3 5 тонный вилочный погрузчик внедорожник 4WD 4x4 Вездеходный дизельный на
- Категория: Forklifts >>>
- Поставщик: Shandong,Yuanxing,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 3451.42 $* | 3624.35 $* |
| Aug-20-2025 | 3422.65 $* | 3593.66 $* |
| Jul-20-2025 | 2871.93 $* | 3015.77 $* |
| Jun-20-2025 | 3364.43 $* | 3532.73 $* |
| May-20-2025 | 2929.21 $* | 3075.79 $* |
| Apr-20-2025 | 3306.47 $* | 3471.94 $* |
| Mar-20-2025 | 3277.94 $* | 3441.99 $* |
| Feb-20-2025 | 3248.59 $* | 3410.11 $* |
| Jan-20-2025 | 3219.85 $* | 3380.1 $* |
Характеристики
Product Description
Chinese Supplier Electric/diesel Mini Forklift Truck Small Rough Terrain Forklift Price 3 ton 4 ton 5 ton 7 ton
1.High quality
Optional Japanese engine diesel forklift truck 1.5 ton 2 ton 2.5 ton 3.5 ton 4 ton 5 ton 3 ton Diesel Forklift Price
--Adopt gradeability improving style electronic hydraulic transmission,compare with other models:efficiency 5% improved,climbing torque 8% increased,noise 3~5dB reduced,thermal equilibrium temperature 8-10°decreased;
--The super large capacity aluminum tube belt radiator and optimized heat dissipation channel further improve the heat dissipation capacity of the vehicle; -- Load sensing priority steering hydraulic system is adopted to reduce pressure loss of hydraulic system, save energy and improve operation comfort.
-All car LED lights, high brightness, long life, energy saving and environmental protection.
2.High comfort
--The new suspension system,adjustable seat,allowing the driver to feel more comfortable and reducing fatigue during long operations;
--The combined color instrument has strong human-machine interaction and timely and accurately feedback the running state of vehicles.
--Spacious control space, comfortable seats, enjoy the pleasure of riding.
3.Rich options
ISUZU engine, high exhaust device, air prefilter, fireproof cap, solid tire, two stage free lift mast, three stage free lift mast , widening fork frame, fork sleeve, side shifter, paper roll clamp, bale clamp, carton clamp, block clamp, rotators, drum clamp, push-pull, etc.
--Adopt gradeability improving style electronic hydraulic transmission,compare with other models:efficiency 5% improved,climbing torque 8% increased,noise 3~5dB reduced,thermal equilibrium temperature 8-10°decreased;
--The super large capacity aluminum tube belt radiator and optimized heat dissipation channel further improve the heat dissipation capacity of the vehicle; -- Load sensing priority steering hydraulic system is adopted to reduce pressure loss of hydraulic system, save energy and improve operation comfort.
-All car LED lights, high brightness, long life, energy saving and environmental protection.
2.High comfort
--The new suspension system,adjustable seat,allowing the driver to feel more comfortable and reducing fatigue during long operations;
--The combined color instrument has strong human-machine interaction and timely and accurately feedback the running state of vehicles.
--Spacious control space, comfortable seats, enjoy the pleasure of riding.
3.Rich options
ISUZU engine, high exhaust device, air prefilter, fireproof cap, solid tire, two stage free lift mast, three stage free lift mast , widening fork frame, fork sleeve, side shifter, paper roll clamp, bale clamp, carton clamp, block clamp, rotators, drum clamp, push-pull, etc.
Chinese Supplier Electric/diesel Mini Forklift Truck Small Rough Terrain Forklift Price 3 ton 4 ton 5 ton 7 ton
Parameters
Product Name | Off-Road Forklift | |||
Model | JK-3.0T | JK-3.5T (Standard version) | JK-3.5T (High version) | |
Size | 4.2*1.8*2.7m | 4.2*1.8*2.7m | 4.2*1.8*2.7m | |
Curb Weight | 4000kg | 4200kg | 4200kg | |
Fork Length | 1220-1820mm | 1220-1820mm | 1220-1820mm | |
Climbing Angle | ≤38° | ≤38° | ≤38° | |
Rated Lifting Force | 3000kg | 3500kg | 3500kg | |
Lifting Height | 3000-6000mm | 3000-6000mm | 3000-6000mm | |
Turning Radius | 3500mm | 3500mm | 3500mm | |
Door Frame Width | 0.7m | 0.7m | 0.7m | |
Door frame front ground clearance | 250-350mm | 250-350mm | 250-350mm | |
Wheelbase center ground clearance | 250mm-300mm | 250mm-300mm | 250mm-300mm | |
Frame | Hinged thickness 3mm | Hinged thickness 3mm | Hinged thickness 3mm | |
Axle | Small wheel side weight cast steel bridge | Small wheel side weight cast steel bridge | Small wheel side weight cast steel bridge | |
Tire | Large 20.5 / 70-16 tires | Large 20.5 / 70-16 tires | Large 20.5 / 70-16 tires | |
Drive Mode | Four-wheel drive | Four-wheel drive | Four-wheel drive | |
Engine Model | HuaDong 4DBY4(490) | Yunnei YN27(490) | Yunnei YN27GBZ | |
Engine Power | 40 KW | 42 KW | 58 KW | |
Gearbox | 265 double high and low speed | 265 double high and low speed | 265 double high and low speed Large pump torque converter Hydraulic torque converter | |
Fuel Tank Volume | 50 L | 50 L | 50 L | |
Detailed Images
Packaging & Shipping
Company Information
FAQ
1.Are you original manufacture?
Yes,we YUANXING are an official leading manufacture in construction machinery in China.
2.What's your trade terms?
EXW, FOB, CFR, CIF
3.What kind terms of payment can be accepted?
Normally we can work on T/T or L/C term,WU also work on small amounts.
4.What about the delivery time?
7-30 days after receving the deposit.
5.What's your warranty?
One year.
6.Do you accept to customize the products?
Yes, all products can be customized. Such as logo, color, size, other extra configuration etc.
