TK-7Y регулятор солнечного нагрева воды под давлением
US $10.00-$30.00
Внешний бак для 50 литров 100 система крыши без давления плоская пластина солнечный водонагреватель
- Категория: Solar Water Heaters >>>
- Поставщик: Beijing,Sola,Solar,Energy,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-18-2025 | 789.90 $* | 805.0 $* |
| Jul-18-2025 | 640.44 $* | 653.98 $* |
| Jun-18-2025 | 776.54 $* | 792.60 $* |
| May-18-2025 | 770.71 $* | 785.94 $* |
| Apr-18-2025 | 615.13 $* | 627.82 $* |
| Mar-18-2025 | 758.61 $* | 773.49 $* |
| Feb-18-2025 | 751.74 $* | 766.91 $* |
| Jan-18-2025 | 745.67 $* | 760.53 $* |
Характеристики
Product Details
Description | Compact Pressurized solar water heater |
Material of out tank | 0.6mm color coated plate |
Material of inner tank | Food grade 0.6mm thickness SUS304-2B |
Tank insulating layer | 50-70mm 45kg/m³ Flame retardant high density polyurethane foam |
Working pressure | 6 Bar |
Testing pressure | 10 Bar |
Bracket | Galvanized steel |
Heat exchange coil | There is no |
Cold/hot water port | DN25~DN50 |
Product net weight | 105kg |
Number of collector tubes | 1 pieces |
Collecting area | 2.0㎡ |
Total water capacity | 105L |
Product size | Length A (mm) 1150、 Width B (mm) 2000 |
Product Display
product detail
Coil heat exchange technology
Soler sunshine pressurized fresh water solar adopts RHEs reverse heat exchange technology. The open water tank is used to store
heat energy, and the closed heat exchanger is used to exchange heat and take water. Pressurized water does not need to add booster
pump, and the water quality is fresh without secondary pollution.
heat energy, and the closed heat exchanger is used to exchange heat and take water. Pressurized water does not need to add booster
pump, and the water quality is fresh without secondary pollution.
20 second rapid heat exchange
With the rapid heat exchange technology developed by sola sunshine, cold water flows through the stainless steel bellows heat
exchanger for 20 seconds and quickly turns into hot water. And the temperature difference between the water temperature and the
heat medium after heat exchange is 2 ~ 5 ℃. Moreover, the water quality is fresh, does not contain nitrite and Legionella, is not
easy to scale, and can be used as kitchen water.
exchanger for 20 seconds and quickly turns into hot water. And the temperature difference between the water temperature and the
heat medium after heat exchange is 2 ~ 5 ℃. Moreover, the water quality is fresh, does not contain nitrite and Legionella, is not
easy to scale, and can be used as kitchen water.
Modular design and expandable water tank
Sola sunshine fresh water solar energy adopts modular design, and the water tank can be expanded. It can be used in places with large water consumption and many water points.
Antifreeze type flat plate collector
Flat plate collector using the copper material, endothermic USES blue coating, black chromium coating technology, each square panels can be instead of 150 kg coal, a 147 - degree, around 80 kg per square collection hot water more than 50 ℃, using binary, not easy scaling, can discharge, don't tube, is not afraid of the hail, cover adopts toughened glass cover, but under pressure, Belong to welding between metal pipes, service life of more than 30 years.
The end cover of the solar water tank adopts flange connection, which can be opened and maintained at any time, making it safer and more convenient to use. | The solar energy adopts a modular design, and the water tank can be expanded to meet the needs of customers with large water consumption and many water points. | The rapid heat exchange technology developed by Sole Sunshine, cold water flows through the stainless steel bellows heat exchanger for 20 seconds to quickly turn into hot water.the water quality is fresh, and it can be used as kitchen water. |
Product advantages
The water quality fresh and drinkable
Open water tank for heat storage, closed coil for heat exchange and water intake. Sola sunshine 20 second rapid heat exchange technology is adopted. The hot water is ready to use, and the water quality is fresh. It can be used as kitchen water.
Constant water pressure
The hot water pressure comes from the municipal cold water pressure, which matches with the cold water. It is simple to adjust the water temperature. The pressure is surging, the water volume is sufficient, and the use experience is good.
Ease of use and maintenance free
The collector uses heat medium water without scaling; The heat exchanger adopts corrugated pipe floating heat exchange to take
water, which is not easy to scale.
The product is simple to operate and easy to maintain.
water, which is not easy to scale.
The product is simple to operate and easy to maintain.
It can be connected with other energy sources
As a pre heating equipment, solar water heater can be combined with conventional energy (electric water heater, gas water heater, air energy heat pump).
