Телескопическая стрела гидравлическая подъемная платформа ножничный подъемник

Телескопическая стрела гидравлическая подъемная платформа ножничный подъемник

Категория: Truck >>>
Поставщик: Newindu,Construction,Engineering,(Shanghai),Co.,Ltd.

Цена:8 900,00 $ - 9 900,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-16-2025	10591.16 $*	11121.69 $*
Aug-16-2025	10502.12 $*	11027.32 $*
Jul-16-2025	8811.46 $*	9252.28 $*
Jun-16-2025	10324.34 $*	10840.24 $*
May-16-2025	8989.61 $*	9438.65 $*
Apr-16-2025	10146.19 $*	10653.50 $*
Mar-16-2025	10057.32 $*	10560.45 $*
Feb-16-2025	9968.74 $*	10466.45 $*
Jan-16-2025	9879.39 $*	10373.95 $*

Характеристики

Telescopic Boom Hydraulic Aerial Work Platform Scissor Lift FSJY0810

Electric Drive Self Propelled Scissor Lift is equipped with two kinds of motors, hydraulic lifting motor and electric driving
motor. Hydraulic lifting motor supply power to lift up and down smoothly. Electric driving motor supply power to move
forward,backward, turn around.

Working Principle is different from hydraulic drive self-propelled scissor lift.Electric Motor Drive Self Propelled Scissor Lift moves and lifts all by battery power. The operator can control lifting, moving,turning and all movement on the platform through the control system.

Contact way

Sales Manager
Winnie Wan

Newindu Construction Engineering (Shanghai) Co.,Ltd
Add: Suite 2801, Super Ocean Finance Center,2067 West Yan'an Road, Shanghai 200336, China
Tel: +86-21-62770109 Fax: +86-21-62120109
Mobile / Whatsapp/ Skype/Wechat: +86-18063016834
Web: www.newindu.com

Products Description

* Dual parallel linkage and telescopic arm could realize the dynamic adjustment of vehicle center of gravity, making the complete vehicle more stable.

* With 4WD, off-road wide tires and axle balance system, the machine is excellent in drive and adaptability to road.

* Multi-load envelope control technologies could real-time monitor the load, effectively making use of boom and making its work performance at leading edge.

* Auto balance extending mechanism improves safety of extending mechanism and extends service life of steel rope.

* Electrical control system adopts the distributed control technologies based on, implementing the auto leveling, the weighting of platform payload, the dynamic monitoring and the fault warning.

Product Paramenters

Model Number		FSJY0608	FSJY0810	FSJY1012	FSJY1214
Lifting capacity	kg	300	300	300	300
Lifting extend capacity	kg	113	113	113	113
Max. Platform Height	mm	6000	8000	10000	12000
Max. Working Height	mm	8000	10000	12000	14000
Folding Max. height (guardrail unfolding)	mm	2150	2275	2400	2525
Folding Max. height (guardrail removed)	mm	1190	1315	1440	1565
Overall length	mm	2400	2400	2400	2400
Overall width	mm	1150	1150	1150	1150
Platform Size	mm	2270*1150	2270*1150	2270*1150	2270*1150
Platform extend size	mm	900	900	900	900
Min. ground clearance (folding)	mm	110	110	110	110
Min. ground clearance (rising)	mm	20	20	20	20
Wheelbase	mm	1850	1850	1850	1850
Min. turn radius (inner wheel)	mm	0	0	0	0
Min. turn radius (outer wheel)	mm	2100	2100	2100	2100
Power source	v/kw	24/3	24/3	24/3	24/3
Running speed (folding)	km/h	3.5	3.5	3.5	3.5
Running speed (rising)	km/h	0.8	0.8	0.8	0.8
Rising/falling speed	sec	40/50	40/50	70/80	70/80
Battery	V/Ah	4*6/210	4*6/210	4*6/210	4*6/210
Charger	V/A	24/25	24/25	24/25	24/25
Max. climbing ability	%	20	20	20	20
Max. working allowable angle		2-3	2-3	2-3	2-3
Way of control		Electro-hydraulic proportion control
Driver		Double front-wheel
Hydraulic drive		Double rear-wheel
Wheel size (stuffed & no mark)		381*127	381*127	381*127	381*127
Overall Net Weight	kg	1900	2080	2490	2760
