Model : ADH 720P + AHD 720P TRACKING
Image Sensor: 1/4.2"OV Color
Waterproof IP: IP69
* Effective Pixels: 1288H*728V
* Horizontal Resolution: 600-800TVL
* Minimum Illumination: 1.0Lux F=1.2 (0Lux with IR on)
* Night Vision: 5-10meters
* Lens: 2.8mm
* Diagonal Viewing Angle: 120 degree optional
* Synchronization: Internal synchronization
* Signal to noise ratio: >42db
* Signal System: PAL/NTSC
* Electronic Shutter: Auto
* Video Output: RCA interface, 1.0Vp-p, 75Ohm
* White Balance: Auto
* Backlight Compensation: Auto
* Power: DC 12V
* Current Consumption: Analog = 3.3V ± 0.1V /Digital = 1.5V ± 0.1V/ I/O = 1.8V/3.3V ± 0.1V, Max 70mA with IR on
* Operating Temperature: -30C~ +85C, RH95% Max
* Storage Temperature: -20C ~ +60C, RH95% Max
* Video cable length: 5m
Model : AHD 1080P Camera
Image Sensor: 1/2.7"OV Color
Waterproof IP69
* Effective Pixels: 1936H*1096V
* Horizontal Resolution: 600-800TVL
* Minimum Illumination: 1.0Lux F=1.2 (0Lux with IR on)
* Night Vision: 5-10meters
* Lens: 2.8mm
* Diagonal Viewing Angle: 120 degree optional
* Synchronization: Internal synchronization
* Signal to noise ratio: >48db
* Signal System: PAL/NTSC
* Electronic Shutter: Auto
* Video Output: RCA interface, 1.0Vp-p, 75Ohm
* White Balance: Auto
* Backlight Compensation: Auto
* Power: DC 12V
* Current Consumption: AVDD =2.8V DVDD = 1.5V DOVDD = 1.8V, Max 130mA with IR on
* Operating Temperature: -30C~ +85C, RH95% Max
* Storage Temperature: -20C ~ +60C, RH95% Max
* Video cable length: 5m
