Огнеупорная поверхность с силиконовой обработкой и саржевым переплетением ткань из стекловолокна силиконовым резиновым
- Категория: Fiberglass Products >>>
- Поставщик: Changshu,Jiangnan,Glass,Fiber,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-18-2025 | 1.25 $* | 1.10 $* |
| Jul-18-2025 | 1.33 $* | 1.41 $* |
| Jun-18-2025 | 1.54 $* | 1.85 $* |
| May-18-2025 | 1.39 $* | 1.63 $* |
| Apr-18-2025 | 1.64 $* | 1.50 $* |
| Mar-18-2025 | 1.60 $* | 1.31 $* |
| Feb-18-2025 | 1.6 $* | 1.69 $* |
| Jan-18-2025 | 1.12 $* | 1.62 $* |
Характеристики
Product Introduction
3732 Silicone Coating Fiberglass Cloth | ||||||||
Item Model | 3732 Silicone Coating Cloth | |||||||
Description | E-glass Industrial Fabric | |||||||
Weave Structure | 1/3 Twill Weave | |||||||
Cloth Weight | 430gsm | |||||||
Silicone Coating Weight | 160g/m2 | |||||||
Thickness | 0.43mm | |||||||
Yarn Type | Warp | EC9 68 1*2 | ||||||
Weft | EC9 68 1*2 | |||||||
Thread Count | Warp | 18±1 ends/cm | ||||||
Weft | 12±1 picks/cm | |||||||
Breaking Strength | Warp | 700N/cm | ||||||
Weft | 600N/cm | |||||||
Loi | < 5% | |||||||
Working Temperature | Basic fabric 550 ºC, Silicone coating 260 ºC. | |||||||
Color | Black, Grey, Red | |||||||
Fire Resistance | Non-Flame | |||||||
Products Description
What is silicone coating fiberglass cloth?
Knife coating is one popular technique for the coating of textile materials. Because the layers of the applied coating are usually very thin, the rheology of the coating is of primary importance. Rheological properties are controlled mostly by the choice of polymer. silicone coated fiberglass cloth is made with high-temperature resistance. Jiangnan silicone-coated fiberglass cloth has good resistance to extreme temperatures, with operating temp ranging from -50°C to +260°C. The general color is Grey and Red. The normal weight of the coating is 40g for 1 side or 2 sides. And 80g for 1 side or 2 sides. All the coating is liquid silicone and it is soft for the fabric. There are different features for the silicone coated fiberglass fabric, you can check it as below:
Product Properties
Type: E-glass
Coating: 130g on each side
Structure: silicone+glass fiber
Weight:590g/m2
Flammability: ≤25%
Thickness: 0.45mm
Weave: Plain
LifeTime: 10 Years under normal environment
Dielectric Constant: 3-3.2
Breakdown Voltage: 20-50 KV/MW
Coating: 130g on each side
Structure: silicone+glass fiber
Weight:590g/m2
Flammability: ≤25%
Thickness: 0.45mm
Weave: Plain
LifeTime: 10 Years under normal environment
Dielectric Constant: 3-3.2
Breakdown Voltage: 20-50 KV/MW
Silicone Coating Features
Maximum continuous coating temperature to 500oF
Silicone Coated / Impregnated Fiberglass Fabric in high-temperature applications
Silicone adds abrasion resistance and waterproofing.
Silicone Coated / Impregnated Fiberglass Fabric in high-temperature applications
Silicone adds abrasion resistance and waterproofing.
Application
Duct Connection
Soft Connection
Connector for Air Duct
How to choose Knife Coating Silicone Coating Fiberglass Fabric?
Knife Coating Silicone Coating Differences between Premier and Industrial Quality | ||||||
Premier Quality | Industry Quality | |||||
1 | Loomstate | High-speed Rapier Weaving Machine | Normal Dornier (small weaving defects might occur occasionally) | |||
2 | Silicone | Wet, High-Quality Silicone Rubber | Dry, Standard Silicone Rubber | |||
3 | Appearance | Shiny and Tacky | Dull but Smooth | |||
4 | Performance | Strong Adhesion Strength Between Silicone Fabric, High Abrasion Resistance | Normal Adhesion Strength Between Silicone Fabric, Normal Abrasion Resistance, silicone might be peeled or scratched off in some particular circumstances | |||
5 | Application | Mostly for Removable Insulation Jackets | Mostly for Welding, But Also for Economic Removable Insulation Jackets | |||
Related Products
Premier Quality | Thickness (mm) | Weight (g/m2) | Weaving | |||
E7628-LG1 | 0.2MM | 230 | Plain | |||
E7628-LG2 | 0.23MM | 280 | Plain | |||
E3732-LG1 | 0.4MM | 510 | Twill | |||
E3732-LG2 | 0.45MM | 590 | Twill | |||
E666-LG1 | 0.65MM | 750 | Satin | |||
E666-LG2 | 0.7MM | 850 | Satin | |||
E3784-LG1 | 0.85MM | 950 | Satin | |||
E3784-LG2 | 0.9MM | 1050 | Satin | |||
Other Thickness and Weight Can be Customized | 0.9mm | 1050 | Satin | |||
Industrial Quality | Thickness (mm) | Weight （g/m2) | Weaving | |||
E7628-SG1 | 0.2MM | 230 | Plain | |||
E7628-SG2 | 0.23MM | 280 | Plain | |||
E3732-SG1 | 0.4MM | 510 | Twill | |||
E3732-SG2 | 0.45MM | 590 | Twill | |||
E666-SG1 | 0.65MM | 750 | Satin | |||
E666-SG2 | 0.7MM | 850 | Satin | |||
E3784-SG1 | 0.85MM | 950 | Satin | |||
E3784-SG2 | 0.9MM | 1050 | Satin | |||
Other Thickness and Weight Can be Customized | ||||||
More Related Products
Company Information
Changshu Jiangnan Glass Fiber Co., Ltd is one of the leading professional manufacturers and exporters of fiberglass composite and thermal resistance materials in China. The Company was established in 1956 and it is located in the famous Chinese cultural and historic city –Changshu. The plant covers a total area of more than 70,000 square meters. It is only 80km from Shanghai port and 200km from Ningbo port. The superior location makes it enjoy pleasant climate all year around and convenient transportation facilities, such as by the Highway along the Yangtze River, Sujiahang Highway, and Changshu Port.
