Дизельный вилочный погрузчик Heli 2 тонны 4 6 7 3 5 CPCD20 CPCD30 CPCD40

Цена:2 000,00 $ - 5 000,00 $*

Количество:

Electric Forklift 2 ton 4 ton 6 ton 7 ton 3.5 ton 3 ton

Product Description

Specification

Model			CPCD10	CPCD15	CPCD20	CPCD25	CPCD30
Rated capacity		kg	1000	1500	2000	2500	3000
Load center	d	mm	500	500	500	500	500
Lift height	h2	mm	3000	3000	3000	3000	3000
Mast tilt angle (forward/backward)	α/β	Deg	6/12	6/12	6/12	6/12	6/12
Front overhang	L3	mm	425	425	483	483	485
Wheel-base	L4	mm	1370	1370	1500	1500	1700
Tread(front/rear)	b4/b5	mm	890/920	890/920	970/950	970/950	1000/970
Travel brake			Hydraulic-Foot pedal
Parking brake			Mechanical-Hand level
Lift speed(with/without load)		mm/s	260/400	260/400	260/400	260/400	280/420
Lower speed (with/without load)		mm/s	(with load),600 <(without load)>300
Travel speed (with/without load)		km/h	11/12	11/12	11/12	11/12	13/15
Max. gradeability (with load)		%	15	10	10	10	13
Max. Towing (with/without load)		kN	6/5	6.5/5.5	9.4/7.5	9.8/8	11/9
Weight Distribution with load(front/rear)			3350/500	3900/600	5250/720	5900/840	6920/1080
Weight Distribution without load(front/rear)			1200/1650	1300/1700	1720/2250	1825/2415	2150/2850

Packing & Delivery

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
