FRD-LH19 H25 портативный роутер для Wi-Fi камеры термического формирования изображений Охотник простор 384x288 с ИК-подсветкой работы в темное время суток прицельное Монокуляр инфракрасная камера режимом ночного
- Категория: Night Vision >>>
- Поставщик: Beijing,Furuide,Photoelectric,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.47 $* | 0.2 $* |
| Aug-16-2025 | 0.33 $* | 0.8 $* |
| Jul-16-2025 | 0.77 $* | 0.2 $* |
| Jun-16-2025 | 0.31 $* | 0.98 $* |
| May-16-2025 | 0.30 $* | 0.41 $* |
| Apr-16-2025 | 0.19 $* | 0.7 $* |
| Mar-16-2025 | 0.74 $* | 0.70 $* |
| Feb-16-2025 | 0.37 $* | 0.99 $* |
| Jan-16-2025 | 0.56 $* | 0.88 $* |
Характеристики
Product Description
FRD-LH19 H25 Portable WIFI Thermal Imaging Hunter Scope 384x288 Night Vision Infrared Sighting Monocular Infrared Night Vision
Specification
Model | LH25 | LH19 | |||
Thermal imaging | Detector type | Uncooled VO×detector | |||
Max image size | 384×288 | ||||
Pixel size | 12μm | ||||
Wave band | 8-14μm | ||||
NETD | ＜35mk | ||||
MRTD | 500mk | ||||
Lens focal length | 25mm | 19mm | |||
Object distance | detect（m) identify(m) | detect（m) identify(m) | |||
Person | 2502 627 | 1900 476 | |||
Image display | FOV | 10.5°×7.9° | 13.8°×10.4° | ||
Max aperture | F1.0 | ||||
Frame frequency | 50fps | ||||
Brightness control | 1-5 level adjustable | ||||
Display resolution | 1280×960 | ||||
Displayer | LCOS | ||||
Manual focusing | Support | ||||
Image mode | Black heat,white heat,red heat,fusion model | ||||
Electronic magnification | 1X,2X,4X,8X | ||||
Base magnification ratio | 2.45 | 1.86 | |||
Contrast control | 1-5 level adjustable | ||||
WIFI | Support | ||||
System function | Image | Support | |||
Video | Support | ||||
Hotspot track | Not Support | ||||
Laser pointing | Support | ||||
Cross division line | Support | ||||
Ranging | Support | ||||
Interface | TYPE-C | ||||
Storage | 8G | ||||
System parameter | Time of endurance | ＞7.5h | |||
Working temp | -20 ～55℃ | ||||
Degree of protection | IP67 | ||||
Weight | ≤300g | ≤310g | |||
Overall size | ≤57×61×171mm | ||||
Packing & Delivery
Night vision binocular handheld Investigator Packaged by Standard Safety Box
Products Application
Company Information
FRD Optics Technology Co., Ltd is focus on the R&D, production and sales of optical components, optical lenses and infrared thermal image for more than 10 years.Our products are mainly used in electric power monitoring, maritime monitoring, petroleum and petrochemical, metallurgical manufacturing, coal mine safety, airport inspection and quarantine,Oilfield monitoring and scientific research, railway testing, urban security monitoring, border monitoring, highway monitoring, forest fire prevention, fire protection and other industries.
What product FRD can supply:
Products including: Optical element,optical lens,such as UV lens, Visible light lens, Near-infrared short-wave lens, medium-wave cooled lens, infrared long-wave lens, terahertz camera lens,we're an all band optical products supplier.
Lenses customized
Such as Extender/Teleconverter lenses,Field lenses,Terahertz Lenses,Beam Expander,Shot Wave Infrared (SWIR)Lenses,UV Lenses,Telecentric Field Lenses,Prime Athermalized Lens,Continuous Zoom Lens,Dual field of view lens,Medical temperature measuring lens,Uncooled surveillance camera,Laser field lens-Telecentric Scan lens,etc.
Optical element:
Such asdiaphragms speculum lenses,sphere lenses,brewster window,plane waveplate,plane mirror,plano filter,plane windows,attenuance filter, plane attenuator,curved surface mirror,
clindrical lenses,prisms,ellipsoidal mirror,spherical lenses,infared (IR) Filter,axicon lenses,aspherical lenses,aspherical metal lenses,aspherical mirror,spherical mirror,etc.
clindrical lenses,prisms,ellipsoidal mirror,spherical lenses,infared (IR) Filter,axicon lenses,aspherical lenses,aspherical metal lenses,aspherical mirror,spherical mirror,etc.
Module customized
Such as LWIR Uncooled module,Temperature measurement type,LWIR Uncooled module--Alarm type,MWIR cooled module,etc.
Complete equipment
Such as Dual optical path monitoring system,HD Laser Night Vision,Automatic infrared human body thermometer,Thermal Imaging Microscope,Dual light ship navigation aid system,FRD_F series handheld thermal imager,Military Multispectral Handheld Thermal Imager,Dual optical path Forest Fire Monitoring System,etc.
Optical materials
Such as BK7,Fused Silica,Quartz,CaF2,MgF2,Sapphire,Silicon,Germanium,ZnS,etc.
Optical design
Quality assurance
Certificate
FAQ
1. Who are we?
We focus on the R&D, production and sales of optical components, optical lenses and infrared thermal imaging system more than 10 years.
2.How can we guarantee quality?
Professional and experienced team,Use the world's advanced testing equipment such as MTF measment equipment, High & Low Temperature Chamber, Zygo interferometer, Profiler,central deviation measuring instrument.
3. Why choose us?
1. Strong customized service capabilities.
2. More than 10 years of R&D and design team.
3. Perfect pre-sale,in-sale and after-sale service.
4. Reliable quality assurance, North America and Europe certification approved, and lifetime maintenance.
4. What services can we provide?
We design and customize the high quality optics and optical components covering UV, VIS, NIR and IR wavelengths.
5.Your products can be customized?
Yes of course!We accept OEM &ODM orders. Actually most of our products are customized. We will try our best to fulfill your requirements.
6. Do you have the after sales service?
24 hours online service!
Free inspection of product fault!
Problems and faults within the warranty period are exempted from all maintenance costs and material costs.
Free upgrade and calibration of software faults
After the warranty period,the maintenance will only charge the cost of spare parts and provide the customer with the repair test quotation report.
We focus on the R&D, production and sales of optical components, optical lenses and infrared thermal imaging system more than 10 years.
2.How can we guarantee quality?
Professional and experienced team,Use the world's advanced testing equipment such as MTF measment equipment, High & Low Temperature Chamber, Zygo interferometer, Profiler,central deviation measuring instrument.
3. Why choose us?
1. Strong customized service capabilities.
2. More than 10 years of R&D and design team.
3. Perfect pre-sale,in-sale and after-sale service.
4. Reliable quality assurance, North America and Europe certification approved, and lifetime maintenance.
4. What services can we provide?
We design and customize the high quality optics and optical components covering UV, VIS, NIR and IR wavelengths.
5.Your products can be customized?
Yes of course!We accept OEM &ODM orders. Actually most of our products are customized. We will try our best to fulfill your requirements.
6. Do you have the after sales service?
24 hours online service!
Free inspection of product fault!
Problems and faults within the warranty period are exempted from all maintenance costs and material costs.
Free upgrade and calibration of software faults
After the warranty period,the maintenance will only charge the cost of spare parts and provide the customer with the repair test quotation report.
