Полностью автоматическая быстродействующая гидравлическая формовочная машина для дома посуды изделий из силиконового каучука 150

Полностью автоматическая быстродействующая гидравлическая формовочная машина для дома посуды изделий из силиконового каучука 150

Категория: Other Plastic & Rubber Machinery >>>
Поставщик: Dongguan,Kesheng,Intelligent,Equipment,Technology,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-17-2025	0.34 $*	0.84 $*
Aug-17-2025	0.75 $*	0.47 $*
Jul-17-2025	0.10 $*	0.2 $*
Jun-17-2025	0.77 $*	0.88 $*
May-17-2025	0.53 $*	0.5 $*
Apr-17-2025	0.70 $*	0.15 $*
Mar-17-2025	0.40 $*	0.61 $*
Feb-17-2025	0.0 $*	0.35 $*
Jan-17-2025	0.89 $*	0.8 $*

Характеристики

Product Description

Rubber products, band, seals, gaskets making machine, double working stations with 2 pumps, full automatic, high pricision, fast speed, 2 layers mold lift-up hydraulic molding machine, High-precision automactic fast-speed track-style hydraulic molding machine

Machine main feature:
1. Track mold, mold lift angle of up to 90 degrees to facilitate personnel to opearate, suitable for 2-layers mold;
2. Machine simple and fast, easy to work in with mold, quick adjustment, easy to repair and maintenance;
3. Adopt dual power individual circuit design, stable, quiet, low failure rate, two axes can be operated simultaneously;
4. With adjustable slow speed of mold features to suit different types of modules;
5. With proofread slow speed of mold function, proofread mold more accurate, more secure.

Applicable products:

Industrial rubber parts, auto parts, medical bottle stoppers, household ware, cookware, silicone/rubber multi-layer molded products.

Main parts instruction:

No.	Part name	Brand / Specification	Remarks
1	Motor	Taiwan Tatung / Dongguan Motor	Large power, quiet and silent
2	Hydraulic oil Pump	Japan SCENERY / HIGH-TECH	Collective type circuit system
3	PLC	Japan MITSUBISHI	Independent writing, easy to poerate
4	Touch Screen	Taiwan Panel Master	Can be seen and operated clearly and conveniently
5	Heating pipe	Taiwan brand	Nickel-chromium alloy wire, never rust
6	Oil seal	Japan NOK	Wear-resistant,durable,no leakage
7	Solenoid valve	Taiwan Vitory / Taiwan 7 Ocean	Fast switching operation,long service life
8	All kinds of electrical accessories	Japan Fuji	Performance and stability
9	Temperature control system	Japan Omron	Using PID correction, make the temperature evenly, the error value at ± 3 ºC
10	Pressure sensor	Denmark TRAFAG / PRESICE	Accuracy,easy to use
11	Heating control system	Taiwan Yang Ming	Make the temperature evenly, the error value at ± 3 ºC
12	Casting	FCD50 Ductile Iron	Aging passivation,high tensile strength
13	Column / Pillar	Medium carbon steel	Hardness up to HRC55-58
14	Work plate	Taiwan brand	45 # high carbon steel, grinding, surface nitriding process, hardness HRC50-55
15	Middle body base	Umbrella shape design	Make the machine pressure evenly, no leakage of material, no bubbles
16	Vacuum pump	Germany Ristschle / Rufus	Pump quickly, can reach 760 mm Hg within 5 seconds

Machine Specification and parameter:

Model	100Ton	150Ton	200Ton	250Ton	300Ton	350Ton	400Ton	450Ton
Clamping force(Ton)	100	150	200	250	300	350	400	450
Stroke(mm)	250	250	250	250	300	300	300	300
Heating plate size(mm)	400x400	450x460	560x560	600x650	650x650	750x700	850x850	1000x1000
Main cylinder diameter(mm)	250	300	355	400	450	475	500	560
Horse power(HP)	5x2	5x2	10x2	10x2	10x2	15x2	15x2	15x2
Electrical power(KW)	12	17	22	34	34	43	48	72
Gross weight(KG)	4500	5500	7000	9000	11000	15000	17500	21500
Machine size(LWH mm)	2360x1650x1850	2650x2000x2000	2930x2350x2100	3200x2700x2500	3460x2630x2500	3650x2600x2610	3750x2700x2800	4200x3300x3300

Characteristic of rubber products processing molding machine:
1. Scientific and reasonable design, more strong and stable.
2. Use high precision and supper quality machine parts.
3. Unique temperature control system, keep the work plate temperature uniform.
4. Convenient operation control system, high efficient hydraulic system, strong and multi-function.

Our machine advantage:
1. Integrally cast molding of machine body, compact structure, the longest useful life.
2. Adopt integrated oil-circle design, high efficient and more stable, low failure rate, energy saving.
3. Japan Mitsubishi operation control system, independent programming; Taiwan Panel Master HMI (touch screen), can be learned and used easily.
4. You can switch in full-automatic and semi-automatic, make the work process simple, saving labor costs.
