Классическое оборудование для переработки текстильных отходов производственная линия джинсовой и

NO

MODEL

UNIT

Q’TY

REMARKS

1.

GM600

SETS

1

Iron roller

2.

GM250

SETS

6

/

3.

Motors

SETS

7

30KW +11KW+5.5*5KW

4.

Electric control cabinet

SETS

1

/

5.

Pipes

SETS

7

/

6.

Cutting machine

SETS

1

Include:With motor& 5 pcs cutting blades .

NO

ITEM

DESCRIPTION

1

Model

GM600*1+GM250*6

RFiller&Spinning products

2

GM600 Opener size

2800*1900*1400

GM250 Cleaner size(Unit set)

1200*1750*1150

3

Weight

6000KG

4

Total power

30KW+11KW+5.5KW*5

5

Working width

1300mm/ Unadjustable£

1000mm/ UnadjustableR

6

 Main roller

R6 channels/Φ600/Teeth wire

R8 channels/Φ250/Teeth wire

7

Capacity

R180-220Kg/h under the working width 1000mm

Depending on the raw material and product requirements(length of fiber), also the correct operate

8

Protection

RMain motor overload protection Open phase protection

9

Way of control

Constant power & Inverter control

10

Bearing

KOYO/Or according to the customer's requirements

11

Inverter

CHINT

12

Print Color

According to the customer's requirements

13

The control cabinet and panel

Electric control cabinet

14

Note

1. CNC cutting equipment and machining center equipment will be used in the manufacture of the machine.

2. All rotating shaft through dynamic balance test.

3. Shaking range must be less than + / - 0.55 mm, and does not influence the main rollers (based on the correct installation and the base must be in the same plane under a highest speed)
