➤ The hydraulic elevator home lift adopts vertical elevating system. This durable and easy-to-use vertical lift is suitable for indoor or outdoor applications requiring vertical transportation.
➤The hydraulic lift can be directly installed into the ground without architectural supporting pits and easy to operate.
➤Its hydraulic or screw system offers passengers smooth and comfortable transportation and different safety devices remove every hiding risk.
➤Emergency descending system: when there is no power or malfunctions, manually descend the lift.
➤Control System: control panel on platform, control columns on every floor and remote control are all available.
➤It’s suitable for large-sized newly-built residential estates and those areas where there is compact land resource.
Specifications | ||||||
Product Name | Model | Lifting capacity | Material | |||
Outdoor wheelchair lift | SJC | 250KG (customizable) | 304 stainless steel or Aluminum plate | |||
Platform size | 1300x1000mm | |||||
Overall size | 1400x1370x 4500mm | |||||
Max. platform height | 3500mm ( customizable as per your actual needs) | |||||
Configuration | open through or front and side entrances | |||||
Lifting speed | 70mm/s | |||||
Power Output | 1.5kw or 2.2kw | |||||
Power Input | 220V/50HZ/25A (or customized as per local voltage) | |||||
Drive System | hydraulic | |||||
Control Mode | inching switch or automatic (optional) | |||||
Drive Control | self-resetting system | |||||
Guardrail & drive cabinet (framework) | 304 Stainless steel or Aluminum Plate (optional) | |||||
Working Condition | both indoors and outdoors | |||||
Working temperature | -10°~60°C | |||||
Installation | Non-pit installation, directly fixed to concrete floor (the concrete floor below the platform shall not be lower than the ground) |
Safety Devices | ||
Safety Interlock | Lock the platform when it is out of control | |
Safety Sensor | The operation must be stopped immediately the safety edge meets obstacles during operation. | |
Emergency lowering | The platform can be lowered down manually when any emergency | |
Auto-flap | Turn up max.75° after lifting up which can prevent wheelchair from dropping down | |
Anti-failing device | If chains broken, lift will stop automatically to prevent it from dropping |
is the professional manufacturer of hydraulic lifts for 12 years. Our factory covers 78500 square meters and has a series of modern production equipments, like auto cutting equipment, automatic equipment, automatic abrasive blasting production rust removal line. spray paint line, automatic welding robot and so on. We have been exporting to different many countries for 5 years. Welcome to visit our factory and test our machines' quality, Sincerely.
* Technical supports and suggestions before you order a machine according to your work place.
* All the machines will be full tested before shipments
* View our Factory.
* Operation manual and training how to use the machine.
* Engineers available to service machinery overseas.
* 12 months warranty period and we will provide the consumable parts at cost price after the warranty period
* 24-hour technical support by emails, calling or videos
Packaging | ||
Size | as per special model | |
Weight | as per special model | |
Packaging Details | The normal package is plywood case.If container is too tigher,we will use pe film for packing or pack it according to customers special request. |
