Ящер 2000 кг 2500 2 тонны 2.5ton Montacargas Electrico Электрический
- Категория: Forklifts >>>
- Поставщик: Wuxi,Pangolin,Metal,Products,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 4736.50 $* | 4973.24 $* |
| Aug-19-2025 | 4696.28 $* | 4931.83 $* |
| Jul-19-2025 | 3940.54 $* | 4137.90 $* |
| Jun-19-2025 | 4617.58 $* | 4848.75 $* |
| May-19-2025 | 4020.89 $* | 4221.92 $* |
| Apr-19-2025 | 4537.56 $* | 4764.68 $* |
| Mar-19-2025 | 4497.39 $* | 4722.18 $* |
| Feb-19-2025 | 4458.71 $* | 4681.50 $* |
| Jan-19-2025 | 4418.83 $* | 4639.90 $* |
Характеристики
Products Description
Product Paramenters
Product Mode | Unit | CPD Electric Forklift | ||||
Steering Mode | Seat | |||||
Rated Load | KG | 1000/1500/2000/2500/3000/3500/5000 | ||||
Load Center | MM | 500 | ||||
Weight(including battery) | KG | 1650/2450/2850/3050/3650/3800/4400/4600/7600 | ||||
Lifting height | MM | 3000 | ||||
Pallet fork size（sheet metal） | MM | 920*100*35;1070*100*35;1070*100*40; 1070*120*40;1070*120*45;1070*120*45;1220*120*55 | ||||
Min.Turning radius | MM | 1400/2000/2300/2300/2500/2600/2750 | ||||
Wheel base | MM | 860/1080/1380/1380/1380/1680/1780/1940 | ||||
Minimum square channel width | MM | 1600/2300/2500/2500/2800/2900/4290 | ||||
Overhead guard height | MM | 2100/1650/1850/2150/2450/2650 | ||||
Overhead guard to the seat height | MM | 950/1005/1005/1005/1005/1005/1400 | ||||
Pallet fork height from the ground(lowest) | MM | 90 | ||||
Tilting angle/The door frame Angle | F/R(α/β) | 6.0/12 | ||||
Travel speed (fully loaded/ no-load) | Km/h | 12/13; 12/14; 12/14; 10/12; 12/14; 12/14; 13*14 | ||||
Lifting speed(fully loaded/no-load) | mm/s | 350/400; 280/340; 280/340; 280/340; 360/390; 340/390; 250/410 | ||||
Maximum climbing ability/Gradability | % | 10/12/12/11/12/11/13 | ||||
The traction | mm | 6000-20000 | ||||
Overall Length | MM | 1650/2080/2380/2380/2600/2700/2950 | ||||
Overall Width | MM | 1000/1050/1150/1150/1250/1250/1510 | ||||
Total height (pallet fork in the highest position) | MM | 4000/4180 | ||||
Height of the door frame | MM | 1980/1980/2000/2000/2000/2000/2180 | ||||
Channel width,with 1000*1200 tray | Ast(mm) | 3810-4090 | ||||
Channel width,with 800*1200 tray | Ast(mm) | 3940-4220 | ||||
Frot Tires | mm | 18*6*12; 6.50-10; 6.50-10; 23*9-10; 23*9-15; 23*9-15; 8.25-5 | ||||
Rear Tires | mm | 15*5*11; 5.00-8 ; 5.00-8; 18*7-10; 18*7-8; 18*7-8; 7.00-12 | ||||
Driving motor power | kw | 3 | ||||
Lifiting motor power | kw | 3 | ||||
Controller typer | DC/AC | |||||
Battery voltage/capacity | V/Ah | 48/60/80/(260Ah*8) | ||||
Noise | dB(A) | ≤70 | ||||
Advantages of our products
●Intelligent controller has reliable quality and its performance is excellent.·Regenerative braking function makes the machine brkae smoothly.Battery can save more power so that it can be durable.
●The machine has high quality driving system and closed-loop control.So it has a swift reponse, controls the machine accurately and runs smoothly.
●High quality AC motor has good heat disperion and long service life. It is free of maintenance.
●The machine is made of special materials and equipped with composite bearings. so that the machine can prevent the portal frame waggling and lift goods smoothly.
●Ergonomic handl is covenient for people to operate.
●Pow-of protection prevents damaging to the motor.
●The machine has high quality driving system and closed-loop control.So it has a swift reponse, controls the machine accurately and runs smoothly.
●High quality AC motor has good heat disperion and long service life. It is free of maintenance.
●The machine is made of special materials and equipped with composite bearings. so that the machine can prevent the portal frame waggling and lift goods smoothly.
