Китайский Топ бренд Shantui SRP95M PLUS 9 5 м асфальтобетономешалка с запасными частями для
- Категория: Pavers >>>
- Поставщик: Maxizm,Construction,Machinery,(Qingdao),Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 1463926.74 $* | 1537122.22 $* |
| Aug-18-2025 | 1451624.93 $* | 1524205.35 $* |
| Jul-18-2025 | 1217888.38 $* | 1278782.9 $* |
| Jun-18-2025 | 1427020.52 $* | 1498371.15 $* |
| May-18-2025 | 1242492.49 $* | 1304617.78 $* |
| Apr-18-2025 | 1402417.11 $* | 1472538.1 $* |
| Mar-18-2025 | 1390115.58 $* | 1459621.91 $* |
| Feb-18-2025 | 1377813.39 $* | 1446704.7 $* |
| Jan-18-2025 | 1365511.95 $* | 1433787.56 $* |
Характеристики
CHINA spare parts Manufacturers Shantui SRP95M PLUS 9.5M Asphalt Concrete Paver
Contact Us
Bunny Cong
Phone Number : +86-13156910727
Email : bunny@maxizm.com
WhatsApp/Wechat : +86-13156910727
Ins : maxizm.bunny
Products Description
CHINA spare parts Manufacturers Shantui SRP95M PLUS 9.5M Asphalt Concrete Paver
Multifunctional paver is a professional equipment use in asphalt concrete surface and base stabilized material paving of highway and other types of road. It is driven by hydraulic force and controlled by microcomputer; screed plate adopts double vibrating and eccentric vibratory compaction technology; material level adopts ultrasonic sensing control technology. This makes the paver have advantage of good paving stability, even material separating and feeding, high prepressing density, smooth surface and easy to operate. Therefore the S RP90S PLUS paver is an ideal construction machine for base and surface paving projects and it offers superior paving performance to maximize productivity while providing exceptional reliability.
Product Parameters
MODEL: | SRP90S plus | SRP95M plus |
Base Paving Width (m) | 3-5.7 | 2.5 |
Maximum Paving Width (m) | 9 | 9.5 |
Maximum Paving Thickness (mm) | 350 | 350 |
Paving Speed (m/min) | 0-18 | 0-18 |
Travel Speed (km/h) | 0-2.4 | 0-2.4 |
Hopper Capacity (t) | 15 | 15 |
Theoretical Productivity (th) | 850 | 850 |
Camber Adjustment(%) | -1 - +3 | -1 - +3 |
Climbing Ability (%) | 20 | 20 |
Vertical Flatness (mm/3m) | <2 | <2 |
Horizontal Slope Error (%) | ±0.02 | 0.02 |
Density Distribution Error (%) | <5 | <5 |
Heating Method | Gas heating | Gas heating |
Lubrication Method | Centralized Lubrication | |
Diesel Engine | BF6M1013EC | BF6M1013EC/ Shangchai SC8D190G2B1 |
Power 0utput | 148 | 148/140 |
RPM | 2300 | 2300 |
Screed | AVS9030D | DVM9525Q |
Vibration Speed (r/min) | 0-1470 | 0-1470 |
Vibration Distance (mm) | 4 | 3 ,5,7.9 |
Secondary Vibration Distance (mm) | - | 0,3,6,9,12 . |
Vibration Frequency (Hz) | 0-50 | 0-50 |
Machine Weight (t) | 24 | 22 |
Maximum Operating Weight (t) | 29 | 30 |
External Dimensions LxWxH(mm) | 7800x9000x3800 | 7300x9500x3800 |
Transport Dimensions LxWxH(mm) | 7800x3000x3360 | 7300x3000x3360 |
