Exliporc SC HF 5.5kw 5kw Инвертор постоянного тока в переменный ток сынусоидный инвертор с mppt Контроллер заряда
- Категория: Power Supplies >>>
- Поставщик: Exliporc,New,Energy,(Shenzhen),Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-15-2025 | 423.45 $* | 431.82 $* |
| Jul-15-2025 | 343.60 $* | 350.83 $* |
| Jun-15-2025 | 416.63 $* | 424.45 $* |
| May-15-2025 | 413.93 $* | 421.98 $* |
| Apr-15-2025 | 330.68 $* | 337.83 $* |
| Mar-15-2025 | 406.21 $* | 414.6 $* |
| Feb-15-2025 | 403.61 $* | 411.71 $* |
| Jan-15-2025 | 400.15 $* | 408.94 $* |
Характеристики
Product Description
Specification
Model | SC HF 3500-24 | SC HF 5500-48 | ||
Rated Power | 3500VA / 3500W | 5500VA / 5500W | ||
INPUT | ||||
Voltage | 230VAC | |||
Selectable Voltage Range | 170-280VAC(For Personal Computers);90-280VAC(For Home Appliances) | |||
Frequency Range | 50Hz / 60Hz(Auto Sensing) | |||
OUTPUT | ||||
AC Voltage Regulation(Batt.Mode) | 230VAC ± 5% | |||
Surge Power | 7000VA | 11000VA | ||
Efficiency(Peak) | UP to 93.5% | |||
Transfer Time | 10ms (For Personal Computers); 20ms (For Home Appliances) | |||
Waveform | Pure Sine Wave | |||
BATTERY | ||||
Battery Voltage | 24VDC | 48VDC | ||
Floating Charge Voltage | 27VDC | 54VDC | ||
Overcharge Protection | 33VDC | 63VDC | ||
SOLAR CHARGER & AC CHARGER | ||||
Maximum PV Array Power | 5000W | 6000W | ||
Maximum PV Array Open Circuit Voltage | 500VDC | |||
MPPT Range @ Operating Voltage | 120 ~ 450VDC | |||
Maximum Solar Charge Current | 100A | |||
Maximum AC Charge Current | 80A | |||
PHYSICAL | ||||
Package size, D*W*H(mm) | 600*400*210 | |||
Gross Weight(kgs) | 10.5 | 11.5 | ||
Communication Interface | USB / RS232 | |||
ENVIRONMENT | ||||
Humidity | 5% to 95% Relative Humidity (Non-condensing) | |||
Operating Temperature | -10°C to 50°C | |||
Storage Temperature | -15°C to 60°C | |||
Product usage
Product Advantages
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
