При создании PCBA производитель в Шэньчжэнь OEM ODM ручная пресс-форма для CEM-3 медь electrolyticfoil электроники Diy Многослойная
- Категория: Rigid PCB >>>
- Поставщик: Shenzhen,Hidly,Electric,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.21 $* | 0.94 $* |
| Aug-19-2025 | 0.36 $* | 0.0 $* |
| Jul-19-2025 | 0.77 $* | 0.68 $* |
| Jun-19-2025 | 0.2 $* | 0.47 $* |
| May-19-2025 | 0.89 $* | 0.13 $* |
| Apr-19-2025 | 0.23 $* | 0.17 $* |
| Mar-19-2025 | 0.25 $* | 0.22 $* |
| Feb-19-2025 | 0.56 $* | 0.84 $* |
| Jan-19-2025 | 0.49 $* | 0.80 $* |
Характеристики
PCB Capacities and Technical Specification | ||
Layer | 1, 2, 4, 6, up to 24 layer | |
Material | FR-4, High Tg, Isola, Aluminum, Rogers, etc | |
PCB type | Rigid, flexible, rigid-flexible | |
Shape | Rectangular, round, slots, cutouts, complex, irregular | |
Max PCB dimensions | 1200mm*600mm | |
Thickness | 0.2~4.0mm, Flex 0.01~0.25'' | |
Thickness tolerance | ± 10% | |
Copper thickness | 0.5-6 oz | |
Copper thickness tolerance | ± 0.25oz | |
Surface finish | HASL, LF HASL, Imm Gold, Imm Silver, OSP etc | |
Solder mask | Green, red, white, yellow, blue, black, orange, purple | |
Silk screen | White, black | |
Silk screen min line width | 0.006'' or 0.15mm | |
Min drill hole diameter | 0.01'', 0.1mm or 10 mil | |
Min trace/gap | 0.075mm or 3mil | |
PCB cutting | Shear, V-score, tab-routed | |
FAQ
Q1.What is needed for PCB PCBA quotation?
A: PCB: Quantity, Gerber file and Technic requirements(material,surface finish treatment, copper thickness,board thickness ,...)
PCBA: PCB information, BOM, (Testing documents...)
Q2. What file formats do you accept for PCB PCBA production?
A: Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BOM: Excel (PDF,word,txt)
Q3. Are my files safe?
A: Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole
process.. All documents from customers are never shared with any third parties.
Q4. MOQ?
A: There is no MOQ in HIDLY.We are able to handle Small as well as large volume production with flexibility.
Q5.Shipping cost?
A: The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to
quote you the shipping cost.