Presently, we have adopted the advanced high-speed rapier weaving machine, three twist yarn machines equipped with variable frequency unit controllers, and two-meter-width coating equipment to ensure the leading supplier to the market with powerful output and guaranteed quality. Jiangnan produces over 8,000 tons of fiberglass yarn, 50 million square meter alkali-resistant fiberglass-mesh, 2.4 million pieces of fire blankets, 10 million meters of fiberglass cloth with silicone, polyurethane, Acrylic, EPDM coating, and 8 million square-meter of fabric used in electronic industry and fireproof. The products are widely used in the field of construction, transportation, electricity, insulation material, wind power generation, and smoke curtains.
Moreover, our production and quality control team has more than 30 years of development and research experience in various fiberglass products. Meanwhile, Jiangnan has its own fire-test laboratory, according to the latest fire blanket standard. We have routine and extensive cooperation with the world leading testing organizations. We also have our own fiberglass yarn raw material subsidiary in Shandong - Shandong Jinming Glass Fiber Co., Ltd. Additionally, Jiangnan have R&D investment and production capacity for blended fiberglass fabrics and special glass fiber fabrics.
Jiangnan and its products have been certified by various certification bodies and organizations with a number of certifications like ISO9001:2015 Quality Systems, ISO14001:2014 Environmental Systems, BSI Kitemark，LPCB, TUV, Australian QAS and other certificates. Jiangnan has cooperative partners across several countries like America, Europe, Australia, Japan, Korea, the Middle East, and other countries.
Jiangnan will continue to make efforts to be the leader with competition and creativity in the global industries based on our core corporate values of "Superior Quality, High Integrity, Continuous Innovation"!
Jiangnan and its products have been certified by various certification bodies and organizations with a number of certifications like ISO9001:2015 Quality Systems, ISO14001:2014 Environmental Systems, BSI Kitemark，LPCB, TUV, Australian QAS and other certificates. Jiangnan has cooperative partners across several countries like America, Europe, Australia, Japan, Korea, the Middle East, and other countries.
Jiangnan will continue to make efforts to be the leader with competition and creativity in the global industries based on our core corporate values of "Superior Quality, High Integrity, Continuous Innovation"!
FAQ
1. Before the order, may I have the sample to test the fire resistance quality?
Samples can be arranged to be sent to you for testing before placing an order. But my shipping will be paid by you. Of course, we will adjust additional samples and shipping costs to your bulk order.
2. How can I get your samples?
Of course, we can send you some samples. Most samples are free, but sometimes we charge a small sample fee. Maybe you can also send us your DHL or EMS/UPS/TNT etc account so you can pay directly to your carrier.
3. Can we print our logo or need our color or size?
We can print your logo, we can also make it to your size and print it in your color.
4. How many payment methods can you accept?
Regarding payment terms, if it is less than $1000.00, we want 100% TT, usually for bulk order, hope can pay 30%-50% in advance, the rest should be paid before shipment.
Samples can be arranged to be sent to you for testing before placing an order. But my shipping will be paid by you. Of course, we will adjust additional samples and shipping costs to your bulk order.
2. How can I get your samples?
Of course, we can send you some samples. Most samples are free, but sometimes we charge a small sample fee. Maybe you can also send us your DHL or EMS/UPS/TNT etc account so you can pay directly to your carrier.
3. Can we print our logo or need our color or size?
We can print your logo, we can also make it to your size and print it in your color.
4. How many payment methods can you accept?
Regarding payment terms, if it is less than $1000.00, we want 100% TT, usually for bulk order, hope can pay 30%-50% in advance, the rest should be paid before shipment.
