Кабель электропитания 0,75-10 мм2, Электрический кабель
US $0.45-$0.55
Гибкий экранированный кабель управления системой солнечной энергии Ali медные электрические сварочные кабели с
- Категория: >>>
- Поставщик: Henan,Ali-Cable,Group,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.10 $* | 0.44 $* |
| Aug-19-2025 | 0.81 $* | 0.92 $* |
| Jul-19-2025 | 0.75 $* | 0.62 $* |
| Jun-19-2025 | 0.17 $* | 0.25 $* |
| May-19-2025 | 0.27 $* | 0.16 $* |
| Apr-19-2025 | 0.77 $* | 0.81 $* |
| Mar-19-2025 | 0.0 $* | 0.93 $* |
| Feb-19-2025 | 0.11 $* | 0.30 $* |
| Jan-19-2025 | 0.95 $* | 0.64 $* |
Характеристики
flexible shielded control cable mechanical control cables
Control cable is suitable for the wiring of electric controlling equipment and instrument, monitoring and controlling return circuit ,electrical protection and measurement in power distribution unit under the circumstance that the rated voltage is up to 450/750 AC.
Products Description
mm2 | Conductor type | Insulation mm | copper tape screen mm | steel tape Layer*thickness | Jacket mm | Over Dia mm | ||
Lowest | highest | |||||||
30*1.0 30*1.5 30*2.5 | 1 1 1 | 0.6 0.7 0.8 | 0.05 0.05 0.05 | 2*0.2 2*0.2 2*0.2 | 1.7 1.7 1.7 | 20.2 23.2 26.7 | 24.7 27.7 31.7 | |
37*1.0 37*1.5 37*2.5 | 1 1 1 | 0.6 0.7 0.8 | 0.05 0.05 0.05 | 2*0.2 2*0.2 2*0.5 | 1.7 1.7 2.0 | 21.7 24.7 30.2 | 26.2 29.7 35.2 | |
44*1.0 44*1.5 44*2.5 | 1 1 1 | 0.6 0.7 0.8 | 0.05 0.05 0.05 | 2*0.2 2*0.2 2*0.5 | 1.7 2.0 2.2 | 23.7 27.7 33.7 | 28.7 33.2 39.2 | |
48*1.0 48*1.5 48*2.5 | 1 1 1 | 0.6 0.7 0.8 | 0.05 0.05 0.05 | 2*0.2 2*0.5 2*0.5 | 1.7 2.0 2.2 | 24.2 29.2 34.2 | 29.2 34.2 39.7 | |
52*1.0 52*1.5 52*2.5 | 1 1 1 | 0.6 0.7 0.8 | 0.05 0.05 0.05 | 2*0.2 2*0.5 2*0.5 | 1.7 2.0 2.2 | 24.7 30.2 35.2 | 29.7 35.2 40.7 | |
61*1.0 61*1.5 61*2.5 | 1 1 1 | 0.6 0.7 0.8 | 0.05 0.05 0.05 | 2*0.2 2*0.5 2*0.5 | 1.7 2.0 2.2 | 26.2 31.7 37.2 | 31.2 36.7 42.7 | |
Details Images
Our Advantages
Company Profile
Henan Ali-Cable Group Co., Ltd. was founded in 2012 and is one non-regional enterprise integrating R&D, manufacturing and sales of various wires and cables. The company’s headquarters is located in Gongyi-Zhengzhou City, which covers an area of 160,000m2 with total assets of 350 million.
With first-class domestic & imported manufacture and test equipment, Ali-Cable can manufacture more than 6000 specifications including All Aluminium Conductor (AAC), All Aluminium Alloy Conductor (AAAC), Aluminium Conductor Steel Reinforced (ACSR), Aluminium Alloy Conductor Steel Reinforced (AACSR), Aluminium Conductor Aluminium Clad Steel Reinforced (ACSR/AW), Aluminium Conductor Aluminium Alloy Reinforced (ACAR), Aluminium Clad Steel Strand (ACS), Aerial Bundle Cable (ABC & Service Drop), LV&MV PVC/XLPE Insulated Power Cable (flame retardant / fire resistance / low smoke halogen free), 8030 Al Alloy Power Cable, Control Cable, Coaxial Cable, Solar Cable, etc. Through years of unremitting effort, our products have obtained a high reputation in the customers from dozens of countries and regions in Southeast Asia, the Middle East, Africa, South America, etc with superior quality, reasonable price and sincere after-sale services.
Certifications
Our factory
Packing shipping
FAQ
1. Q: Are you a factory or trading company?
A: We’re a factory locates in Henan Province, which integrates R&D, manufacture and sales of various wires and cables
2. Q: What are your main products?
A: AAC/AAAC/ACSR/ACAR/AACSR/ACSR-AS/ACSS/ACSS-AW/ACS/GSW conductor, ABC cable, power cable, control cable, concentric cable,common electric wire, etc
3. Q: Can we have our logo or company name to be printed on your products or the package?
A: Yes, OEM and ODM are both acceptable for us.
4. Q: Do you provide samples? Free or not?
A: Yes, we’d like to provide free samples for your reference, but won’t bear the express fees.
5. Q: How long is your warranty period?
A: 1 year, and we promise to return or replace the cables within one year if any quality problem is found..
