18650 50100 aa литий-ионная батарея импульсный микрокомпьютер точечный сварочный аппарат aaa AC педаль ручной аккумулятор

1.The inverter frequency is 4kHz, and the time control accuracy is 250us, which can achieve the precision welding effect.

2.Two control modes of primary constant current and secondary constant current

3.Programmable up to 128 sets of welding specifications

4.Two-stage heating process with independent ramp up and ramp down and real-time welding current waveform display

5.Multi output input I/O interface, better application in automation scenarios

6.Counting system of solder joint count, workpiece number, packing number, electrode repair mold count, etc., convenient for production management

7.485 communication and BCD code control function: can be externally connected with industrial computer, PLC and other equipment

8.Copy welding specification process parameters, convenient and fast setting of specification parameters

9.Authority function, three-level user password authority management, convenient for quality management

10.Record and store welding current, time, network voltage, specification number, welding result, etc. support USB data export

11.Alarm recording function, convenient to check historical alarm information

12.Current control accuracy: 5%
