Характеристики
* Sound insulation
vibration and noise generated by water flow.
Due to the inner sheet of graphite structure of gray cast iron, the cast iron drainage pipe can absorb the
vibration and noise generated by water flow.
The wall thickness is thicker than UPVC, and the pipes are connected with seal rubber rings, the cast iron pipe gains an good effect against noise.
* High strength and density, durable
(a. Maximum Brinell Hardness 260HB
(b.Minimum Tensile Strength 200MPa
(c.Minimum Ring Crush Strength 350MPa
(d. Minimal maintenance costs
* Anti-corrosion
Inside epoxy painting with thickness above 120 micron, outside paint ( Epoxy resin paint, epoxy coal asphalt, epoxy powder etc.) in color red with thickness above 40 micron.
Inside epoxy painting with thickness above 120 micron, outside paint ( Epoxy resin paint, epoxy coal asphalt, epoxy powder etc.) in color red with thickness above 40 micron.
* Easy to install&maintain
Flat straight pipeline, good convenience of installation. It has a reinforced seal: EPDM clamps and cuffs according to the EN681 standard. With these two parts, it is easy to set the desired rotation angles to the system.
Flat straight pipeline, good convenience of installation. It has a reinforced seal: EPDM clamps and cuffs according to the EN681 standard. With these two parts, it is easy to set the desired rotation angles to the system.
Nominal Diameter(DN): | DN50-DN300 |
Sizes: | 40mm-300mm |
Main Material： | Cast Iron |
Length: | 3000mm |
Wall Thickness： | 3.0-7.0mm |
Standard： | EN545 /BS EN877/ISO 6594/ISO2531 |
Application： | Drainage water system |
Shape： | Round |
Hardness： | 230HB |
Pull Strength： | >200MPa |
Yield (≥ MPa): | ≥350Mpa |
Surface treatment: | Epoxy coating |
Paint: | Red/Black/Yellow |
Packing: | In bulk/Pallet |
The connection of flexible cast iron pipes insists of three types: A,B and W. In general, B and W are more commonly utilized.
Size (mm) | Innerdia (mm） B | Outterdia(mm) J | Wall thickness (mm) T | Length(mm) L | Unit weight (kg) | Laying Length(m) |
50 | 50 | 58 | 3.5 | 3000±20 | 13 | 180 |
(2”) | 50 | 61 | 4.3 | 3000±10 | 16.5 | |
75 | 75 | 83 | 3.5 | 3000±20 | 18.9 | 123 |
(3”) | 75 | 86 | 4.4 | 3000±10 | 24.4 | |
100 | 100 | 110 | 3.5 | 3000±20 | 25.2 | 86 |
(4”) | 100 | 110 | 4.8 | 3000±10 | 34.6 | |
125 | 125 | 135 | 4.0 | 3000±20 | 35.4 | 70 |
(5”) | 125 | 137 | 4.8 | 3000±10 | 43.1 | |
150 | 150 | 160 | 4.0 | 3000±20 | 42.2 | 59 |
(6”) | 150 | 162 | 4.8 | 3000±10 | 51.2 | |
200 | 200 | 210 | 5.0 | 3000±20 | 69.3 | 37 |
(8”) | 200 | 214 | 5.8 | 3000±10 | 81.9 | |
250 | 250 | 274 | 5.5 | 3000±20 | 99.8 | 26.4 |
(10”) | 250 | 268 | 6.4 | 3000±10 | 113.6 | |
300 | 300 | 326 | 6.0 | 3000±20 | 129.7 | 20.3 |
(12”) | 300 | 318 | 7.0 | 3000±10 | 148 |
XINLURUN cast iron pipes fabricated by centrifugal technology STRICTLY MEET THE FOLLOW STANDARDS | ||||
Material | Pull Strength(Mpa) | Yield (≥ MPa): | ||
No.150 cast iron implemented to ISO185 | Flat straight pipe&fittings: ≥150Mpa | Average（3 times testing）：≥350Mpa | ||
phosphorus≤0.6% | W-Type flat straight pipe：≥200Mpa | Every single test：≥300Mpa | ||
Sulfur≤0.1% | Pipe fittings：≥150Mpa | / | ||
Standard：EN545 /BS EN877/ISO 6594/ISO2531 | Standard：BS EN877 | Standard：ISO2531/EN545 | ||
Where this flexible cast iron can be used?
