8s 10s 13s 16s Jikong 36 В 48 Циркулярный Ant Jbd Smart Jk Bms Lifepo4 для литий-ионной батареи 50 Ач 18650 с
- Категория: PCB & PCBA >>>
- Поставщик: Shenzhen,Haisheng,Hongye,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-19-2025 | 37.74 $* | 38.44 $* |
| Jul-19-2025 | 30.46 $* | 31.85 $* |
| Jun-19-2025 | 36.87 $* | 37.89 $* |
| May-19-2025 | 36.17 $* | 37.94 $* |
| Apr-19-2025 | 29.53 $* | 30.31 $* |
| Mar-19-2025 | 35.74 $* | 36.62 $* |
| Feb-19-2025 | 35.75 $* | 36.59 $* |
| Jan-19-2025 | 35.79 $* | 36.84 $* |
Характеристики
JK jikong BMS Introduction
☆ All BMS have built-in bluetooth, app available, support Android/IOS devices
☆ All products are CE certified
☆ Each product is 100% inspected before leaving the factory
☆ Each product is 100% inspected before leaving the factory
☆ common/same port equalization
☆ With Short Circuit protection
☆ With Temperature Protection
☆ Other interfaces LCD Display GPRS Customizable
☆ Suitable for 7-24 strings battery Management protection board, 40A-200A current, ☆ maximum current support 300A 350A 500A 1000A
☆ Smart BMS For Lifepo4/Li-ion/Lto Battery Pack
☆ All JK BMS Types:
BD4A17S4P\tBD6A17S6P\tBD6A20S6P\tBD6A24S6P\tBD6A17S8P\tBD6A20S8P\tBD6A24S8P\tBD6A20S10P\tBD6A24S10P\tB1A20S15P\tB1A24S15P\tB1A8S20P\tB2A8S20P\tB2A24S15P\tB2A24S20P\tB2A20S20P
☆ Active Balancer Equalizer:
JK-B1A16S JK-B2A16S JK-B1A24S JK-B2A24S
☆ Active Balancer Equalizer:
JK-B1A16S JK-B2A16S JK-B1A24S JK-B2A24S
Models and parameters of JK BMS seen in the picture blew.
JK jikong Active Equalization Balancer Introduction
→☆◎ Support 2S to 24S battery pack
→☆◎ Single-cell voltage acquisition range: 1V ~ 5V, accuracy: ±3mV
→☆◎ Support all battery types such as: Li-ion, Lipo, Lifepo4, LTO, super capacitor and other batteries
→☆◎ Single-cell voltage acquisition range: 1V ~ 5V, accuracy: ±3mV
→☆◎ Support all battery types such as: Li-ion, Lipo, Lifepo4, LTO, super capacitor and other batteries
→☆◎ The balance current is independently set within the range of 0.1~1A/2A/5A/10A, independent of the battery voltage difference
→☆◎ Supports balanced cascade, suitable for battery packs above 24S, and can theoretically be cascaded infinitely; for example,Can be 28S, 32S, 36S, 40S...etc
→☆◎ Supports balanced cascade, suitable for battery packs above 24S, and can theoretically be cascaded infinitely; for example,Can be 28S, 32S, 36S, 40S...etc
→☆◎ Support BT communication, equipped with mobile APP, real-time viewing of battery status
→☆◎ Balance line resistance detection, early detection of abnormal contact faults
→☆◎ Power supply range: 40V~100V
→☆◎ Low-voltage shutdown function to prevent battery damage
→☆◎ Size: 157*98.2*18.7 (1A/2A). 5A/10A larger size
→☆◎ Balance line resistance detection, early detection of abnormal contact faults
→☆◎ Power supply range: 40V~100V
→☆◎ Low-voltage shutdown function to prevent battery damage
→☆◎ Size: 157*98.2*18.7 (1A/2A). 5A/10A larger size
Type | JK-B1A16S | JK-B2A16S | JK-B1A24S | JK-B2A24S | |||
Active equalization Current | 0.1-1A | 0.1-2A | 0.1-1A | 0.1-2A | |||
Strings | 2-16S | 2-24S | |||||
Applicable voltage | 40-100V | ||||||
APP | Android IOS available | ||||||
Temperature range | -30℃ to +70℃ | ||||||
Product Description
Specification
item | value |
Model Number | JK BMS 01 |
Place of Origin | GUA |
Brand Name | JK |
Base Material | copper |
Copper Thickness | 1-2mm |
Board Thickness | 1.5mm |
Min. Hole Size | 1mm |
Min. Line Width | 1mm |
Min. Line Spacing | 1mm |
Surface Finishing | copper plated |
Board Size | 135*83*17.6mm/162*102*20mm |
Product Type | JK BMS |
Voltage | 12V ~ 96V |
Current | 40A 60A 80A 100A 150A 200A 500A |
Apply For | Lifepo4/Li-ion/Lto Battery Pack |
With BT | YES |
App | Android/IOS Available |
R485/CAN/GPS | support |
Screen | support |
Single package size | 26X16X6 cm |
Board Size | 135*83*17.6mm/162*102*20mm |
