108954.54 $* |
| Mar-18-2025 | 131634.16 $* | 134267.57 $* |
| Feb-18-2025 | 130555.89 $* | 133166.76 $* |
| Jan-18-2025 | 129476.85 $* | 132066.68 $* |
Характеристики
Product Description
Two ways packaging delivery—CKD or CBU
Many floor material option
1.The advanatages of Truck Bodies
1).It is made of GRP and PU foam with all-closed structure that the GRP (Glass Reinforced Plastic Fiber) outside and PU foam in the core
2).Light in weight:40% lighter than metal body.
3).it is be good at strength and long life.
4).Non-corrosion, non-pollution, anti-brine, acid and soda-resisting
5).The panel used for the truck body was constructed in type of sandwich.
6).The thermal insulation layer is 50-80mm thick, which offers a very good thermal insulation performance.
1)Outer/inner skin is FRP panel
2)polyurethane insulated ,PU foam density 42-45kg/m3
3)304 stainless steel locks ,hinges,door frame, wrap angle
4) aluminium alloy Edge Protector
5)EPDM rubber door seal
6)thickness: 62mm ,82mm,102mm or other special demands, body size as you demanded
7)side door is optional
8)Light in weight: 40% lighter than metal body.
9) Better insulation: K value less than 0.3w/m2k..
10)High in strength and long life: 5 times longer than metal body.
11)Non-corrosion, non-pollution, anti-brine, acid and soda-resisting.
12)Easy to be assembled and repaired at site.
Our products can be shipped in CBU (completely built up) and CKD (completely knock down) type
Temperature range,-18°C--+25°C,special request reach to -40°C
The Thickness
1)Front wall panel:85mm
2)Rear wall panel:85mm
3)Side wall panel:85mm
4)Roof wall panel:105mm
5)Floor wall panel:105mm
6)With the dimensions, the truck body can be the best Refrigeration Effect. But we also can change the Thickness by your requirements. And the thickness range is from 25mm to 150mm
Truck body, FRP truck body, FRP refrigerated truck body, FRP Cargo box, FRP truck box, FRP insulated truck body, reefer van body,
reefer truck body, Truck body panels, CKD truck body, Freezer truck body, isolation truck body, Isolated cargo box, truck box, truck van body, Van truck body, cargo van body, meat transport truck body, truck cold box, truck cool box, REFRIGERATED TRUCK BODY ckd
1).It is made of GRP and PU foam with all-closed structure that the GRP (Glass Reinforced Plastic Fiber) outside and PU foam in the core
2).Light in weight:40% lighter than metal body.
3).it is be good at strength and long life.
4).Non-corrosion, non-pollution, anti-brine, acid and soda-resisting
5).The panel used for the truck body was constructed in type of sandwich.
6).The thermal insulation layer is 50-80mm thick, which offers a very good thermal insulation performance.
1)Outer/inner skin is FRP panel
2)polyurethane insulated ,PU foam density 42-45kg/m3
3)304 stainless steel locks ,hinges,door frame, wrap angle
4) aluminium alloy Edge Protector
5)EPDM rubber door seal
6)thickness: 62mm ,82mm,102mm or other special demands, body size as you demanded
7)side door is optional
8)Light in weight: 40% lighter than metal body.
9) Better insulation: K value less than 0.3w/m2k..
10)High in strength and long life: 5 times longer than metal body.
11)Non-corrosion, non-pollution, anti-brine, acid and soda-resisting.
12)Easy to be assembled and repaired at site.
