24 порта Экранированный cat6 Сетевой Патч-панель

24 port shielded cat6 network patch panel 19" 1U cat6 STP patch panel price

1.Product Name:Cat6 Patch Panel

2. Product Type: Cat6 24-port patch panel, shielded

3. Specifications: 19′′ installation size

4. Material: injection molded with high quality cold rolled steel, phosphor bronze and PC

5. Color: Black

6.Main technical parameters

*IDC: Phosphor bronze, silver plated (20~50uiLZh), suitable for cables of 22, 24 and 26AWG (0.64, 0.5 and 0.4mm), with a life of not less than 250 times.

*8-line pin: phosphor bronze, gold-plated (20~50uiLZh), plug and socket can be re-plugged no less than 750 times

* Flame retardant: injection molded with PPO+PC to meet international standards

* Contact resistance: no more than 2.5mΩ under normal atmospheric pressure (without body resistance)

*Insulation resistance: not less than 1000MΩ under normal atmospheric pressure conditions

*Electrical strength: DC 1000V (AC, 700V) No breakdown and arcing in 1 minute

*Standard: Designed and manufactured according to international standard ISO/IEC11801; TIA/EIA568

   For more products,pls contact me for the details!

1.About the price?
Re.We usually quote within 12 hours after we confirm the technical data of your products.

2.What's the payment method?
Re.We accept L/C,T/T,Western Union,MoneyGram,PayPal etc.

3.What are your terms of payment?
Re.30% in advance,and 70% before shipment

4.How to ship the items to me?
Re.Courier(DHL,TNT,FEDEX,UPS,EMS),Airfreight,Ocean Ship are available.

5.How long is your delivery time?
Re.The general delivery time is 5-7 days after order confirmed,it depends on the order quantity.
