Микрофон MEMS 2662-2718-DT1Z1 цифровой

Категория: Acoustic Components >>>
Поставщик: Dongguan,Xunster,Electronic,Technology,Co.,Ltd.

Цена:0,40 $ - 0,42 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-19-2025	0.99 $*	0.48 $*
Aug-19-2025	0.41 $*	0.97 $*
Jul-19-2025	0.10 $*	0.46 $*
Jun-19-2025	0.48 $*	0.63 $*
May-19-2025	0.90 $*	0.33 $*
Apr-19-2025	0.14 $*	0.21 $*
Mar-19-2025	0.84 $*	0.5 $*
Feb-19-2025	0.54 $*	0.42 $*
Jan-19-2025	0.14 $*	0.10 $*

Характеристики

XST-GM-ML-2662-2718-DT1Z1 is high-performance top-port digital silicon microphone that receives the sound signal from the topside hole on lid.Provides a series of packaged MEMS silicon microphones with compact size to achieve high performance such as high SNR, high sensitivity, excellent reliability and broad frequency response.

Parameter	Symbol	Condition	Min.	Typ.	Max	Unit
Sensitivity	Sens	94dB SPL @1kHz	-27	-26	-25	dBFS
Signal to noise ratio	SNR	94dB SPL @1kHz		61		dB(A)
Current consumption	Idd	Vdd=1.8V, fCLOCK=768KHz		300	350	µA
Total harmonic distortion	THD	94dB SPL @1kHz		0.1		%
Acoustic Overload Point	AOP	10% THD @ 1kHz		120		dBSPL
Power supply rejection	PSR	100mVpp square wave @ 217 Hz, A-weighted		-90		dBFS(A)
