Геофон или гидрафон land and marsh без кабеля струнная струна для передачи данных с
- Категория: >>>
- Поставщик: SmartSolo(Beijing)Inc.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 459.59 $* | 482.21 $* |
| Aug-19-2025 | 455.75 $* | 478.99 $* |
| Jul-19-2025 | 382.79 $* | 401.78 $* |
| Jun-19-2025 | 448.25 $* | 470.1 $* |
| May-19-2025 | 390.87 $* | 410.83 $* |
| Apr-19-2025 | 440.11 $* | 462.43 $* |
| Mar-19-2025 | 436.27 $* | 458.65 $* |
| Feb-19-2025 | 432.5 $* | 454.45 $* |
| Jan-19-2025 | 428.68 $* | 449.59 $* |
Характеристики
Products Description
IAU-19 is a new generation smart seismic acquisition node used to connect with external land and marsh geophone or hydrophone.lt has wireless QC functionality to enable a field deployment tool or mobile phone to check for good status.This includes recording parameters, battery voltage, temperature, remaining data storage,GPS position and quality, connected sensor status and more.
Specification
Physical Specifications
Physical Size:132mm(L)×97mm(W)×50mm(H)(without external DCK plug)
weight:0.8 kg
0perating temperature:-40°℃~+70°C
Waterproof:IP68
Operating Life@25°C: 25 days Continuous
weight:0.8 kg
0perating temperature:-40°℃~+70°C
Waterproof:IP68
Operating Life@25°C: 25 days Continuous
50 days Segmented(12hours ON/12hours SLEEP)
Channel Performance
(2ms sample interval,31.25 Hz, 25°C, unless otherwise indicated)
(2ms sample interval,31.25 Hz, 25°C, unless otherwise indicated)
Maximum lnput Signal | 士2.5Vpeak@ Gain 0dB |
Dynamic Range | 125dB@ 2ms Gain 0dB |
Equivalent Input Noise | 0.18uv@ 2ms Gain 18dB |
Total Harmonic Distortion | <0.0002%6@ Gain odB |
Common Mode Rejection | ≥100dB |
Gain Accuracy | <0.5% |
GPS Time Standard | 1 ppm |
Timing Accuracy | ±10us,GPS Disciplined |
Details Images
Why Choose Us
High quality and 100% test
1.We have 30 years of experience in the seismic industry
2.we use supper special method to make it high quality
3.Perfect design from our own patent
4.100% test before delivery.
5.we use very good material
Company Profile
The DTCC Group was formed in 1999, with its headquarters located in Calgary, Canada. It is a manufacturer of vibration sensing and measuring equipment. This equipment, which uses “internet of Things” technology,is designed for use in unusual and challenging environments.The DTCC Group has an international presence. in addition to the corporate, training and marketing facilities in North America, we have a Business Development Center located in Beijing, together with a Research, Development and Manufacturing Facility in Shenzhen. Aditional production locations are in Langfang, Hebei and Dongguan, Guangdong.DTCC also has offices and subsidiaries in several other countries round the world. Our product ranges from Geophones, Geophone Strings available in Land, Marsh,3C, Hydrophones, Dual Component for transition and marine seismic.Digital cables for Land, Marsh and Transition Zone for the most widely used recording systems. Leader wire and connectors of all types used in seismic acquisition.
Manufacture
Exhibition
Package
Small package carton box saving deliver fee
Middle size use plywood box,make is safer
big size make it safe and saving
Certifications
FAQ
1.How many times can the IGU be assembled/disassembled?
The IGU can be assembled/disassembled at least 500 times.
2.What's the influence of IGU burying and non-burying?
Based on experiments under burying and non-burying conditions, both results meet the coupling requirement. But buried IGUs give better coupling result.
3.Does IGU test geophone element resistance and dip in the field?
IGU can do a self-test based on script setting and get geophone element resistance result but can't get dip result. Since there is no communication between IGU and HHT, the HHT cannot send test command to IGU.
4.What output data formats are provided?
SEGD 1.0, SEGD 2.1, SEGD 3.1, SEGY 1.0, SEGY 2.0, SEG 2, SAC.
Any more questions please contact with SmartSolo team
