45 degree elbow silicone tubing flame retardant silicon rubber hose food grade silicone hose pipe for car
Product Description
1. Size/hardness/color can be customized.
2. Hardness range :50A ~80A, density range :1.30-1.4g/mm
3. Surface: high resistance to low pressure, high and low temperature, and UV.
4. Product certification: Made of 100% silicone, after strict testing, in line with ROSH, REACH, UL and other certifications.
5. Product service: Our factory can also allocate silicone raw materials according to your use requirements or performance
requirements.Size, tear and tensile strength can be customized.
6. Value-added services: Customized OED/ODM, LOGO,etc.
2. Hardness range :50A ~80A, density range :1.30-1.4g/mm
3. Surface: high resistance to low pressure, high and low temperature, and UV.
4. Product certification: Made of 100% silicone, after strict testing, in line with ROSH, REACH, UL and other certifications.
5. Product service: Our factory can also allocate silicone raw materials according to your use requirements or performance
requirements.Size, tear and tensile strength can be customized.
6. Value-added services: Customized OED/ODM, LOGO,etc.
Details Images
Performance of 45 degree silicone hose.
Anti-explosion,high pressure resistant,high resilience,anti-aging.
Excellent heat resistance,inflaming retarding.
Work temperature range :-50℃ ~ 280℃.
Work temperature range :-50℃ ~ 280℃.
Wear resistance,tear resistance,durable.
Multilayer woven,tear resistance,anti-fatigue.
Multilayer woven,tear resistance,anti-fatigue.
Waterproof and dust-proof,insulation.
Non-toxic and tasteless,colorless.
Suitable for all kinds of environment.
Moulding production mode.
Tolerance meet ISO 3302 E1/E2.
No visible mold marks and flash,no burr.
Size/structure be complied with 3D drawing.
Meet RoHS,LFGB,and food grade certificate.
Custom different size,structure or material.
Proofing and testing can be done before mass production.
Logo can be embossed/debossed/printing.
Material Parameter
Temperature range | -50℃~+280℃ | ||||||
Plasticity | 170-400 | ||||||
Density g/㎤ | 1.07-1.22 | ||||||
Hardness(shore A) | 30-90 | ||||||
Bursting force(KG/mm²) | ≥38 | ||||||
Bending radius(mm) | 35-140 | ||||||
Stretching rate | ≥0.00 | ||||||
Tensile strength(Mpa) | ≥60 | ||||||
Elongation at break(%) | ≥(150-700) | ||||||
Tear strength(KN/M) | ≥20.0 | ||||||
Tear permanent deformation(%) | ≤5 | ||||||
Flame retardant grade(UL94-2013) | HB | ||||||
High pressure resistant,high tensile strength performance,chemically stable,weak acid and alkali resistance,excellent heat resistance,inflaming retarding.Meet ISO,PAHS,REACH,ROHS,Food Grade,94V0,LFGB and other related food medical certifications | |||||||
Note | Higher temperature resistant materials can be customized.And different hardness, different numerical value | ||||||
Usage
Our silicone hose is widely applied for car,truck,bus,racing car,heavy machine or other engineering,they are used in car water tank,intercooler,supercharger,automotive air consitioning,vacuum environment,exhaust emission etc.
