Характеристики



Product Description
This series of camera parameter archives are saved in the form of files, which is convenient for mass production and release, easy to develop, and compatible across platforms; it supports simultaneous operation of multiple cameras, and the work is stable and reliable; it supports 8bit, 24bit, and 32bit image data format output; supports small resolution and high frame rate Preview, large resolution snapshot function, seamless switching; support resolution customization function, view cropping (ROI), BIN, SKIP snapshot, zoom functions can be freely combined and set to match different aspect ratios and field of view requirements.


Product Features
(1)2 lane eDP interface with 2.7 Gbps link rates
(2)16.7M(6bit+Hi FRC) color depth, color gamut 45%
(3)Green product (RoHS & Halogen free product
(4)On board LED driving circuit
(5)Low driving voltage and low power consumption
(6) Adjust backlight brightness with PWM mode


Specification


item
SMI-TFT-01
Active area(mm)
344.16(H) *193.59(V)
Number of pixels
1920(H) *1080(V)
Pixel pitch(mm)
0.17925(H) *0.17925(V)
Pixel arrangement
RGB Vertical stripe
Display colors
16.7M
Color gamut
45%@CIE1931
Display mode
Normally black
Dimensional outline(mm)
359.50*206.50*3.2(MAX)
Weight(g)
460(TYP)
Surface treatment
Anti-Glare
Surface hardness
3H

Power consumption(W)
PD : 0.75(Max.)
Module 3.564(max)
Power Supply Voltage
-0.3~4V
Logic Supply Voltage
-0.3~Vcc V
Operating Temperature
0~50℃
Storage Temperature
-20~60℃