●Ergonomic handl is covenient for people to operate.
●Pow-of protection prevents damaging to the motor.
Our Factory
Wuxi Pangolin Metal Products Co., Ltd.
The pangolin forklift group company is a high-tech enterprise, and has the only“nationally recognized enterprise technology center"in the national forklift in-dustry.
We are located inWuxi, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of markets around the world. Covering an area of 20000 square meters, we now have over 1500 employees and an annual sales figure that exceeds USD 1000 Million. We are currently exporting 65% of our products worldwide. Our well-equipped facilities and excellent quality control throughout all stages of production enable us to guarantee total customer satisfaction. As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching North America and South Asia.
Exhibition
Product packaging
Certifications
The pangolin forklift group company is a high-tech enterprise, and has the only“nationally recognized enterprise technology center"in the national forklift in-dustry.
After multiple phases of technological transformation, a flexible manu-facturing system for forklifts based on CN equipment and CAO / CAO / CAO/NIMADE-ll has been initially established; a sound quality system has been es-tablished, and IS09001 quality system certification and CEo safety certificationin accordance with EU standards have been passed.The company producesand operates forklifts, wreckers, loaders and other construction machinery. Theleading product is the contemporary international level H2000 series forkliftwith completely independent intellectual property rights.
FAQ
Q1: How about the delivery time?
A1: Usually our producing time is 15- 20 days after we receive the advanced payment. For some standard products, we may have stock and could delivery immediately.
Q2: How about the continuous working time for the electric series forklifts ? How long time to charge the battery full?
A2: Our battery continuous working time is around 3-6 hours (working time depend on battery volume).It needs usually 8 - 12 hours to charge the battery, our charger is automatic, after the battery is full, it will stop working automatically.
Q3: Can you provide customized products? OEM products or ODM products?
A3: Yes, we can provide customized products per your request, both OEM and ODM are acceptable. We do a lots of non-standard products, welcome your special reqeust.
Q4: Could we request our own color for the products?
A4: Yes, of course, you just need to offer us the RAL code.
Q5: How long is the after-sales warranty?
A5: We can provide video technical support.
Q6. Can I visit your company?
A6: Of course. We always with great pleasure at your service. We have a showroom in Wuxi, China. If you want to order our products and visit our company, please contact us to make an appointment.
A1: Usually our producing time is 15- 20 days after we receive the advanced payment. For some standard products, we may have stock and could delivery immediately.
Q2: How about the continuous working time for the electric series forklifts ? How long time to charge the battery full?
A2: Our battery continuous working time is around 3-6 hours (working time depend on battery volume).It needs usually 8 - 12 hours to charge the battery, our charger is automatic, after the battery is full, it will stop working automatically.
Q3: Can you provide customized products? OEM products or ODM products?
A3: Yes, we can provide customized products per your request, both OEM and ODM are acceptable. We do a lots of non-standard products, welcome your special reqeust.
Q4: Could we request our own color for the products?
A4: Yes, of course, you just need to offer us the RAL code.
Q5: How long is the after-sales warranty?
A5: We can provide video technical support.
Q6. Can I visit your company?
A6: Of course. We always with great pleasure at your service. We have a showroom in Wuxi, China. If you want to order our products and visit our company, please contact us to make an appointment.
Maintenance & Attention
◎Correct lifting goods, do not overload or partial load use, avoid the goods beyond the front of the fork use, avoid the goods are
too wide, pay attention to read the body of the load bearing curve and warning signs.
◎According to the ground conditions to determine whether to allow the use.
◎For special customized specifications such as broadening, heightening, lengthening, etc., the actual usage tonnage should be
reduced by 40%-50% compared with the marked tonnage of the machine.
◎Please wear safety shoes and gloves when operating.
◎Do a thorough inspeck before each job.
◎Do not ignore the potential hazards that may exist during operation.
◎Each time finishing the work, the fork should be empty and lowered.
◎When operate maintenance, check oil, air and lubrication.
too wide, pay attention to read the body of the load bearing curve and warning signs.
◎According to the ground conditions to determine whether to allow the use.
◎For special customized specifications such as broadening, heightening, lengthening, etc., the actual usage tonnage should be
reduced by 40%-50% compared with the marked tonnage of the machine.
◎Please wear safety shoes and gloves when operating.
◎Do a thorough inspeck before each job.
◎Do not ignore the potential hazards that may exist during operation.
◎Each time finishing the work, the fork should be empty and lowered.
◎When operate maintenance, check oil, air and lubrication.