Construction,machine structure pipe, Agriculture equipment pipe, Water and gas pipe, Greenhouse pipe, Scaffolding pipe, Building material tube, Furniture tube, Low pressure fluid tube, Oil pipe, etc.
Founded in 2012, chongqing xinlurun pipe industry co.,ltd has committed to manufacture cast iron products and fittings in the past ten years.
Our main productions are DN80mm-DN2600mm ductile cast iron pipe& fittings, cast iron pipes &fittings,Valves and rubber rings. The annual production capacity of 300,000 tons for casting iron pipes, and 30,000 tons for the casting iron fittings . Our main customers are from U.A.E, South Africa, Iraq, Syria, Bangladesh,Singapore and so on.
Our factory covers an area of 80,000 square meters, with own advanced production equipment, laboratory, independent R & D, and innovation department. We have an whole producing& assembly line consist of medium frequency electric furnace, spectrum analyzer, centrifugal molding, annealing, zinc spray, finishing, and packaging.
The casting iron pipes&fittings are widely used in gas transmission, water supply, water launching, drainage, electric power and other projects. The fabricated products are strictly inspected and complied with ISO 2531, EN545, BS EN598. Meanwihile, the blast furnace cement internal protection complies with the standard ISO 4179, metallic zinc complies with the standard ISO8179.
Our main productions are DN80mm-DN2600mm ductile cast iron pipe& fittings, cast iron pipes &fittings,Valves and rubber rings. The annual production capacity of 300,000 tons for casting iron pipes, and 30,000 tons for the casting iron fittings . Our main customers are from U.A.E, South Africa, Iraq, Syria, Bangladesh,Singapore and so on.
Our factory covers an area of 80,000 square meters, with own advanced production equipment, laboratory, independent R & D, and innovation department. We have an whole producing& assembly line consist of medium frequency electric furnace, spectrum analyzer, centrifugal molding, annealing, zinc spray, finishing, and packaging.
The casting iron pipes&fittings are widely used in gas transmission, water supply, water launching, drainage, electric power and other projects. The fabricated products are strictly inspected and complied with ISO 2531, EN545, BS EN598. Meanwihile, the blast furnace cement internal protection complies with the standard ISO 4179, metallic zinc complies with the standard ISO8179.
Q1. Are you trading company or manufacturer?
A:We are a manufacturer with own branch company and sales department, you will get a factory-direct price from us if you buy from us.
Q2. How Can I order?
A:Please contact our sales representatives, they are able to communicate in English and will provide the most suitable purchase solutions for you.
Q3. How does your factory do regarding quality control?
A:Quality is priority. Our people always attach great importance to quality control from the production beginning to the end. We have well-trained and professional workers and strict QC system in each production link, and each product has to be 100% inspected before shipment.
Q4. What are the terms of payments?
A:We accept T/T、Western Union、LC、Paypal etc.
Q5. What's your delivery time?
A:In general, the items which are in stock will be shipped out within 3 working days, for customized products and huge order, the delivery time will be based on our negotiation. Please be assured we'll make the delivery as soon as possible with the guaranteed quality.
A:We are a manufacturer with own branch company and sales department, you will get a factory-direct price from us if you buy from us.
Q2. How Can I order?
A:Please contact our sales representatives, they are able to communicate in English and will provide the most suitable purchase solutions for you.
Q3. How does your factory do regarding quality control?
A:Quality is priority. Our people always attach great importance to quality control from the production beginning to the end. We have well-trained and professional workers and strict QC system in each production link, and each product has to be 100% inspected before shipment.
Q4. What are the terms of payments?
A:We accept T/T、Western Union、LC、Paypal etc.
Q5. What's your delivery time?
A:In general, the items which are in stock will be shipped out within 3 working days, for customized products and huge order, the delivery time will be based on our negotiation. Please be assured we'll make the delivery as soon as possible with the guaranteed quality.