Our products can be shipped in CBU (completely built up) and CKD (completely knock down) type
Temperature range,-18°C--+25°C,special request reach to -40°C
The Thickness
1)Front wall panel:85mm
2)Rear wall panel:85mm
3)Side wall panel:85mm
4)Roof wall panel:105mm
5)Floor wall panel:105mm
6)With the dimensions, the truck body can be the best Refrigeration Effect. But we also can change the Thickness by your requirements. And the thickness range is from 25mm to 150mm
Truck body, FRP truck body, FRP refrigerated truck body, FRP Cargo box, FRP truck box, FRP insulated truck body, reefer van body,
reefer truck body, Truck body panels, CKD truck body, Freezer truck body, isolation truck body, Isolated cargo box, truck box, truck van body, Van truck body, cargo van body, meat transport truck body, truck cold box, truck cool box, REFRIGERATED TRUCK BODY ckd
Specification
echnical Specification -CARRYMAN refrigerated truck body | ||
Truck Body size (LWH) | 4000*2300*2350 | |
Inside &Outside skin | FRP | |
Insulation foam | insulation foam | |
Truck body Panel total Thickness(Panel thickness can be changed according to your requirments and applications) | ||
Roof | 80mm | |
Front Wall | 80mm | |
Side Wall | 80mm | |
Floor | 80mm | |
Rear Doors | 80mm | |
Color | white | |
Parts | ||||
Double swing door at rear | √ | standard specification | ||
Door gasket | √ | |||
Floor: FRP surface | √ | |||
Stainless Steel door locks &hinges&handle&hanger | √ | |||
Stainless Steel rear door frame | √ | |||
aluminium profile and stainless steel angle | √ | |||
Internal lights and switch | √ | |||
Sub-frame | √ | |||
Accessories for truck body assembling:(for CKDtype | ||||
Other options parts (pay extra money) |
LED right |
corner light |
Kick plate |
Single leaf side door |
Aluminum T-Channel floor |
Aluminum checker plate floor |
Aluminum corrugated floor |
Meat hanging system(sliding rail and meat hook) |
Low temperature PVC curtains |
Clapboard within body |
Truck refrigeration units |
Rear foot steps |
mudapron |
crash barrier |
Company Profile
Shandong Shenghao Special Purpose Vehicle Co., Ltd. was established in 2020 and more than 78 Employees (6 professional technology R & D). It is located in Zhucheng truck production base, coastal blue economic zone of Shandong Peninsula. At present, our company is mainly engaged in the R & D, manufacturing and sales design of special vehicles, including refrigerated vehicle body, dry truck body, truck body, truck body panel, meat transport vehicle body and other types of van body you want, as well as refrigerated compartment, insulation compartment, wingspan compartment, FRP honeycomb panel compartment, logistics stowage transport vehicle, van transport vehicle, medical garbage vehicle, livestock and poultry transport vehicle, corrugated board, aluminum plate, warehouse grid compartment Hydraulic tail plate transporter, etc.
The company has advanced technology and equipment in the international industry. It adopts today's European and American classic structure and advanced refrigeration compartment plate making technology. The product quality and performance have reached the international leading level. The products sell well at home and abroad and are widely praised by customers. Such as South America, East Asia, Africa, domestic market and Central America.
The company has advanced technology and equipment in the international industry. It adopts today's European and American classic structure and advanced refrigeration compartment plate making technology. The product quality and performance have reached the international leading level. The products sell well at home and abroad and are widely praised by customers. Such as South America, East Asia, Africa, domestic market and Central America.
Cooperative Client
Package & Transport
for truck body,we are transport it by container.
for light truck,we are transport it by container. nude packing
for bigger truck,RO-RO ship it. nude packing
for light truck,we are transport it by container. nude packing
for bigger truck,RO-RO ship it. nude packing
FAQ
1. What are your shipping terms? |
Usually, we ship our truck bodies CKD (fully disassembled) or SKD (semi disassembled) by container, and assembled trucks are also shipped by container, but in small quantities |
2. Our truck is a Korean or Japanese brand, does your truck body fit it? |
Of course, the general global light truck can be divided into 10ft, 11ft, 12ft, 14ft, 15ft, 16ft, 18ft according to the length of the cargo box, and the medium truck has 20-32ft. The body can be matched with different brands of trucks just by adjusting the distance of the beam. |
3. Is it difficult to install the body CKD or SKD? |
Our company has ten years of truck body export experience. We can provide the easiest to assemble truck body ckd |
4. Why should you buy from us instead of other suppliers? |
For the past 10 years, our company has only produced truck bodies. Our more specialized truck body. |
5. What are your payment terms? |
T/T 30% as deposit, 70% for copy of bill of lading |
6. What are your delivery terms? |
EXW,FOB,CFR,CIF |
7. What is your delivery time? |
Usually within 10 days |
8. Can it be produced according to customer requirements? |
Yes, we can produce according to customer's technical drawings and specifications |
