RW профессиональные шкафы для хранения документов с рельсовой картой Архивный Шкаф мобильные полки
- Категория: Filing Cabinets >>>
- Поставщик: Shenyang,Richwinner,Trade,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 117.34 $* | 123.4 $* |
| Aug-17-2025 | 116.38 $* | 122.83 $* |
| Jul-17-2025 | 97.59 $* | 102.67 $* |
| Jun-17-2025 | 114.28 $* | 120.99 $* |
| May-17-2025 | 99.27 $* | 104.54 $* |
| Apr-17-2025 | 112.35 $* | 118.47 $* |
| Mar-17-2025 | 111.58 $* | 117.43 $* |
| Feb-17-2025 | 110.56 $* | 116.92 $* |
| Jan-17-2025 | 109.54 $* | 114.9 $* |
Характеристики
Product Description
Shelf body | Stand Column | Cold-roll steel | 1.5mm | GB708 |
Partition Whole body partition flange 25mm (reinforcing rib under the partition) | Cold-roll steel | 1.0mm | GB708 | |
Side plate | Cold-roll steel | 1.0mm | GB708 | |
Upper cover plate (whole body side plate dimension 300*100mm) | Cold-roll steel | 1.0mm | GB708 | |
Panel | Cold-roll steel | 1.0mm | GB708 | |
chassis | Main beam and whole frame board(every wheeolk frame board have six; 55mm beam bush hold. every hole have sealing | Hot rolled steel plate | 3.0mm | GB710 |
pathway | Rail | High quality steel plate | Solid square tube | GB710 |
Rail box | High quality steel plate | 26*95mm Thickness 3.0 | GB710 | |
Pathway | High quality steel plate | 50*185mm Thickness 3.0 | GB710 | |
Transmission part | Handle crank | ZG45 | Bothway overload clutch double axis transmission | GB1285 |
Transmission shaft | Solid core 45 steel | Φ20 | GB699 | |
Linkage rail | Seamless steel tube | Φ20*2.5 | GB699 | |
Bearing | Precision bearing | HR6204 | GB/T307.9-2005 | |
Chain wheel | ZG45 | GB1135 | ||
Chain | FR420 | Φ8.5, pitch 12.7 breaking force 1800kg | GB1244 | |
Idler wheel | HT20-40 | Cast iron | Gb11351 | |
Sealing rubber strip | Magnetic fluid sealant | |||
Dust shield | Cold-roll steel | 1.0 | Gb710 | |
Barb | Hot rolled steel plate | 3.0mm | Gb711 |
Details Images
