Чистое серебро провода 9999, акустический кабель провод
US $0.85-$1.20
Медный кабель 1 5 мм 2 4 6 10 16 25 электрический медный ПВХ домашний
- Категория: Wires, Cables & Cable Assemblies >>>
- Поставщик: Zhengzhou,Sitong,Cable,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.29 $* | 0.78 $* |
| Aug-16-2025 | 0.32 $* | 0.15 $* |
| Jul-16-2025 | 0.24 $* | 0.89 $* |
| Jun-16-2025 | 0.60 $* | 0.24 $* |
| May-16-2025 | 0.77 $* | 0.58 $* |
| Apr-16-2025 | 0.7 $* | 0.83 $* |
| Mar-16-2025 | 0.72 $* | 0.35 $* |
| Feb-16-2025 | 0.79 $* | 0.32 $* |
| Jan-16-2025 | 0.2 $* | 0.1 $* |
Характеристики
Product Description
| Production Name | 450/750V PVC insulated electrical copper wire,house wiring,building wire |
| Standard | IEC,ASTM,BS,DIN,CSA,JIS,NF,KS,etc. |
| Brand | SITONG |
| Used | House Wiring |
| Material of Conductor | 100% Oxygen-free Copper |
| Material of Insulation | PVC,PE.XLPE |
| Rated Voltage | 300/500V,450/750V |
| Size | 0.5,1,1.5,2.5,4,6,10,16,25,35,50,70,95,120,150,185,240,400 mm2 |
| Color | Red,Yellow,Blue,Green,Black,White,etc. |
| Cergification | SGS,ISO,BV,TUV. |
Copper Cable Wire 1.5mm 2.5mm 4mm 6mm 10mm 16mm 25mm Electrical Cable Copper PVC House Wire
Application:
The product is suitable for power installation, fixed wiring or flexible connection for electrical appliances with rated voltage of 450/750V and below.
Technical Data:
Dimensions conductor cross-section | Construction of individual conductor | External diameter | External diameter | Conductor resistance at 20 °C | Specific. el. resistance of insulation at 70°C | Cu weight | Cable weight |
nominal | min-max. | min-max. | max. | min. | approx | ||
mm² | n x mm | mm | mm | Ω/km | MΩkm | kg/km | kg/km |
0,5 | 1 x 0,80 | 1,9 – 2,3 | 1,9 – 2,3 | 36,0 | 0,014 | 4,8 | 9 |
0,75 | 1 x 0,95 | 2,1 – 2,5 | 2,1 – 2,5 | 24,5 | 0,013 | 7,2 | 10 |
1 | 1 x 1,13 | 2,2 – 2,7 | 2,2 – 2,7 | 18,1 | 0,011 | 9,6 | 14 |
1,5 | 1 x 1,38 | 2,6 - 3,2 | 2,6 - 3,2 | 12,10 | 0,011 | 14,4 | 20 |
2,5 | 1 x 1,78 | 3,2 - 3,9 | 3,2 - 3,9 | 7,41 | 0,010 | 24,0 | 31 |
4 | 1 x 2,26 | 3,6 - 4,4 | 3,6 - 4,4 | 4,61 | 0,0087 | 38,4 | 46 |
6 | 1 x 2,70 | 4,1 - 5,0 | 4,1 - 5,0 | 3,08 | 0,0070 | 57,6 | 65 |
10 | 7 x 1,35 | 5,6 - 06,7 | 5,6 - 06,7 | 1,83 | 0,0067 | 96 | 120 |
Testing
1.100% all material must be tested.
2.All semi-finished products must be tested before entering the next process.
3.All finished products must be tested before packaging.
4.Commissioned by the authority of the third-party certification testing company for sampling.
Packaging & Shipping
1) Packing length:100 to 1,000m reeled in carton drum or according to customers' requirement.
2) Outer packing: wooden case, carton box.
3) Other packing requirement according to client's request.
Company Information
ZHENGZHOU SITONG CABLE CO.,LTD a integrated in cable production,research & development,and domestic & international trade company. | |
| Established year | 2011 |
| Location | Zhengzhou City,Henan Province,China. |
| Total asset | USD 50 million |
| Plant area | 28200 m2 |
| Number of staff | 310 |
| Number of Engineer | 15 |
| Laboratory Inspector | 24 |
| Production line | 20 |
| Testing Machine | 15 |
| Annual Producing Capacity | 600000km |
| Annual Output Value | USD 50 million |
| Main Product: | AAC,AAAC,ACSR,Bare copper wire,Steel Wire,0.6/1kv ABC Cable,Concentric Cable,Electric Wire,Power Cable,etc. |
Our Services
FAQ
1. What kinds of products does Sitong CABLE manufacture?
1)Overhead Conductor ,such as AAC,AAAC,ACSR,ACAR,AACSR,ACSR/AW and so on;
3)Concentric cable (aluminum /copper conductor);
4) PVC/XLPE Insulated and Sheathed (Armoured) Power Cable;
5)Electrical wire/buildling wire
6), Control Cable, Rubber Sheathed Cable and so on.
2. Which markets do you involve mainly in?
Our products have been exported mainly to Australia, Russia, Africa, Middle East, South-east Asia, South America,Central America,North America, Europe ,Austrapa, etc.
3. Which standards do you comply with when you produce the electrical wires and cables ?
We are able to produce electrical wires and cables based on GB, JB, IEC, BS, DIN, ASTM, JIS, NF, AS/NZS, CSA, etc. Meanwhile, we can design and manufacture the cables according to the samples and technical specification the customer provided.
4. What is the min.order quantity ?
1000M for bare conductor cable and abc cables,pvc insulated building wires can have 1000meters order quantity;
Contact Information
Jason Du(Mr.)
----------------------------
Zhengzhou Sanhe Cable Co.,Ltd.(Trading Company)
Zhengzhou Sitong Cable Co.,Ltd.( Production Plant )
Phone: +86 371 65341360/69176007
Fax: +86 371 69176006
Mobile:+86 15138668963
Mail:shcable009cnzzcable.com.cn
s009sitongcable.com.
Web:http://www.sanhecable.com.cn
QQ ID: 503950121 Wechat ID:0086 15138668963
Skype ID: jason00918
WhatsAPP ID:0086 15138668963
